JTF-ML2 8/8/2017 ASM Assembly Systems Page 23 03146665 - xx JTF-ML2, service kit w ith CACCIA Note: M issing function are described in the C RND, 578_C_290317 _Add itionalFun ctio nality forJTF-ML2

JTF-ML2-part- and sales-numbers

8/8/2017 ASM Assembly Systems Page 22

JTF-ML2: 00588116-xx (with two cassettes 9/9)

Optional - JTF-ML2 cassette 7: 00588177-xx

Optional - JTF-ML2 cassette 9: 00588199-xx

Changeover table JTF-ML: 00588112-xx

Mounting Kit for JTF-ML2: 00588117-xx

Output Conveyor Extension SIPLACE TX: 0588110-xx

Part-Number: 03132258-xx

(JTF-ML2 without cassettes)

JTF-ML2

8/8/2017 ASM Assembly Systems Page 23

03146665- xx JTF-ML2, service kit with CACCIA

Note: Missing function are described in the CRND, 578_C_290317_AdditionalFunctionalityforJTF-ML2

Stations Software 710.1

8/8/2017 ASM Assembly Systems Page 24

Touchless placement

On board PCB inspection

Combine C&P20P and CPP in one placement area

X4 Smart Tumble combensation

Measurement Head offset depending on the temperature sensor (TX micron)

Verifying the vacuum tooling, checking the vacuum tooling fiducials (TX micron)

Extend Long Board option up to 1525mm on SX machine with external shuttel

Audible Signal for Indicator Lamps – New Pulse State
