69
13. References and details
YSM20R (SESMK18400-00) v2.001
　
Installation nozzle (1-beam specs.)
Item Details
Installation nozzle
* Write when no nozzle station is provided.
* According to the restrictions on operating program,
31X nozzle and 30X nozzle cannot be mixed within
one head.
* The initial setting is either 312A or 301A.
* For narrow pitch mounting, install 312A nozzles for
the number of heads. For standard pitch mounting,
install 301A nozzles for the number of heads. (When
no nozzle station is provided.)
Type Outer shape Applicable (Metric)
"Narrow-
pitch" 31X
nozzle
3110 A 0402
311A 0603
312A 1005 / 1608
313A 2012 / 3216 / 3225
314A SOP
315A QFP(□32mm or less)
318A
QFP
* HM head can be attached
only H2 / H8
317A Cylindrical components
Standard
30X
nozzle
3010A 0402
301A 0603 / 1005
302A 1608 / 2012 / 3216
303A SOP
304A QFP(□32mm or less)
307A
QFP
* HM head can be attached
only H2 / H8
306A Cylindrical components
Head
HM head
12 12 12 12 12 12 12 12 12
H1 H3 H5 H7H2 H10H8 H9H6H4
FM head
24 24 24 24
Left FID Camera
H4H2 H5H3H1
Automatic Push-up Pin Exchange System
(Matrix Type)
None (Standard)
Provided. (Option)
Standard number of push-up pins
Dual Stage 80pics (20 pics / pin stations, 4 pin stations)
Single Lane 40pics (20 pics / pin stations, 2 pin stations)
QFP recovery conveyor
230
613
87116
78
Applicable component height
HM head (Max. component height, 15 mm)
70-feeder fixed, ZS carriage, SS carriage: 15 mm or less
FM head (Max. component height, 28 mm)
70-feeder fixed, SS carriage: 28 mm or less
ZS carriage: 15 mm or less
* For combinations other than those shown above, consult your
distributor.
KLF-M9400-01X, Dump Station Assy.MU
* Counter specs. (C-specs.)
* The permissible quantity can be set.
KLF-M9400-11X, Dump Station Assy.MU
* Sensor specs. (S-specs.)
* "Full" sensor / the permissible quantity can be set.
70
13. References and details
YSM20R (SESMK18400-00) v2.001
13.3 Nozzle station
13.3.1 For HM Head Nozzle station (2-beam specs.)
Each table uses one nozzle station. Each of the front and rear nozzle stations can be installed selectively.
The same head numbers that correspond to each station number are applied to the A table and B table.
1
73
75
74
76
19
37
55
2
20
38
56
3
21
39
57
4
22
40
58
5
23
41
59
6
24
42
60
7
25
43
61
8
26
44
62
9
27
45
63
10
28
46
64
11
29
47
65
12
30
48
66
13
31
49
67
14
32
50
68
15
33
51
69
16
34
52
70
17
35
53
71
18
36
54
72
Front Side
: Custom-order Area
No.
Head
No.
Nozzle Type
No.
Head
No.
Nozzle Type
Standard Narrow-pitch Standard Narrow-pitch
1
- Custom-order
39 5 Type304A Type315A
2 40 - Custom-order
3 1 Type304A Type315A 41 7 Type304A Type315A
4 - Custom-order 42 - Custom-order
5 3 Type304A Type315A 43 9 Type304A Type315A
6
- Custom-order
44 - Custom-order
7 45 1
Type301A Type312A
8 46 2
9 1
Type303A Type314A
47 3
10 2 48 4
11 3 49 5
12 4 50 6
13 5 51 7
14 6 52 8
15 7 53 9
16 8 54 10
17 9 55 3
Type3010A Type3110A
18 10 56 4
19
- Custom-order
57 5
20 58 6
21 59 7
22 60 8
23 61 9
24 62 10
25 63 1
Custom-order Type311A
26 64 2
27 1
Type302A Type313A
65 3
28 2 66 4
29 3 67 5
30 4 68 6
31 5 69 7
32 6 70 8
33 7 71 9
34 8 72 10
35 9 73
- φ13.5 Custom-order
36 10 74
37 1
Type3010A Type3110A
75 3
Type307A Type318A
38 2 76 8
* "-" described above shows that there is no initial setting.
* The head numbers corresponding to the station number are different from those of the 1-beam specifications.
71
13. References and details
YSM20R (SESMK18400-00) v2.001
13.3.2 For FM Head Nozzle station (2-beam specs.)
Each table uses one nozzle station. Each of the front and rear nozzle stations can be installed selectively.
The same head numbers that correspond to each station number are applied to the A table and B table.
44
49
45
50
46
51
47
52
48
53
54
55 56 57
11
22
33
1
12
23
34
2
13
24
35
3
14
25
36
4
15
26
37
5
16
27
38
6
17
28
39
7
18
29
40
8
19
30
41
9
20
31
42
10
21
32
43
Front Side
: Custom-order Area
No.
Head
No.
Nozzle Type
No.
Head
No.
Nozzle Type
Standard Narrow-pitch Standard Narrow-pitch
1 - Custom-order 30 4 Type301A Type312A
2 1 Type303A Type314A 31 5 Type304A Type315A
3 - Custom-order 32 5 Type301A Type312A
4 2 Type303A Type314A 33 - Custom-order
5 - Custom-order 34 1 Type3010A Type3110A
6 3 Type303A Type314A 35 1 Custom-order Type311A
7 - Custom-order 36 2 Type3010A Type3110A
8 4 Type303A Type314A 37 2 Custom-order Type311A
9 - Custom-order 38 3 Type3010A Type3110A
10 5 Type303A Type314A 39 3 Custom-order Type311A
11 -
Custom-order
40 4 Type3010A Type3110A
12 - 41 4 Custom-order Type311A
13 1 Type302A Type313A 42 5 Type3010A Type3110A
14 - Custom-order 43 5 Custom-order Type311A
15 2 Type302A Type313A 44 1
Type307A Type318A
16 - Custom-order 45 2
17 3 Type302A Type313A 46 3
18 - Custom-order 47 4
19 4 Type302A Type313A 48 5
20 - Custom-order 49
-
φ13.5 Custom-order
21 5 Type302A Type313A 50
22 - Custom-order 51
23 1 Type304A Type315A 52
24 1 Type301A Type312A 53
25 2 Type304A Type315A 54
φ25 Custom-order
26 2 Type301A Type312A 55
27 3 Type304A Type315A 56
28 3 Type301A Type312A 57
29 4 Type304A Type315A
* "-" described above shows that there is no initial setting.
* The head numbers corresponding to the station number are different from those of the 1-beam
specifications.
