10. Safety
YSM20R (SESMK18400-00) v2.001
10. Safety
10.1 Overview
This equipment is an industrial machine dedicated to indoor use only.
To ensure that the machine you purchased is used safely and correctly, always comply with the instructions
and rules in separate manual regarding safety.
To maintain the safety of the operator or person working with this machine, it is essential that it (including
external parts feeders) be installed correctly in compliance with the safety standards and onditions of that
country.
Complying with the safety regulations and laws of that country is the responsibility of the customer who
purchased this machine. The supervisor of this machine must take responsibility to ensure all measures have
been taken for machine safety.
10.2 Ensuring the safety
The following describes typical safety instructions, such as warnings and cautions to ensure the safety. For
details, check the manuals.
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
These are points most essential for protecting the safety of the machine operator, inspector and service
personnel.
Pictorial symbol put down with warning messages
== Examples of warning massages ==
• Never allow any part of your body (hand or head, etc.) to enter within the machine movement range
during operation.
• Safety devices (safety interlocks) that stop machine operation should always be in good operating
condition.
• Always shut off the power and air supply before replacing parts or performing repairs.
• During teaching or when making machine adjustments, always keep alert so that you can stop the
machine whenever needed.
CAUTION
Indicates a potentially hazardous situation which, if not avoided, may result in minor injury, or material loss
or damage to the machine. These points are important for protecting the safety of the machine and data, etc.
Pictorial symbol put down with caution messages
== Examples of caution messages ==
• The work person operating the machine must have been trained in correct machine operation and safety.
• If the component supply unit is installed without stopping the machine, this may cause a part of your
body to be entangled in the machine.
22
10. Safety
YSM20R (SESMK18400-00) v2.001
10.3 Warning labels
To use the YAMAHA machines safely and correctly, warning labels are attached to the machine body and
peripheral equipment. Check that the information on each warning label is clearly legible and comply with
the instructions.
The following 3 types of marks are used on warning labels. Each mark has its own meaning and is typically
used with a pictogram to emphasize the message.
Usage examples
Prohibition mark Instruction mark
WARNING WARNINGWARNING
Mark and pictogram
Marks and examples used with pictogram
Definition Shape/Color
Meaning of the above
examples
Warning
Indicates a hazard, how to
avoid the hazard, and potential
consequences of ignoring the
warning.
Yellow triangle with black
border. Pictogram is black on
yellow.
Risk of electrical shock
Prohibition
Indicates a prohibited action to
avoid the potential hazard.
Red circle with slash. Pictogram
is black and located behind
slash.
Do not modify or disassemble
safety cover switch.
Instruction
Indicated an action that must
be taken to avoid the potential
hazard.
Blue circle. Pictogram is white
on blue.
Read the manual to understand
procedure bef
ore starting
operation.
Warning mark
10.4 Warnings regarding strong magnetic fields
Some machines contain parts generating strong magnetic fields which may cause death, bodily injury, or
device malfunction. Always comply with the following instructions.
* Persons wearing a pacemakers and/or hearing aids or other electronic medical devices should stay
away from the head at all times.
* Persons with implants of magnetic metal should stay away from the head at all times.
* Keep all iron and steel items such as tools and screws, etc., away from strong magnetic field warning
areas.
* Keep items such as magnetic cards, etc., which could be damaged by magnetic forces away from the
head.
Ferromagnetic field warning label
23
10. Safety
YSM20R (SESMK18400-00) v2.001
10.5 Keeping hands away from moving parts
During use of this machine, the customer’s equipment and operating conditions might allow the operator’s
hands to come into contact with moving parts.
Use the following safety measure options to avoid possible danger where openings or gaps are found on the
machine.
Dummy feeder
Use dummy feeders as safety measures to fill a gap between tape feeders. Install dummy feeders on the
feeder plate the same way as normal feeders in order to prevent hands from entering.
One-stop cover (for machines designed for use with feeder exchange carriage, excluding YSM40/YSM40R)
If not using a feeder exchange carriage in the machine that is to be used with feeder exchange carriages,
install a one-stop cover in the position where a feeder exchange carriage is to be installed.
Muzzle plate
Use these plates as a safety measure for the board conveyor entrance and exit openings.
Each plate is movable, so adjust the mounting position to match the boards to be produced.
10.6 Warnings regarding tape cutter
Operating the built-in tape cutter in an incorrect manner can be extremely hazardous.
Always observe the following rules:
* Never supply electrical power and air to the machine while the covers for the tape cutter are removed.
* Tape cutter maintenance tasks must be performed by YAMAHA service personnel.
Tape cutter warning label
