Feature Release 17-1
8/8/2017 ASM Assembly Systems Page 4
- Improvement TX micron (Verifying Vacuumtooling, CPP M head)
- SIPLACE JTF-ML2 - Tray Feeder
- Providing Process data via OIB
- Shuttle TX extension with PCB Barcode and Stationwise download
- Touchless placement for CPx heads
- PCB-Onboard inspection ( M270)
- ASM Printer programming (SIPLACE pro forDEK) / Monitoring DEK
- Ease of Use 2.1
- Extend option LBO1500mm to LBO 1525mm on SX machine
- SIPLACE Bulkfeeder X in combination with SX- and X-Series S (M270)
Additional Documents, which described new features from the release:
- Manual OSC Package feature from release R16-2 (R90) 00198374-xx
- Manual Onboard PCB inspection
- Manual Touchless placement 00198376-xx
- Upload Machine Configuration described in the Online help of SIPLACE Pro
SIPLACE Pro Features
8/8/2017 ASM Assembly Systems Page 5
1. New Concave Nozzles:
Nozzle Placement head
1204 C&P20 A,C&P20 M
4204 C&P20 P, C&P20 M2
2204 CPP,CPPM
2. Long Board Option up to 1525 mm SX-machine
The licensed Long Board Option (LBO) is now supported for boards up to 1525 mm.
3. New feeder:
SIPLACE JTF-ML2 tray feeder supported the TX machine with two different cassette types. 14 levels
(supporting 7/7 cassettes) or 18 levels (supporting 9/9 cassettes). The cassette variants cannot be combined
with each other!
4. Support CPP M head on TX micron (only 20µm) and CA V2 machine
SIPLACE Pro 14.1
ASM Printer programming
8/8/2017 ASM Assembly Systems Page 6
ASM Printer Programming extends the existing SIPLACE Pro programming system by adding functionality for
editing print process data for DEK printing systems. The SIPLACE Pro programming system allows preparing,
optimizing and downloading placement and printing programs. ASM Printer Programming can be ordered
separately.
License:
DEK SIPLACE Pro – Machine Connection (Single- / Floating- license)
DEK ASM Traceability – Machine Connection (Single- / Floating- license)
Workflow oriented Editor in ASM Studio for complete offline printer program creation.
Central SIPLACE Pro database for print&place programs with shared objects for better process control and
data change management over all products.
Import of existing .pr1 Printer Programs to an existing SIPLACE Pro board side.
Program Download from SIPLACE Line Control to DEK and SIPLACE machines.
Upload of program changes and additional data into the central database.
Programming also for DEK standalone printers (no SIPLACE in line).
