JGGB-10101-01 Jig List 23.1mm 22.9mm 6.0 mm 5.0 mm

100%1 / 712
Jig List
SHEET
4/12
No. Jig name / Parts No. Outside appearance
Qty skrameR sesU
17 Phase adjusting jig
A-1433-195-A
1
Phase adjustment for nozzle Phase adjusting jig (1): 3-280-810-01
Phase adjusting jig (2): 3-280-811-01
2-C3x14 : 4-706-724-04
18 RT origin jig
3-280-796-01
1
RT axis origin position setup
19 RT Axis belt tension Jig (B) KIT
A-1433-200-A
1
Adjustment of RT axis belt tension RT axis belt tension jig: 3-280-798-01
C4x14 (SUS): 4-706-725-03
C4x10: 4-706-725-11
20 RN Axis belt tension Jig
A-1433-201-A
1
Adjustment of RN axis belt tension
21 Tension block Jig
3-212-839-01
1
Adjustment of FF/FR axis belt tension 3-C3x12: 4-706-724-03
22
H Axis sensor adjusting Jig (1)
A-1433-198-A
1
Adjustment of H Axis Upper End OT
Sensor (H-CCW)
Adjustment of H Axis Lower End OT
Sensor (H-CW)
H shaft OT tool (1) :3-280-800-01
2-C3x20 :7-683-410-04
2-N3 :7-684-013-08
4-C4x12 (SUS): 4-706-725-12
RN axis
belt tension jig B: 3-280-799-01
JGGB-10101-01
Jig List
23.1mm
22.9mm
6.0 mm
5.0 mm
JGGB-10101-01
Jig List
