User Manual HS-50 6 Vision functions
Software Version SR.501.xx 12/99 Issue US 6.6 Test Component
267
t IIt
Rectangles: 6
green: X and Y- pick-up tolerances 6
light blue: A. 2 to 4 search windows for position recognition. These are positioned
around the central lead of each row of leads.
B. 2 additional search windows for angular measurement. The two
windows are located on the same row of leads. 6
Star: 6
orange: Results of approximate search 6
Comments: 6
The star indicates the position in the direction of the leads. Depending on which measure-
ment algorithm has been selected the middle or the tip of the lead will be displayed. 6
Cross:
white: Results of position recognition -> X and Y-angles
6
brown: Residual angle tolerance for subsequent measurement steps 6
Overlay: 6
gray: Profile in the integration direction in question 6
blue: Gradients from the above profiles 6
yellow: Results from the geometric filter 6
red: Interpolation limits for position determination 6
light blue: Results of interpolation -> position 6
6
3. Corner Mode 6
See Section 6.6.4.14
on page 289 for a definition of the measuring methods. 6
This measurement method can be recognized by the windows around the entire row of leads. 6
6
Procedure: 6
Å Determine the position in the direction of the leads in the light blue window
Å Determine the position vertically to this in the dark blue window
Å Calculate the position of each lead group and thus of the component
6
6
6
6 Vision functions User Manual HS-50
6.6 Test Component Software Version SR.501.xx 12/99 Issue US
268
t IIt
Rectangles: 6
light blue: Search window for the position in the direction of the leads 6
dark blue: Search window for the position vertically to this 6
green: X and Y-tolerances 6
Star: 6
orange: Results: Location of the group in question 6
Comments: 6
Depending on which measurement algorithm was selected the middle or the end of the lead
group in the direction of the leads will be shown. 6
Cross: 6
white: Results of position recognition -> X and Y- angles 6
Overlays: 6
gray: Profile in the integration direction in question 6
blue: Gradients from the above profiles 6
yellow: Results from the geometric filter 6
red: Interpolation limits for position determination 6
light blue: Results of interpolation -> Position 6
Comments: 6
The overlay will be provided for both the light blue and the dark blue search window. 6
4. Lead mode 6
See Section 6.6.4.14
on page 289 for a definition of the measuring methods. 6
This measurement method can be recognized by 6
– either there being a window around a leads group (combined window, preset value)
– or there being a window around every single lead (separate window). You can modify the win-
dow types separate or combined window in the Measure mode Lead menu.
Procedure: 6
Each lead will be measured in a way similar to corner mode or the entire leads group will be mea-
sured. 6
6
6
6
User Manual HS-50 6 Vision functions
Software Version SR.501.xx 12/99 Issue US 6.6 Test Component
269
t IIt
Rectangles: 6
dark blue: search window around the entire leads group or around every 6
light blue: search window around the first lead in a group 6
green: X and Y-tolerances 6
Cross: 6
white: Results of position recognition X and Y-angles 6
Overlay:
gray: Profile in the integration direction in question
6
blue: Gradients from the above profiles 6
The gradients are only required and displayed for the profiles in the
direction of the leads. 6
yellow: Results from the geometric filter 6
red: Interpolation limits for position determination 6
light blue: Results of interpolation -> Position 6
Comments: 6
An overlay is available for both directions of interpolation. 6
Optical measurement of BGAs and flip-chips with the 80F
4
or 80F
5
placement machine 6
The crosshairs indicate the position of the component in the camera coordinates system. The
outline of the component will be emphasized by the use of color. 6
The measured values represent geometric component parameters such as 6
– position in the camera coordinates system
– rotation angle
– maximum offset of the balls in X and Y-directions
– factor for the quality of measurement
6
1. Grid mode 6
See Section 6.6.4.14
on page 289 for a definition of the measuring methods. 6
Grid mode works with preset pattern tolerances and is therefore to be regarded as the first mea-
surement step in the optical surveying of BGAs and flip-chips. To ascertain the approximate posi-
tion it will be adequate to measure just a few connections. 6
