13. References and details
YSM20R (SESMK18400-00) v2.001
13. References and details
13.1 Layout configuration
The layout is composed of items
①
to
⑪
shown below.
YSM20R-2 - HM - HM - R - F - DS - 2 - F64/64 - N - N - #009#BN
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪
Layout
No. Item Remarks
①
Frame beam type
YSM20R-2 : 2 beams
YSM20R-1 : 1beams
②
Head A
HM : HM head
FM : FM head
③
Head B
HM : HM head
FM : FM head
N : None
④
Conveyor entrance
R : Right
L : Left
⑤
Conveyor reference
F : Front
R : Rear
⑥
Conveyor type
DS : Dual stage
SL3 : Single lane (L360)
SL5 : Single lane (L510)
⑦
Number of multi-view
cameras
N : None
1A : A (front) side
1B : B (rear) side
2 : Front/rear
⑧
Feeder specficaitions
F64 / 64 : 32-feeder carriage x 4
F32 / 64 : 32-feeder carriage, 1 on front and 2 on rear
F64 / 32 : 32-feeder carriage, 2 on front and 1 on rear
F32 / 32 : 32-feeder carriage, 1 on front and 1 on rear
N70 / 70 : 70-feeder fixed plate on front and rear
⑨
Conveyor length
N : Standard 1374mm
E1 : Entrance extension 1559mm
E2 : Exit extension 1559mm
E3 : Both 1744mm
S : Special order
⑩
Tray Supply
N : None
CF : cATS10 (Front)
CR : cATS10 (Rear)
C2 : cATS10 (Front and Rear)
SF : sATS30 (Front)
SR : sATS30 (Rear)
S2 : sATS30 (Front and Rear)
SC : sATS30 (Front) / cATS10 (Rear)
CS : cATS10 (Front) / sATS30 (Rear)
NF : sATS30NS (Front)
NR : sATS30NS (Rear)
N2 : sATS30NS (Front and Rear)
NC : sATS30NS (Front) / cATS10 (Rear)
CN : cATS10 (Front) / sATS30NS (Rear)
SN : sATS30 (Front) / sATS30NS (Rear)
NS : sATS30NS (Front) / sATS30 (Rear)
Special order : Other than those above
⑪
Type #xxx#xx
* Rear conveyor reference is a special order item.
63
13. References and details
YSM20R (SESMK18400-00) v2.001
Layouts list (2 Beam)
Layouts No. Maximum PCB size
Conveyor
entrance
Conveyor
reference
Number of
multi
camera
Feeder bank
Composition
Conveyor
type
Conveyor
length
Tray feeder
#001
L510mm × W490mm
(Option : L810mm ×W490mm)
or
L360mm × W490mm
Right Front
None
1 : Front
1 : Rear
2 : Both
F64 / 64
Single
Lane
1,374mm (Normal)
1,559mm (Entrance
extension)
1,559mm
(Exit extension)
1,744mm (Both)
None
#002 F32 / 64 cATS10 (Front)
#003 F64 / 32 cATS10 (Rear)
#004 F32 / 32 cATS10 (Both)
#005 F32 / 64
sATS30 (Front) or
sATS30NS (Front)
#006 F64 / 32
sATS30 (Rear) or
sATS30NS (Rear)
#007 F32 / 32
sATS30 (Front) or
sATS30NS (Front) /
sATS30 (Rear) or
sATS30NS (Rear)
#008 N70 / 70 None
#00S
F32 / 32
sATS30 (Front) or
sATS30NS (Front)
/ cATS10 (Rear)
#00T
cATS10 (Front) /
sATS30 (Rear) or
sATS30NS (Rear)
#009
L810mm x W490mm
F64 / 64
Dual
Stage
None
#00A F32 / 64 cATS10 (Front)
#00B F64 / 32 cATS10 (Rear)
#00C F32 / 32 cATS10 (Both)
#00D F32 / 64
sATS30 (Front) or
sATS30NS (Front)
#00E F64 / 32
sATS30 (Rear) or
sATS30NS (Rear)
#00F F32 / 32
sATS30 (Front) or
sATS30NS (Front) /
sATS30 (Rear) or
sATS30NS (Rear)
#00G N70 / 70 None
#00U
F32 / 32
sATS30 (Front) or
sATS30NS (Front) /
cATS10 (Rear)
#00V
cATS10 (Front) /
sATS30 (Rear) or
sATS30NS (Rear)
64
13. References and details
YSM20R (SESMK18400-00) v2.001
Layouts No. Maximum PCB size
Conveyor
entrance
Conveyor
reference
Number of
multi
camera
Feeder bank
Composition
Conveyor
type
Conveyor
length
Tray feeder
#011
L510mm × W490mm
(Option : L810mm ×W490mm)
or
L360mm × W490mm
Left Front
None
1 : Front
1 : Rear
2 : Both
F64 / 64
Single
Lane
1,374mm (Normal)
1,559mm (Entrance
extension)
1,559mm
(Exit extension)
1,744mm (Both)
None
#012 F32 / 64 cATS10 (Front)
#013 F64 / 32 cATS10 (Rear)
#014 F32 / 32 cATS10 (Both)
#015 F32 / 64
sATS30 (Front) or
sATS30NS (Front)
#016 F64 / 32
sATS30 (Rear) or
sATS30NS (Rear)
#017 F32 / 32
sATS30 (Front) or
sATS30NS (Front) /
sATS30 (Rear) or
sATS30NS (Rear)
#018 N70 / 70 None
#01S
F32 / 32
sATS30 (Front) or
sATS30NS (Front) /
cATS10 (Rear)
#01T
cATS10 (Front) /
sATS30 (Rear) or
sATS30NS (Rear)
#019
L810mm x W490mm
F64 / 64
Dual
Stage
None
#01A F32 / 64 cATS10 (Front)
#01B F64 / 32 cATS10 (Rear)
#01C F32 / 32 cATS10 (Both)
#01D F32 / 64
sATS30 (Front) or
sATS30NS (Front)
#01E F64 / 32
sATS30 (Rear) or
sATS30NS (Rear)
#01F F32 / 32
sATS30 (Front) or
sATS30NS (Front) /
sATS30 (Rear) or
sATS30NS (Rear)
#01G N70 / 70 None
#01U
F32 / 32
sATS30 (Front) or
sATS30NS (Front) /
cATS10 (Rear)
#01V
cATS10 (Front) /
sATS30 (Rear) or
sATS30NS (Rear)
