Clearance underneath PCB
Standard: 25 mm
Option: Up to 40 mm
PCB conveyor height
830 ± 15 mm (standard)
952,5 ± 15 mm (option) SMEMA
Type of interface
Siemens (standard)
SMEMA (option)
Clear guide edge of component 3 mm
PCB changeover time 2.5 s
Components on each conveyor Same or different
PCB width on each conveyor Same or different
Ink spot recognition Possible
Automatic width adjustment Possible
User Manual HS-50 2 Operational Safety
Software Version SR.501.xx 12/99 Issue US 2.1 Safety instructions
51
t IIt
2 Operational Safety
2.1 Safety instructions
2.1.1 Conventions for the use of hazard symbols
This User Manual contains notes that must be observed to guarantee your personal safety and to
avoid damage to equipment. These notes are highlighted by warning triangles and are indicated
as follows according to the level of risk: 2
2
DANGER or 2
as used in this User Manual means that death, severe injury or considerable damage to equip-
ment may occur if the danger instructions are not followed. 2
2
WARNING or 2
as used in this User Manual means that death, severe injury or considerable damage to equip-
ment may occur if the warning instructions are not followed. 2
2
CAUTION or 2
as used in this User Manual means that slight injury or damage to equipment may occur if the cau-
tion instructions are not followed. 2
2
PLEASE NOTE 2
as used in this User Manual provides information on the product or indicates a part of the User
Manual that requires particular attention. 2
2.1.2 Qualified personnel
Qualified or adequately trained personnel means that these people are familiar with the setting up,
operation and maintenance of automatic placement systems and add-on devices and are suitably
qualified, e.g. 2
– have been trained, instructed or authorized to switch on and off, isolate, earth and identify elec-
trical circuits and system components in accordance with normal safety standards.
