7. Preparations and installation

YSM20R (SESMK18400-00) v2.001

7.5 Network

For operation of the product connected to the network, it is preconditioned that the product is operated in the

closed network environment that consists of only the product and offline PC prepared by the customer. When

connecting the product to the customer’s in-factory or an external network, the customer shall be held

responsible for such connection work.

YAMAHA shall not be held responsible for any defect arising from the network setting or network

connection if the product is connected to a network other than that consisting of only the product and offline

PC.

7.6 Anti-virus measures

The product uses embedded Microsoft Windows dedicated to industrial machines. On the other hand, it is

already known that there are many computer viruses that attempt invading Windows systems. From this

background, YAMAHA takes the following measures for the product.

According to the reasons shown below, YAMAHA does not take any anti-virus measures.

-1- Protection of system area by Write Filter

The system data of Windows is stored into an area protected by a function called "Write Filter". Even if a computer virus invades

and writes the system data, this data is not saved and the system data is restored to that before computer virus infection when the

power is restarted. (This does not function if the Write Filter function is set disabled,.)

-2- Insensitivity to computer virus infection by originally developed data format (non-sensitized)

Normally, the computer virus infects a general format data file. So, it is thought that the infectivity becomes extremely low for

YAMAHA’s original data that is used for the product. Even if the data is infected, the data can be restored by reinstalling the

application programs and backup data.

-3- Virus check before shipment

The virus check of the product is performed in YAMAHA’s shipping inspection. When the virus infection is not detected and the

product is considered as correct, the "Checked" label is affixed to the USB port.

-4- Reminder not to use USB flash memory with computer virus infection risk

A virus-checked dedicated USB flash memory for data backup is supplied with the product. A generally available USB flash

memory, the virus infection of which has not been checked, shall not be used.

-5- Recommendations for operation in local network

YAMAHA warrants only the operation in the "closed network" that consists of the product and offline PC prepared by the customer.

This prevents virus infection unless the product is connected to the customer’s office LAN or an external internet.

When the customer connects the product to the office LAN at the customer’s own risk, it is recommended to take anti-virus

measures, such as installation of two LAN cards into offline PC and separation of the network system using different IP addresses,

installation of generally available anti-virus software and Microsoft’s patch programs, or stopping of Computer-Browser service.

-6- Correction patch programs disclosed by Microsoft do not apply to the product.

Since the product uses embedded Microsoft Windows dedicated to industrial machines, patch programs intended for general PC OS

that are disclosed by Microsoft do not apply to this product. Note that these patch programs can be installed into the customer’s

offline PC.

-7- Software other than that specified (application or system software) cannot be installed.

Software specified for the target product is only OS (operating system) that is a basic program for the machine and application

program that provides mounter functions. Any software other than that specified cannot be installed into the product. YAMAHA

shall not be held responsible for any defect arising from installation of other software.

8. Inspection and acceptance

YSM20R (SESMK18400-00) v2.001

8. Inspection and acceptance

8.1 Inspection before shipment

The product is inspected with the customer attended at YAMAHA’s factory before shipment. After this

attendance inspection is considered as accepted, the product is shipped to the factory site designated by the

customer.

The following describes the inspection items, inspection methods, and acceptance criteria.

-1- Inspection items

Units and quantities making up this equipment and other conditions stated in the delivery specification shall

be satisfied.

-2- Inspection methods

The mounting test is performed using the materials under the conditions described below.

Board for attendance inspection YAMAHA test boards

Customer boards.

* If customer boards are to be used,

please send the boards and

coordinate data (and the

components as well, in some

cases) to Yamaha at least 2 weeks

prior to the inspection date.

Component securing method Two-sided adhesive tape.

Witnessed inspection components

As a general rule, the following components

shall be used for the witnessed inspection:

Standard Yamaha square components (0603,

1005, 1608, 2012, 3216; "mm" sizes), and

mini-mold TR & SOP components.

In some cases, dummy SOP and dummy QFP

components may also be used.

* Unless otherwise specified, Yamaha shall

prepare the above components.

* Separate consultations shall be

required if the customer's

components or special components

are to be used.

Number of mountings Total of 2,500 or more components.

Acceptance criteria

No component mounting errors shall occur in

the above inspection process (including

recovery operations).

* The components to be mounted in the witnessed

inspection may be changed depending on the

device specifications (cameras, nozzles, feeders,

etc.).

* When the 0402 square chip component ("mm"

size) is included in the inspections, separate

consultation is required regarding the component

supply method and evaluation standard.

8.2 Inspection after installation

After "8.1 Inspection before shipment" has been considered as accepted, the product is shipped to the factory

site designated by the customer and the delivery work is conducted. After the installation and adjustment

work have been completed at the installation site, the inspection with the same contents as described in "8.1

Inspection before shipment" is performed. This inspection is called "Inspection after installation".

8.3 Acceptance

In the same manner as "8.1 Inspection before shipment" described above, when the results of "8.2 Inspection

after installation" satisfy the acceptance criteria, the product is considered as accepted.

9. Warranty

YSM20R (SESMK18400-00) v2.001

9. Warranty

9.1 Warranty period

The warranty period of the product ends when any of the following applies (whichever comes first).

-1- One year elapses from the time of installation.

-2- 18 months elapse from the time of shipment from YAMAHA’s factory

-3- Total operation hours reach 5,000 hours.

9.2 Warranty coverage and contents

The following describes the warranty coverage and contents.

-1- The warranty coverage of the product is the portions that are described as normal contents of this

delivery specification, that is, the contents stated in "1. Machine configuration" and "3. Arrangements".

The warranty coverage does not include the contents of "2. Custom-order specifications and specific

items". The warranty coverage of the custom-order specifications and specific items shall be discussed

separately.

-2- If any defect or trouble due to YAMAHA’s design or workmanship is found in machine unit, software,

or genuine part, that has been delivered to the customer’s factory with YAMAHA's Scope of

responsibility and considered as accepted, during the warranty period, YAMAHA shall repair or replace

the defective unit, software, or genuine part free of charge.

-3- YAMAHA shall not accept the customer’s compensations for any incidental or consequential losses,

losses due to absence from work, faulty product production, cost losses, and sales opportunity losses

(lost earnings).

-4- If the customer receives a claim regarding compensations for losses due to infringement on patent right,

intellectual property right, or other right resulting from use of products that the customer has

manufactured using this equipment, software, and genuine parts from a third party, YAMAHA shall not

accept the customer’s compensations.

-5- The contents described in this specification explain the specifications of this equipment.

YAMAHA does not warrant or permit the operation of a third person’s patent right, intellectual property

right or other rights.
