Information
8/8/2017 ASM Assembly Systems Page 27
1. TX machine with the head combination C&P20P and CPP is now possible and the combination to use the vacuum pump
with this combination.
A new retrofit kit to support one gantry with pressere air and the other gantry with vacuum is necessary.
03157293-0101 TX2i Mixed Heads Retrofit Kit
2. New machine type: SIPLACE CA V2 (not released)
The SIPLACE CA4 V2 placement machine supports placement on a single or a dual lane conveyor system.
With the different transport system and only single conveyor is equipped the SIPLACE CA V2 eWLP.
Additional the machine is equipped with the X fiducial bar and various vacuum tooling types (Soko).
Both machine types use the C&P20 M2 or the CPP M head. – SW Support, only!
Information
8/8/2017 ASM Assembly Systems Page 28
3. Providing Process Data via OIB e.g. (Release 07/2017)
Barcode, recipe, barcode side, State(placed,not placed,skipped,..), Feederlocationkey, Gantry, Segment, Placeposition,…
4. X4 Smart Feeder - Tumble Compensation (internal- deactivated))
5. Support new camera type sst.48 G – component camera for C&P20P2 on TX V2 with a greater field of view
(Release R17-2) replacement for sst.23
Field of view 11.1x11.1mm component size 8.2x8.2mm
sst.49 G – component camera high resolution and a greater field of view for C&P20M2
replacement for sst.41
only for TXmicron
This camera required new nozzles Calibration: 4335 -10.8mm long
MFU: 4104 - 10.6mm long
6. Technical information TI2017-04D04 / TI2017-04E04 New calibration function on SX machines “System identification”
