7. Preparations and installation

YSM20R (SESMK18400-00) v2.001

7. Preparations and installation

When the customer arranges a transportation company, be sure to thoroughly understand the

responsible area (conditions) and make the judgement.

See section "7.1" to "7.1.5", Responsible area when YAMAHA arranges the transportation company.

See section "7.2", Responsible area when the distributor or customer arranges the transportation company.

7.1

Responsible area when YAMAHA arranges the transportation company.

The transportation company designated by YAMAHA transports the product to the factory site designated by

the customer.

7.1.1 Unloading the product

To unload the product, the transportation company designated by YAMAHA unloads the product using heavy

machines, such as forklift, crane, and car gondola prepared by the customer.

If the customer is difficult to prepare heavy machines, contact YAMAHA at least one week before the

delivery date.

7.1.2 Transportation within factory site

To transport the product within the customer’s factory site, YAMAHA or the transportation company

designated by YAMAHA transports the product to the installation place at YAMAHA’s own risk. If the

customer unloads and transports the product for some reason, this shall be conducted at the customer’s own

risk.

7.1.3 Securing a delivery route

A delivery route necessary to transport the product is secured. In particular, securing of the opening width,

elimination of stepped portions, securing of the installation place, and relocation of other equipment are

conducted at the customer’s own risk. For details about the width of the opening, see "11. Major

specifications", 11.1 "Outline dimensions" described later.

7.1.4 Dew condensation prevention

To transport the product from a cold environment (about 10°C or less) to a temperature regulated

environment, such as clean room (about 20°C or more), it is necessary to install the product while gradually

balancing the product temperature so as to prevent dew condensation.

In this case, a temporary placing space suitable for the temperature balancing work needs to be secured.

However, when a truck with the temperature regulation function is used, this temperature balancing work is

not needed. When the customer requests this type of truck, YAMAHA will arrange it.

7.1.5 Collection of transportation tools and gears

After the transportation has been completed, the transportation company designated by YAMAHA collects

the waste packing materials, hand lifters, and curing materials.

On the delivery date, the transportation company’s staffs wait until completion of the production line startup

work (waiting at local site until 16:00).

7. Preparations and installation

YSM20R (SESMK18400-00) v2.001

7.2

Responsible area when the distributor or customer arranges the transportation company.

The product is delivered to the customer at the shipping place of YAMAHA’s factory.

The transportation work from loading the product onto the truck to delivery at the local installation place is

the responsible area of the company that arranges the transportation company.

* The quantity check of the accessories shall be conducted before loading the product onto the truck

(when both parties’ responsible personnel attend).

YAMAHA shall not be held responsible for missing or damaged accessory during transportation.

* When suspending the machine by a crane, etc., always use a gondola.

(Attaching suspension wires/belts directly to the machine could cause machine damage.)

7.3 Preparations for power source and air supply source

The customer shall complete the air supply source and power source construction work before the delivery

work. The customer connects the air supply source and power source to the product at the customer’s own

risk. For details, see section 11. "Main Specs.".

7.4 Securing environmental conditions

For details about conditions required for the product installation environment, see "11. Major

specifications" described later. The customer needs to secure various environmental conditions before the

delivery work.

* There are various conditions, such as temperature, humidity, altitude, atmosphere, floor conditions,

ambient noise, ambient illumination, immunity (electro magnetic noise resistance), and emission

(electro magnetic noise emission).

7. Preparations and installation

YSM20R (SESMK18400-00) v2.001

7.5 Network

For operation of the product connected to the network, it is preconditioned that the product is operated in the

closed network environment that consists of only the product and offline PC prepared by the customer. When

connecting the product to the customer’s in-factory or an external network, the customer shall be held

responsible for such connection work.

YAMAHA shall not be held responsible for any defect arising from the network setting or network

connection if the product is connected to a network other than that consisting of only the product and offline

PC.

7.6 Anti-virus measures

The product uses embedded Microsoft Windows dedicated to industrial machines. On the other hand, it is

already known that there are many computer viruses that attempt invading Windows systems. From this

background, YAMAHA takes the following measures for the product.

According to the reasons shown below, YAMAHA does not take any anti-virus measures.

-1- Protection of system area by Write Filter

The system data of Windows is stored into an area protected by a function called "Write Filter". Even if a computer virus invades

and writes the system data, this data is not saved and the system data is restored to that before computer virus infection when the

power is restarted. (This does not function if the Write Filter function is set disabled,.)

-2- Insensitivity to computer virus infection by originally developed data format (non-sensitized)

Normally, the computer virus infects a general format data file. So, it is thought that the infectivity becomes extremely low for

YAMAHA’s original data that is used for the product. Even if the data is infected, the data can be restored by reinstalling the

application programs and backup data.

-3- Virus check before shipment

The virus check of the product is performed in YAMAHA’s shipping inspection. When the virus infection is not detected and the

product is considered as correct, the "Checked" label is affixed to the USB port.

-4- Reminder not to use USB flash memory with computer virus infection risk

A virus-checked dedicated USB flash memory for data backup is supplied with the product. A generally available USB flash

memory, the virus infection of which has not been checked, shall not be used.

-5- Recommendations for operation in local network

YAMAHA warrants only the operation in the "closed network" that consists of the product and offline PC prepared by the customer.

This prevents virus infection unless the product is connected to the customer’s office LAN or an external internet.

When the customer connects the product to the office LAN at the customer’s own risk, it is recommended to take anti-virus

measures, such as installation of two LAN cards into offline PC and separation of the network system using different IP addresses,

installation of generally available anti-virus software and Microsoft’s patch programs, or stopping of Computer-Browser service.

-6- Correction patch programs disclosed by Microsoft do not apply to the product.

Since the product uses embedded Microsoft Windows dedicated to industrial machines, patch programs intended for general PC OS

that are disclosed by Microsoft do not apply to this product. Note that these patch programs can be installed into the customer’s

offline PC.

-7- Software other than that specified (application or system software) cannot be installed.

Software specified for the target product is only OS (operating system) that is a basic program for the machine and application

program that provides mounter functions. Any software other than that specified cannot be installed into the product. YAMAHA

shall not be held responsible for any defect arising from installation of other software.
