16
7. Preparations and installation
YSM20R (SESMK18400-00) v2.001
7.2
Responsible area when the distributor or customer arranges the transportation company.
The product is delivered to the customer at the shipping place of YAMAHA’s factory.
The transportation work from loading the product onto the truck to delivery at the local installation place is
the responsible area of the company that arranges the transportation company.
* The quantity check of the accessories shall be conducted before loading the product onto the truck
(when both parties’ responsible personnel attend).
YAMAHA shall not be held responsible for missing or damaged accessory during transportation.
* When suspending the machine by a crane, etc., always use a gondola.
(Attaching suspension wires/belts directly to the machine could cause machine damage.)
7.3 Preparations for power source and air supply source
The customer shall complete the air supply source and power source construction work before the delivery
work. The customer connects the air supply source and power source to the product at the customer’s own
risk. For details, see section 11. "Main Specs.".
7.4 Securing environmental conditions
For details about conditions required for the product installation environment, see "11. Major
specifications" described later. The customer needs to secure various environmental conditions before the
delivery work.
* There are various conditions, such as temperature, humidity, altitude, atmosphere, floor conditions,
ambient noise, ambient illumination, immunity (electro magnetic noise resistance), and emission
(electro magnetic noise emission).
17
7. Preparations and installation
YSM20R (SESMK18400-00) v2.001
7.5 Network
For operation of the product connected to the network, it is preconditioned that the product is operated in the
closed network environment that consists of only the product and offline PC prepared by the customer. When
connecting the product to the customer’s in-factory or an external network, the customer shall be held
responsible for such connection work.
YAMAHA shall not be held responsible for any defect arising from the network setting or network
connection if the product is connected to a network other than that consisting of only the product and offline
PC.
7.6 Anti-virus measures
The product uses embedded Microsoft Windows dedicated to industrial machines. On the other hand, it is
already known that there are many computer viruses that attempt invading Windows systems. From this
background, YAMAHA takes the following measures for the product.
According to the reasons shown below, YAMAHA does not take any anti-virus measures.
-1- Protection of system area by Write Filter
The system data of Windows is stored into an area protected by a function called "Write Filter". Even if a computer virus invades
and writes the system data, this data is not saved and the system data is restored to that before computer virus infection when the
power is restarted. (This does not function if the Write Filter function is set disabled,.)
-2- Insensitivity to computer virus infection by originally developed data format (non-sensitized)
Normally, the computer virus infects a general format data file. So, it is thought that the infectivity becomes extremely low for
YAMAHA’s original data that is used for the product. Even if the data is infected, the data can be restored by reinstalling the
application programs and backup data.
-3- Virus check before shipment
The virus check of the product is performed in YAMAHA’s shipping inspection. When the virus infection is not detected and the
product is considered as correct, the "Checked" label is affixed to the USB port.
-4- Reminder not to use USB flash memory with computer virus infection risk
A virus-checked dedicated USB flash memory for data backup is supplied with the product. A generally available USB flash
memory, the virus infection of which has not been checked, shall not be used.
-5- Recommendations for operation in local network
YAMAHA warrants only the operation in the "closed network" that consists of the product and offline PC prepared by the customer.
This prevents virus infection unless the product is connected to the customer’s office LAN or an external internet.
When the customer connects the product to the office LAN at the customer’s own risk, it is recommended to take anti-virus
measures, such as installation of two LAN cards into offline PC and separation of the network system using different IP addresses,
installation of generally available anti-virus software and Microsoft’s patch programs, or stopping of Computer-Browser service.
-6- Correction patch programs disclosed by Microsoft do not apply to the product.
Since the product uses embedded Microsoft Windows dedicated to industrial machines, patch programs intended for general PC OS
that are disclosed by Microsoft do not apply to this product. Note that these patch programs can be installed into the customer’s
offline PC.
-7- Software other than that specified (application or system software) cannot be installed.
Software specified for the target product is only OS (operating system) that is a basic program for the machine and application
program that provides mounter functions. Any software other than that specified cannot be installed into the product. YAMAHA
shall not be held responsible for any defect arising from installation of other software.
18
8. Inspection and acceptance
YSM20R (SESMK18400-00) v2.001
8. Inspection and acceptance
8.1 Inspection before shipment
The product is inspected with the customer attended at YAMAHA’s factory before shipment. After this
attendance inspection is considered as accepted, the product is shipped to the factory site designated by the
customer.
The following describes the inspection items, inspection methods, and acceptance criteria.
-1- Inspection items
Units and quantities making up this equipment and other conditions stated in the delivery specification shall
be satisfied.
-2- Inspection methods
The mounting test is performed using the materials under the conditions described below.
Board for attendance inspection YAMAHA test boards
Customer boards.
* If customer boards are to be used,
please send the boards and
coordinate data (and the
components as well, in some
cases) to Yamaha at least 2 weeks
prior to the inspection date.
Component securing method Two-sided adhesive tape.
Witnessed inspection components
As a general rule, the following components
shall be used for the witnessed inspection:
Standard Yamaha square components (0603,
1005, 1608, 2012, 3216; "mm" sizes), and
mini-mold TR & SOP components.
In some cases, dummy SOP and dummy QFP
components may also be used.
* Unless otherwise specified, Yamaha shall
prepare the above components.
* Separate consultations shall be
required if the customer's
components or special components
are to be used.
Number of mountings Total of 2,500 or more components.
Acceptance criteria
No component mounting errors shall occur in
the above inspection process (including
recovery operations).
* The components to be mounted in the witnessed
inspection may be changed depending on the
device specifications (cameras, nozzles, feeders,
etc.).
* When the 0402 square chip component ("mm"
size) is included in the inspections, separate
consultation is required regarding the component
supply method and evaluation standard.
8.2 Inspection after installation
After "8.1 Inspection before shipment" has been considered as accepted, the product is shipped to the factory
site designated by the customer and the delivery work is conducted. After the installation and adjustment
work have been completed at the installation site, the inspection with the same contents as described in "8.1
Inspection before shipment" is performed. This inspection is called "Inspection after installation".
8.3 Acceptance
In the same manner as "8.1 Inspection before shipment" described above, when the results of "8.2 Inspection
after installation" satisfy the acceptance criteria, the product is considered as accepted.
