11. Specications

YSM20R (SESMK18400-00) v2.001

11.14 Restrictions on mounting components on boards

Component height

(For details about mountable

component height, see below.)

3.5mm

Max.30mm

W direction

L direction

Rear

Front

5.5mm

3.5mm

5.5mm

：

19mm

(Dual-stage conveyor)

17.5mm

(Single lane)

Upper side of board: See "11.5.1 Height of mountable components".

* No components can be placed in areas of 3mm from both ends in the board transport direction.

See also the figure in "11.8 Unmountable areas on board".

Back side of board: 30mm or less

* No components can be placed in areas of 3.5mm from both ends in the board transport direction.

No components can be mounted in the shaded areas in the above figure.

11.15 Board transport speed

50 to 500mm / sec (Speed setting can be changed.)

* The transport speed may vary depending on the board weight.

12. General specications

YSM20R (SESMK18400-00) v2.001

12. General specifications

12.1 Safety design

This machine conforms to the EU Machinery Directive 2006/42/EC and EMC Directive 2014/30/EU (CE

marking). However, this machine does not bear CE marking if a special order item with custom

specifications is installed. See "10.7 CE marking" for details.

12.2 Emergency stop and error detection systems

To ensure the safety, this machine has an emergency stop system and error detection system shown in the

table below.

No. System area and item

Registration

name

Built-in

Remarks

YSM20R-2 YSM20R-1

Emergency stop on front

operation console

SB31

◎ ◎

Push-lock, turn-reset button

Emergency stop on rear

operation console

SB31

◎ ◎

Push-lock, turn-reset button

03 Front safety cover SQ101

◎ ◎

Mechanical switch with key

04 Rear safety cover SQ102

◎ ◎

Mechanical switch with key

05 Front left 32-feeder bank (*1) -

△ △

Feeder exchange carriage and ATS

docking check

06 Front right 32-feeder bank (*1) -

△ △

Feeder exchange carriage docking

check

07 Rear right 32-feeder bank (*1) -

△ △

Feeder exchange carriage and ATS

docking check

08 Rear left 32-feeder bank (*1) -

△ △

Feeder exchange carriage docking

check

09 Servo 1 group of control box -

◎

YA1, YA2, UA, PUA axis error detection

10 Servo 2 group of control box -

◎ ◎

YB1, YB2, UB, PUB axis error detection

11 Servo 3 group of control box -

◎ ◎

XA, SCA, XB, SCB axis error detection

12 Servo 4 group of control box -

△ △

AZA and AZB axis error detection, ATS

option

13 Remote servo 1 of control box -

◎

ZA1-10, RA1, RA2 (HM head) / ZA1-5,

RA1-5 (FM head) axis error detection

14 Remote servo 2 of control box -

◎ ◎

ZB1-10, RB1, RA2 (HM head) / ZB1-5,

RB1-5 (FM head) axis error detection

15 Remote servo 3 of control box -

◎ ◎

CV1-4, W1-4, ATA, ATB, AHA, AHB axis

error detection

16 Axis interference detection SQ027

◎

YA and YB axis interference detection

* Meaning of "Built-in" mark ==>

◎

: Provided,

△

: Selectable as option

"Registration name" is the name described in the control wiring diagram for maintenance support (YAMAHA

Support & Service Website).

* (*1) Not available when a fixed feeder plate is used.

* Other hardware-related detection errors include temperature errors, fan stop, and power supply errors.

For details, see the user’s manuals.

12. General specications

YSM20R (SESMK18400-00) v2.001

12.3 Pause (interlock) system and error detection system

To protect the machine or continue the operation, this machine as a pause system and error stop system

shown in the table below.

No. System area and item

Registration

name

Built-in

Remarks

YSM20R-2 YSM20R-1

01 Front left feeder group SQ131

◎ ◎

Check for feeder setup

02 Front right feeder group (*1) SQ132

△ △

Check for feeder setup

03 Rear right feeder group SQ133

◎ ◎

Check for feeder setup

04 Rear left feeder group (*1) SQ134

△ △

Check for feeder setup

05 Front head air pressure SP11

◎

- Air pressure drop

06 Rear head air pressure SP12

◎ ◎

Air pressure drop

07 Front-side chip dump box SQ196

◎ ◎

With or without chip dump box

08 Rear-side chip dump box SQ197

◎

- With or without chip dump box

09 Front-side shaft blow SQ191

◎ ◎

With or without nozzle

10 Rear-side shaft blow SQ192

◎

- With or without nozzle

* Meaning of "Built-in" mark ==>

◎

: Provided,

△

: Selectable as option, No mark : not available

* "Registration name" is the name described in the control wiring diagram for maintenance support

(YAMAHA Support & Service Website).

* (*1) Not available when a fixed feeder plate is used.

* Other hardware-related detection errors include temperature errors, fan stop, and power supply errors.

For details, see the user’s manuals.

12.4 Machine status indication

The status of this machine is displayed using the signal tower as described in the table below.

According to the shipment destination or the customer’s equipment specifications, the desired lighting

pattern can be selected using Lighting color pattern in "1. Machine configuration".

No. Machine status

Lighting

portion

Lighting color

General

Europe

YAMAHA

standard

01 Emergency stop status, safety cover open, CPU error, etc. Upper portion White Red

02 Pickup error, transport error, component supply run-out, etc. Middle portion Blue Yellow

03 Automatic operation is running. Lower portion Green Green
