WKGB-10101-01
Installing System Software
[Procedure]
1
1.
Click the button on the left up-
per of the screen.
USER LEVEL screen is displayed.
2.
Click the SERVICE button.
A cursor appears on a PASSWORD entry space.
3.
Enter the password and click the Set
button.
The screen returns to HI screen and respective
menu buttons of DATA EDIT, M/C SETUP,
SERVICE appear on the right of the screen.
2
1.
Click in an order of SERVICE menu
Explorer button.
Explorer screen is displayed.
WKGB-10101-01
Installing System Software
3
This working is a risk measure when install is
failed. Delete the shortcut in the moving des-
tination after version up.
1.
Move the “AutoStarter” file to the
other folder which cannot be rewritten
by the installer from the C:¥Document
andSetting¥asm¥StartMenu
¥Programs¥startup in the front PC.
2.
Move the “AutoStarter” file to the
other folder which cannot be rewritten
by the installer from the C:¥Document
andSetting¥asm¥StartMenu
¥Programs¥startup in the rear PC.
4
1.
Close the explorer window.
2.
Press the power off switch.
Shutting down of the system starts and the power
is automatically shut off.
3.
Press the power on switch.
OnlyWindowsscreenisstarted.
If the HI screen, soft key board start, camera im-
age is not moved. Move the “AutoStarter” file to
the other folder to restart the unit.
