26-1
Chapter 26
Chapter26.
Reference Table
Table26.1 EasyOLP
支持的
CAD
数据文件
No Vendor CAD Type
File Extention
1 ACADEMI XFR program CAD style asc
2 Accel Technologies P-CAD pdf, pcb
3 Tango pcb
4 Tango-Pro pcb
5 Bosch FEX CAD *
6 Hexe CAD asy
7 CAD Ulm GmbH Ariadne pca
8 Cadence Design
Systems
Cadence Allegro pcb
9 CADENCE cad
10 CADES-G CADES-G df
11 CADNETIX Cadnetix dos
12 Cadnetix, Dazix,
Intergraph
Cadnetix edf
13 CADSTAR CADIF v.3.0 & 4.0 paf
14 CALAY CALAY yes
15 CV (Computer Vision
Theda)
Computer Vision
Autoboard
*.tl only or *.ate & *.tl file
16 DDE Supermax DDE ipl, zip
17 DeCad DeCad rg
18 DEDALE DEDALE Inputs 4 files .dat, .rou, .fgg
and .fig
26-2
lvswG}]
lvswG}]
19 DIF C-Link dif
20 DOCICA DOCICA dcc
21 DXF DXF
22 Eagle UniDAT UniDat uni
23 EDIF EDIF
24 Fabmaster Fabmaster asc,yes
25 Generic CAD GenCAD cad
26 GERBCAM GCPlace n/a
27 Hewlett-Packard HP-EGS df
28 PCDS df
29 P-Link NONE
30 IBM IBM Circuit Board
Design System
plk
31 UNICAD arc
32 INTEGRA Integra txf
33 INTERGRAPH CAD eif
34 Mentor Graphics Mentor Boardstation neu,geo,wir,net,com or *.vss
35 Mentor Expedition hkp
36 ODB++ Valor ODB++ odb
37 Or CAD OrCAD +386 for DOS asc
38 OrCADWin min, mod
39 PADS Software Inc. PADS asc, pad
40 Prisma Calay V4 pcb
41 CAD cxf
42 Protel Technology Protel2. pcb
43 Protel3.0 pcb
44 Protel3.5 pcb
45 REDAC REDAC paf
46 SCI-Cards CII txt
47 SCI-Cards rea, fab
48 Sharp Sharp inf
49 TOPCAD TOPCAD inf
50 ULTIBOARD Ultiboard ddf
No Vendor CAD Type
File Extention
