YSM20R_KMK_pl - 第61页
19 5 33 28 25 8 15 32 24 4 14 11 23 9 31 7 3 26 11 30 29 13 28 20 9 12 18 5 10 2 21 1 17 22 16 6 27 19 5 33 28 25 8 15 32 24 4 14 11 23 9 31 7 3 26 11 30 29 13 28 20 9 12 18 5 10 2 21 1 17 22 16 6 27 Shaft Head Assy (FM)…
20
15
9
23,24,25,26,27
16
20
13
8
7
1
6
3
12
5
4
11
2
10
22
14
19
21
18
17
20
15
9
23,24,25,26,27
16
20
13
8
7
1
6
3
12
5
4
11
2
10
22
14
19
21
18
17
R Axis Assy (FM)
Head
KMK-1803
5-2
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
90112-2AJ010
BOLT, HEX.SOCKET HEAD
20
2
90152-03J03
SCREW SET
10
3
90990-28J140
WASHER,PLAIN
20
4
90K2L-0G1111
AC SERVO MOTOR
1
5
90K2L-0G1112
AC SERVO MOTOR
1
6
90K2L-0G1113
AC SERVO MOTOR
1
7
90K2L-0G1128
AC SERVO MOTOR
1
8
90K2L-0G1129
AC SERVO MOTOR
1
9
KJX-M7C4A-00
COLLAR,BEARING
5
10
KLW-M7431-00
PLATE,MOTOR R
5
11
KLW-M7432-00
PULLEY,MOTOR R
5
12
KLW-M7433-00
SHEET
5
13
KLW-M7442-00
BLOCK,SHAFT
1
14
KLW-M7445-00
PLATE,SPLINE
1
15
KLW-M7449-00
PLATE,SPLINE
5
16
KLW-M744B-00
PLATE,SPRING
1
17
KLW-M74RA-00
BELT
5
18
91312-03008
BOLT HEX,SOCKET HEAD
10
19
91312-03010
BOLT HEX,SOCKET HEAD
12
20
91317-03008
BOLT HEX,SOCKET HEAD
26
21
92902-03200
WASHER,PLAIN
10
22
99480-03010
PIN,PARALLEL
2
23
KLW-M7430-00
R1 MOTOR ASSY.
1
with 4
24
KLW-M7430-10
R2 MOTOR ASSY.
1
with 5
25
KLW-M7430-20
R3 MOTOR ASSY.
1
with 6
26
KLW-M7430-30
R4 MOTOR ASSY.
1
with 7
27
KLW-M7430-40
R5 MOTOR ASSY.
1
with 8
19
5
33
28
25
8
15
32
24
4
14
11
23
9
31
7
3
26
11
30
29
13
28
20
9
12
18
5
10
2
21
1
17
22
16
6
27
19
5
33
28
25
8
15
32
24
4
14
11
23
9
31
7
3
26
11
30
29
13
28
20
9
12
18
5
10
2
21
1
17
22
16
6
27
Shaft Head Assy (FM)
Head
KMK-1803
5-3
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$PLH4-M5M
JOINT
5
2
$UEF
JOINT
5
3
90112-2AJ008
BOLT, HEX.SOCKET HEAD
10
4
90112-2AJ012
BOLT, HEX.SOCKET HEAD
20
5
90115-02J004
BOLT, HEX. SOCKET HEAD
10
6
90152-03J03
SCREW SET
10
7
90440-10J008
CIRCLIP
20
8
90933-02J685
BEARING
5
9
90990-01J057
BOLT HEX,SOCKET HEAD
10
10
90990-16J002
NUT, U & NUT, SELF LOCKING
5
11
90990-28J045
WASHER,PLAIN
10
12
90990-28J046
WASHER,PLAIN
5
13
90990-29J033
SHIM
5
14
91609-16006
PIN, SPRING
10
15
95602-05100
NUT, U
5
16
KHN-M7145-00
NUT,SPLINE
5
17
KJX-M7C37-00
COLLAR,PULLY
5
18
KJX-M7C4A-00
COLLAR,BEARING
5
19
KJX-M7C4E-00
O-RING
10
20
KJX-M7C4N-00
WAVE WASHER
5
21
KLW-M7441-00
SPLINE SHAFT
5
22
KLW-M7443-00
PULLEY,R
5
23
KLW-M7446-00
ARM
5
24
KLW-M7447-00
BLOCK,SPLINE
5
25
KLW-M744A-00
PLATE,BRG.
5
26
KLW-M744C-00
STOPPER,JOINT
5
27
KLW-M74D0-00
ROLLER LOCK ASSY.
5
28
KV7-M8171-00
PLATE,SPRING
20
29
KV7-M81D1-00
ARM,NOZZLE
10
No assy
30
KV7-M81D3-01
PIN
20
31
KV7-M81D4-00
ROLLER
10
32
90990-22J009
PACKING
5
33
KLW-M741S-A0
SHAFT,SPARE
1
Spare
31
6
31
7
8
33
16
10
32
34
33
34
17
19
15
30
33
20
5
1
25
4
26
13
28
2
20
5
9
1
22
28
27
24
21
11
23
14
3
18
12
27
29
31
6
31
7
8
33
16
10
32
34
33
34
17
19
15
30
33
20
5
1
25
4
26
13
28
2
20
5
9
1
22
28
27
24
21
11
23
14
3
18
12
27
29
Z Axis Assy (FM)
Head
KMK-1803
5-4
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
90112-2AJ006
BOLT, HEX.SOCKET HEAD
20
2
90933-02J605
BEARING
5
3
90990-02J004
SCREW, SET
10
4
90990-18J033
PIN,PARALLEL
10
5
90990-41J148
COLLAR
20
6
90K2M-0F1503
MOTOR
1
7
90K2M-0F1504
MOTOR
1
8
90K2M-0F1505
MOTOR
1
9
90K2M-0F1506
MOTOR
1
10
90K2M-0F1507
MOTOR
1
11
KHN-M712A-00
BEARING
5
12
KHN-M712M-00
COUPLING
5
13
KJX-M711P-00
CIRCLIP 5
5
14
KLH-M7C2P-00
SPACER
10
15
KLW-M7411-01
PLATE,HEAD
1
16
KLW-M7412-00
PLATE L
1
17
KLW-M7413-00
PLATE R
1
18
KLW-M7414-00
HOLDER,MOTOR Z
5
19
KLW-M7415-00
HOLDER,BRG.
5
20
KLW-M7416-00
DAMPER Z
10
21
KLW-M7417-00
PLATE,BRG. Z
5
22
KLW-M7421-00
BALL SCREW
5
23
KLW-M7422-00
LOCK NUT,SCREW
5
24
KLW-M7424-00
HOLDER,NUT
5
25
KLW-M7425-00
GUIDE,Z
5
26
91312-03005
BOLT HEX,SOCKET HEAD
30
27
91312-03008
BOLT HEX,SOCKET HEAD
40
28
91312-03010
BOLT HEX,SOCKET HEAD
20
29
91312-03012
BOLT HEX,SOCKET HEAD
10
30
91312-03022
BOLT HEX,SOCKET HEAD
20
31
91312-04030
BOLT HEX,SOCKET HEAD
4
32
99480-03010
PIN,PARALLEL
5
33
99480-05010
PIN,PARALLEL
6
34
91312-06020
BOLT HEX,SOCKET HEAD
4
