47
12. General specications
YSM20R (SESMK18400-00) v2.001
12.11 Feeder lane configuration
For an overall feeder lane layout, refer to the figure and table stated in "12.10 Feeder bank configuration".
The feeders that can be used by each head may vary depending on the relationship between the head shape
and X-axis movable range and the feeder bank layout.
The feeder set numbers that can be used by each head of the machine are as follows:
HM head Supply form Head
Feeder set number
Table A Table B
YSM20R-2
32-feeder exchange carriage
1 1 to 55 101 to 155
2 1 to 56 101 to 156
3 1 to 57 101 to 157
4 1 to 58 101 to 158
5 1 to 59 101 to 159
6 2 to 60 102 to 160
7 3 to 61 103 to 161
8 4 to 62 104 to 162
9 5 to 63 105 to 163
10 6 to 64 106 to 164
70-feeder fixed plate
1 1 to 61 101 to 161
2 1 to 62 101 to 162
3 1 to 63 101 to 163
4 1 to 64 101 to 164
5 1 to 65 101 to 165
6 2 to 66 102 to 166
7 3 to 67 103 to 167
8 4 to 68 104 to 168
9 5 to 69 105 to 169
10 6 to 70 106 to 170
YSM20R-1
32-feeder exchange carriage
1 6 to 64 101 to 155
2 5 to 63 101 to 156
3 4 to 62 101 to 157
4 3 to 61 101 to 158
5 2 to 60 101 to 159
6 1 to 59 102 to 160
7 1 to 58 103 to 161
8 1 to 57 104 to 162
9 1 to 56 105 to 163
10 1 to 55 106 to 164
70-feeder fixed plate
1 6 to 70 101 to 161
2 5 to 69 101 to 162
3 4 to 68 101 to 163
4 3 to 67 101 to 164
5 2 to 66 101 to 165
6 1 to 65 102 to 166
7 1 to 64 103 to 167
8 1 to 63 104 to 168
9 1 to 62 105 to 169
10 1 to 61 106 to 170
48
12. General specications
YSM20R (SESMK18400-00) v2.001
FM head Supply form Head
Feeder set number
Table A Table B
YSM20R-2
32-feeder exchange carriage
1 1 to 55 101 to 155
2 1 to 57 101 to 157
3 2 to 59 102 to 159
4 4 to 61 104 to 161
5 6 to 63 106 to 163
70-feeder fixed plate
1 1 to 61 101 to 161
2 1 to 63 101 to 163
3 2 to 65 102 to 165
4 4 to 67 104 to 167
5 6 to 69 106 to 169
YSM20R-1
32-feeder exchange carriage
1 6 to 63 101 to 155
2 4 to 61 101 to 157
3 2 to 59 102 to 159
4 1 to 57 104 to 161
5 1 to 55 106 to 163
70-feeder fixed plate
1 6 to 63 101 to 161
2 4 to 61 101 to 163
3 2 to 59 102 to 165
4 1 to 57 104 to 167
5 1 to 55 106 to 169
49
12. General specications
YSM20R (SESMK18400-00) v2.001
12.12 Signal specifications
12.12.1
Machine-to-machine signal specifications
(between this machine and post-process machine)
* Next Interface
According to the operating conditions, such as machine combination and signal cable selection, make
appropriate selections from the table shown below.
These specifications must match the selected settings in "12.12.2 Machine-to-machine signal specifications"
(between this machine and pre-process machine: Previous interface).
* When connecting to other company’s machine, the customer shall be held responsible for maintenance of
the functions related to other company’s machine.
Selection
Next interface connector on
this machine AMP: 206043-1
(Receptacle 14 pins)
GATE signal
specifications
ADVANCED (extended)
GATE specifications
ADVANCED (extended)
GATE 2 specifications
SMEMA signal
specifications
YAMAHA YV series or
earlier (YV or earlier) and
other company’s machine
YAMAHA X series or later
(X / Xg / YG / YS)
YAMAHA YS series (YS)
or later
*1
SMEMA signal
compatible
machine
Pin
No
Class Signal name Signal name Signal name Signal name
1 DC +24V
GATE IN
(com)
Board
unloading
request signal
input from the
post-process
machine
BUSY IN
(com)
Status signal input
showing that the
post-process
machine is loading
the board.
Same as left.
SMEMA
specifications
2
PNP input
(Judged as ON when
the voltage is +24V.)
GATE IN
(input)
BUSY IN
(input)
3
Relay
contact
output
Conducted
/ Closed
when
turned ON.
Not used.
BA OUT
(output)
Status signal output
showing that this
machine is ready to
unload the board.
Same as left.
4
Relay
contact
output
Not used.
BA OUT
(output)
5
Incorrect
connection
prevention
function
application
Key plug
inserted.
Dedicated to mating
designation
(Blocked)
Dedicated to mating
designation
(Blocked)
Dedicated to mating
designation
(Blocked)
6
Dedicated to mating
designation
(Receivable)
Dedicated to mating
designation
(Receivable)
Dedicated to mating
designation
(Receivable)
7 DC 0V Not used. Not used. Not used.
8 Reserved. Reserved. Reserved. Reserved.
9
Relay
contact
output
Conducted
/ Closed
when
turned ON.
Not used.
UR OUT
(output)
Status signal output
showing that this
machine is running in
the automatic
operation mode.
Same as left
10
Relay
contact
output
Not used.
UR OUT
(output)
11 DC +24V Not used.
LR IN
(com)
Status signal input
showing that the
post-process
machine is running in
the automatic
operation mode.
Same as left
12
PNP input
(Judged as ON when
the voltage is +24V.)
Not used.
LR IN
(input)
13 DC +24V
Not used.
*2
Not used.
*2
LE IN
(com)
Signal input
showing the
board presence
status at the
standby position
of the post
process
machine
14
PNP input
(Judged as ON when
the voltage is +24V.)
Not used.
*2
Not used.
*2
LE IN
(input)
*1 : The YS / YG series mounters have already been applicable to the ADVANCED GATE 2 specifications
from the machines shipped in November, 2009. When connecting the YS / YG series mounter shipped
before this date to the line, the machine (except for YS24) needs to be modified.
*2 : This signal can be handled as the counter reset signal input.
(The signal waits for replacement of the magazine rack of the unloader.)
