SettingUPSwhenexchangingharddisk
WKGB-10103-02
Setting UPS when exchanging
hard disk
9/14
4. Click “ ” to open
the link. Make a double click on
“ ”. USB
window
appears.
5. Click “ ” tab to show Port
Setting window.
SettingUPSwhenexchangingharddisk
WKGB-10103-02
Setting UPS when exchanging
hard disk
10/14
6. Click Advanced. Advanced Settings
for COM8 appears.
7. Select “ ” from list box of COM
Port Number. Click OK button.
COM No. change has been completed.
Close all windows.
SettingUPSwhenexchangingharddisk
WKGB-10103-02
Setting UPS when exchanging
hard disk
11/14
[UPSre-setting]
This work should be done on the machine
front and rear separately.
1. Make a double click “Power Options”.
window
appears.
2. Click UPS tab. The indication has
been switched UPS tab indication.
3. Click Select button.
window appears.
