26-3
Reference Table
Table26.2
各设备的
System File Location
及更新时需要的文件
51 UNICAD UNICAD arc
52 UniDat UniDat uni
53 VANGUARD VANGUARD drw, lib(several)
54 VCAD SIEMENS VCAD cad, dat
55 VERIBEST VERIBEST
56 VUTRAX Vutrax art
57 Zuken-Redac CadStar for DOS cdi
58 CadStar V8 for windows cpa
59 VISULA CAD Expert paf
60 CR3000 *.bsf*.mdf*.udf[*.ccf][*.wdf]
61 CR5000 *.ftf*.pcf*.pnf
Machine
File (Initial path)
Remarks
CP-40 Series
C:₩Scp₩ SCP.ini
C:₩ Scp₩ System₩ sysqXXXX.stm
C:₩ Scp₩ System₩ SyskXXXX.stm
C:₩ Scp₩ System₩ stdmech.stm
C:₩ Scp₩ System₩ stdelec.stm
C:₩ Scp₩ System₩ visset.stm
C:₩ Scp₩ System₩ viscam.stm
C:₩ Scp₩ System₩ vhead.stm
The path is the
initial path used for
MMI installation.
XXX : Machine
number
CP-45 Series
SM320
C:₩ MarkX₩ MarkX.ini
C:₩ MarkX₩ PartDB₩ Part.mdb
C:₩ MarkX₩ System₩Device.mdb
C:₩ MarkX₩ System₩ Config.db
C:₩ MarkX₩ System₩ Factory.stm
C:₩ MarkX₩ System₩ System.stm
The path is the
initial path used for
MMI i
n
stallation.
X Value CP45:3,
CP55:4, SM320:5
No Vendor CAD Type
File Extention
26-4
lvswG}]
lvswG}]
Table26.3
标准带式喂料器
(TapeFeeder)
表
CP-6x Series
SM310
C:₩ Kimchi₩ gui₩ Model₩ Machine.cfg
C:₩Kimchi₩gui₩Model₩Calibration_ComNam
e.arc
C:₩ Kimchi₩ gui₩ Model₩ Permanent.tbl
C:₩ Kimchi₩ gui₩ main₩ UserDevices.tbl
The path is the
initial path used for
MMI installation.
The 'Model'
signifies the
machine model.
CP60, CP60HP,
CP63, CP63HP,
SM310
SM400Series C:₩SmartSM₩SmartSM.ini
C:₩SmartSM₩PartDB₩ Part.mdb
C:₩SmartSM₩PartDB₩Device.mdb
C:₩SmartSM₩System₩ Config.db
C:₩SmartSM₩System₩ Factory.stm
C:₩SmartSM₩System₩ System.stm
ID TYPE LEFT(mm) RIGHT(mm)
0 TapeFeeder8mm 7.3 7.2
1 TapeFeeder12mm 15.8 14.2
2 TapeFeeder16mm 20.1 16.6
3 TapeFeeder24mm 25.45 18.4
4 TapeFeeder32mm 28.2 25.45
5 TapeFeeder44mm 34.15 30.3
6 TapeFeeder56mm 46 40
11 TapeFeeder12mmNS 7 22
12 TapeFeeder16mmNS 7 22
13 TapeFeeder24mmNS 22 16.3
14 TapeFeeder32mmNS 22 24.3
15 TapeFeeder44mmNS 22 36.3
16 TapeFeeder56mmNS 22 48.3
20 TapeFeeder8mmSM 7.25 7.25
21 TapeFeeder12mmSM 7 20
22 TapeFeeder16mmSM 7 22
23 TapeFeeder24mmSM 7 29
Machine
File (Initial path)
Remarks
Table26.4
更新支援内容
24 TapeFeeder32mmSM 7 37
25 TapeFeeder44mmSM 7 49
26 TapeFeeder56mmSM 7 61
27 TapeFeeder72mmSM 7 77
104 TapeFeeder8mm 28.2 24.45
Machine Series[Machine] Supported Items
CP40 Series
[CP40, CP33, QSA40,
QSA30, CP50, CP20, CP50 Ⅱ ]
SYS[Scp.ini], SYSVER[1], PCB[*.pcb,
*.ANC; *.opt], PCBVER[1], PARTLIB[*.lib],
PARTLIBVER[1]
CP45 Series
[CP45]
PCB[*.pcb; *opt], PCBVER[1,2,3,4],
SYS[Mark3.ini], SYSVER[1,2,3,4],
PARTLIB[Part.mdb],
PARTLIBVER[1,2,3,4]
CP55 Series
[CP55]
PCB[*.pcb; *.opt], PCBVER[1],
SYS[Mark4.ini], SYSVER[1]
CP60 Series
[CP60, CP60HP]
PCB[*.def; *.opt],
PCBVER[16,24,25,27,28,29,30]SYS[Mac
hine.cfg], SYSVER[16,24,25,27,28,29,30]
SM320 Series
[SM320]
PCB[*.pcb; *opt], PCBVER[5],
SYS[Mark5.ini], SYSVER[5],
PARTLIB[Part.mdb], PARTLIBVER[5]
SM310 Series
[SM310]
PCB[*.def; *opt], PCBVER[100],
SYS[Machine.cfg], SYSVER[100],
PARTLIB[Part.mdb], PARTLIBVER[100]
SM400 Series PCB[*.pcb; *opt],
PCBVER[5],SYS[Mark5.ini],
SYSVER[5],PARTLIB[Part.mdb],
PARTLIBVER[5]
ID TYPE LEFT(mm) RIGHT(mm)
