75
13. References and details
YSM20R (SESMK18400-00) v2.001
Details
ZS feeder 24mm wide (KLJ-MC400-00X, ZS FEEDER ASSY. 24MM)
Dimensions and weight of
feeder
Length 507mm, Height 228mm, Width 31.5mm
Weight 1.47Kg
Applicable carrier tape
specifications
Width 24mm, Maximum thickness 0.6mm
Material Emboss
Convex emboss pocket, Maximum size 15mm
Feed pitch setting 2mm / 4mm / 8mm / 12mm / 16mm / 20mm / 24mm / 28mm / 32mm
Applicable reel specifications Width 30.4mm or less,
φ
382mm or less
Empty tape feed groove Width 20.2mm, Depth 17mm
8mm-converted installation
occupied width
12mm pitch 3
16mm pitch 2
ZS feeder 32mm wide (KLJ-MC500-00X, ZS FEEDER ASSY. 32MM)
* When installing in YS series models, the applicable emboss depth becomes 17mm.
Dimensions and weight of
feeder
Length 508mm, Height 228mm, Width 39.5mm
Weight 1.76Kg
Applicable carrier tape
specifications
Width 32mm, Maximum thickness 0.6mm
Material Emboss
Convex emboss pocket, Maximum size 24mm
Feed pitch setting 4mm / 8mm / 12mm / 16mm / 20mm / 24mm / 28mm / 32mm / 36mm /
40mm / 44mm / 48mm / 52mm / 56mm
Applicable reel specifications Width 38.4mm or less,
φ
382mm or less
Empty tape feed groove Width 25mm, Depth 25mm
8mm-converted installation
occupied width
12mm pitch 4
16mm pitch 3
ZS feeder 44mm wide (KLJ-MC600-00X, ZS FEEDER ASSY. 44MM)
* When installing in YS series models, the applicable emboss depth becomes 17mm.
Dimensions and weight of
feeder
Length 508mm, Height 228mm, Width 51.5mm
Weight 2.03Kg
Applicable carrier tape
specifications
Width 44mm, Maximum thickness 0.6mm
Material Emboss
Convex emboss pocket, Maximum size 24mm
Feed pitch setting 4mm / 8mm / 12mm / 16mm / 20mm / 24mm / 28mm / 32mm / 36mm /
40mm / 44mm / 48mm / 52mm / 56mm
Applicable reel specifications Width 50.4mm or less,
φ
382mm or less
Empty tape feed groove Width 37mm, Depth 25mm
8mm-converted installation
occupied width
12mm pitch 5
16mm pitch 4
76
13. References and details
YSM20R (SESMK18400-00) v2.001
Details
ZS feeder 56mm wide (KLJ-MC700-00X, ZS Feeder Assy 56mm)
* When installing in YS series models, the applicable emboss depth becomes 17mm.
Dimensions and weight of
feeder
Length 508mm, Height 228mm, Width 63.5mm
Weight 2.29Kg
Applicable carrier tape
specifications
Width 56mm, Maximum thickness 0.6mm
Material Emboss
Convex emboss pocket, Maximum size 24mm
Feed pitch setting 4mm / 8mm / 12mm / 16mm / 20mm / 24mm / 28mm / 32mm / 36mm /
40mm / 44mm / 48mm / 52mm / 56mm
Applicable reel specifications Width 62.4mm or less,
φ
382mm or less
Empty tape feed groove Width 49mm, Depth 25mm
8mm-converted installation
occupied width
12mm pitch 6
16mm pitch 4
ZS feeder 72mm wide (KLJ-MC800-00X, ZS Feeder Assy 72mm)
* When installing in YS series models, the applicable emboss depth becomes 17mm.
Dimensions and weight of
feeder
Length 508mm, Height 228mm, Width 79.5mm
Weight 2.82Kg
Applicable carrier tape
specifications
Width 72mm, Maximum thickness 0.6mm
Material Emboss
Convex emboss pocket, Maximum size 24mm
Feed pitch setting 4mm / 8mm / 12mm / 16mm / 20mm / 24mm / 28mm / 32mm / 36mm /
40mm / 44mm / 48mm / 52mm / 56mm
Applicable reel specifications Width 89.0mm or less,
φ
382mm or less
Empty tape feed groove Width 65mm, Depth 25mm
8mm-converted installation
occupied width
12mm pitch 7
16mm pitch 5
ZS feeder 88mm wide (KLJ-MC900-00X, ZS Feeder Assy 88mm)
* When installing in YS series models, the applicable emboss depth becomes 17mm.
Dimensions and weight of
feeder
Length 508mm, Height 228mm, Width 95.5mm
Weight 3.23Kg
Applicable carrier tape
specifications
Width 88mm, Maximum thickness 0.6mm
Material Emboss
Convex emboss pocket, Maximum size 24mm
Feed pitch setting 4mm / 8mm / 12mm / 16mm / 20mm / 24mm / 28mm / 32mm / 36mm /
40mm / 44mm / 48mm / 52mm / 56 mm
Applicable reel specifications Width 105.0mm or less,
φ
382mm or less
Empty tape feed groove Width 81mm, Depth 25mm
8mm-converted installation
occupied width
12mm pitch 8
16mm pitch 6
77
13. References and details
YSM20R (SESMK18400-00) v2.001
Details
ZS feeder 104mm wide (KLJ-MCA00-00X, ZS Feeder Assy 104mm)
* When installing in YS series models, the applicable emboss depth becomes 17mm.
Dimensions and weight of
feeder
Length 508mm, Height 228mm, Width 111.5mm
Weight 3.62Kg
Applicable carrier tape
specifications
Width 104mm, Maximum thickness 0.6mm
Material Emboss
Convex emboss pocket, Maximum size 24mm
Feed pitch setting 4mm / 8mm / 12mm / 16mm / 20mm / 24mm / 28mm / 32mm / 36mm /
40mm / 44mm / 48mm / 52mm / 56mm
Applicable reel specifications Width 121.0mm or less,
φ
382mm or less
Empty tape feed groove Width 97mm, Depth 25mm
8mm-converted installation
occupied width
12mm pitch 10
16mm pitch 7
Item Details
Splicing sensor built-in ZS feeder, 8 mm wide KLJ-MC100-10X, ZS FEEDER ASSY.8-S
Splicing sensor built-in ZS feeder, 12 / 16 mm wide KLJ-MC200-10X, ZS FEEDER ASSY.1216S
Splicing sensor built-in ZS feeder, 24 mm wide KLJ-MC400-10X, ZS FEEDER ASSY.24-S
Splicing sensor built-in ZS feeder, 32 mm wide KLJ-MC500-10X, ZS FEEDER ASSY.32-S
Splicing sensor built-in ZS feeder, 44 mm wide KLJ-MC600-10X, ZS FEEDER ASSY.44-S
Splicing sensor built-in ZS feeder, 56 mm wide KLJ-MC700-10X, ZS FEEDER ASSY.56-S
Splicing sensor built-in ZS feeder, 72 mm wide KLJ-MC800-10X, ZS FEEDER ASSY.72-S
Splicing sensor built-in ZS feeder, 88 mm wide KLJ-MC900-10X, ZS FEEDER ASSY.88-S
Splicing sensor built-in ZS feeder, 104 mm wide KLJ-MCA00-10X, ZS FEEDER ASSY.104S
Additional splicing sensor for feeder width of 8 mm KHJ-MC1A5-10X,Splice sensor 8mm
Additional splicing sensor for feeder width of 12 mm or more KHJ-MC2A5-10X,Splice sensor Large
