78
13. References and details
YSM20R (SESMK18400-00) v2.001
13.4.2 SS Feeder
Details
SS feeder 8mm wide (KHJ-MC100-0XX, SS feeder Assy 8mm)
Dimensions and weight of
feeder
Length 425mm, Height 226mm, Width 11.5mm
Weight 0.7Kg
Applicable carrier tape
specifications
Width 8mm, Maximum thickness 1.0mm
Material Paper / Emboss
Convex emboss pocket, Maximum size 3mm
Feed pitch setting 1mm / 2mm / 4mm / 8mm
Applicable reel specifications Width 14.4mm or less,
φ
382mm or less
Empty tape feed groove Width 4.6mm, Depth 3mm
8mm-converted installation
occupied width
12mm pitch 1
16mm pitch 1
SS feeder 12 / 16mm wide (KHJ-MC200-00X, SS FEEDER ASSY. 12 / 16mm)
* Top cover is replaced with an included one to make the feeder width applicable to 12mm / 16mm.
Dimensions and weight of
feeder
Length 425mm, Height 226mm, Width 23.5mm
Weight 1.2Kg
Applicable carrier tape
specifications
12mm Width
Width 12mm, Maximum thickness 1.0mm
Material Paper / Emboss
16mm Width
Width 16mm, Maximum thickness 0.8mm
Material Emboss
Convex emboss pocket, Maximum size 15mm
12mm Width Feed pitch setting 4mm / 8mm / 12mm / 16mm
16mm Width Feed pitch setting 4mm / 8mm / 12mm / 16mm
Applicable reel specifications
12mm Width Width 18.4mm or less,
φ
382mm or less
16mm Width Width 22.4mm or less,
φ
382mm or less
Empty tape feed groove
12mm Width Width 8.3mm, Depth 17mm
16mm Width Width 11.9mm, Depth 17mm
8mm-converted installation
occupied width
12mm pitch 2
16mm pitch 2
SS feeder 24mm wide (KHJ-MC400-0XX, SS feeder Assy 24mm)
Dimensions and weight of
feeder
Length 425mm, Height 226mm, Width 31.5mm
Weight 1.35Kg
Applicable carrier tape
specifications
Width 24mm, Maximum thickness 0.6mm
Material Emboss
Convex emboss pocket, Maximum size 15mm
Feed pitch setting 4mm / 8mm / 12mm / 16mm / 20mm / 24mm
Applicable reel specifications Width 30.4mm or less,
φ
382mm or less
Empty tape feed groove Width 20.2mm, Depth 17mm
8mm-converted installation
occupied width
12mm pitch 3
16mm pitch 2
79
13. References and details
YSM20R (SESMK18400-00) v2.001
Details
SS feeder 32mm wide (KHJ-MC500-0XX, SS feeder Assy 32mm)
Dimensions and weight of
feeder
Length 425mm, Height 226mm, Width 39.5mm
Weight 1.5Kg
Applicable carrier tape
specifications
Width 32mm, Maximum thickness 0.6mm
Material Emboss
Convex emboss pocket, Maximum size 17mm
Feed pitch setting 4mm / 8mm / 12mm / 16mm / 20mm / 24mm / 28mm / 32mm / 36mm /
40mm / 44mm / 48mm / 52mm / 56mm
Applicable reel specifications Width 38.4mm or less,
φ
382mm or less
Empty tape feed groove Width 25mm, Depth 18.5mm
8mm-converted installation
occupied width
12mm pitch 4
16mm pitch 3
SS feeder 44mm wide (KHJ-MC600-0XX, SS feeder Assy 44mm)
Dimensions and weight of
feeder
Length 425mm, Height 226mm, Width 51.5mm
Weight 1.8Kg
Applicable carrier tape
specifications
Width 44mm, Maximum thickness 0.6mm
Material Emboss
Convex emboss pocket, Maximum size 17mm
Feed pitch setting 4mm / 8mm / 12mm / 16mm / 20mm / 24mm / 28mm / 32mm / 36mm /
40mm / 44mm / 48mm / 52mm / 56mm
Applicable reel specifications Width 50.4mm or less,
φ
382mm or less
Empty tape feed groove Width 37mm, Depth 18.5mm
8mm-converted installation
occupied width
12mm pitch 5
16mm pitch 4
SS feeder 56mm wide (KHJ-MC700-0XX, SS feeder Assy 56mm)
Dimensions and weight of
feeder
Length 425mm, Height 226mm, Width 63.5mm
Weight 2.0Kg
Applicable carrier tape
specifications
Width 56mm, Maximum thickness 0.6mm
Material Emboss
Convex emboss pocket, Maximum size 17mm
Feed pitch setting 4mm / 8mm / 12mm / 16mm / 20mm / 24mm / 28mm / 32mm / 36mm /
40mm / 44mm / 48mm / 52mm / 56mm
Applicable reel specifications Width 62.4mm or less,
φ
382mm or less
Empty tape feed groove Width 49mm, Depth 18.5mm
8mm-converted installation
occupied width
12mm pitch 6
16mm pitch 4
80
13. References and details
YSM20R (SESMK18400-00) v2.001
Details
SS feeder 72mm wide (KHJ-MC800-0XX, SS feeder Assy 72mm)
Dimensions and weight of
feeder
Length 425mm, Height 226mm, Width 79.5mm
Weight 2.4Kg
Applicable carrier tape
specifications
Width 72mm, Maximum thickness 0.6mm
Material Emboss
Convex emboss pocket, Maximum size 17mm
Feed pitch setting 4mm / 8mm / 12mm / 16mm / 20mm / 24mm / 28mm / 32mm / 36mm /
40mm / 44mm / 48mm / 52mm / 56mm
Applicable reel specifications Width 89.0mm or less,
φ
382mm or less
Empty tape feed groove Width 65mm, Depth 18.5mm
8mm-converted installation
occupied width
12mm pitch 7
16mm pitch 5
SS feeder 88mm wide (KHJ-MC900-0XX, SS feeder Assy 88mm)
Dimensions and weight of
feeder
Length 425mm, Height 226mm, Width 95.5mm
Weight 2.93Kg
Applicable carrier tape
specifications
Width 88mm, Maximum thickness 0.6mm
Material Emboss
Convex emboss pocket, Maximum size 17mm
Feed pitch setting 4mm / 8mm / 12mm / 16mm / 20mm / 24mm / 28mm / 32mm / 36mm /
40mm / 44mm / 48mm / 52mm / 56mm
Applicable reel specifications Width 105.0mm or less,
φ
382mm or less
Empty tape feed groove Width 81mm, Depth 18.5mm
8mm-converted installation
occupied width
12mm pitch 8
16mm pitch 6
Item Details
Splicing sensor built-in SS feeder, 8 mm wide KHJ-MC100-1XX, SS feeder Assy 8-S
Splicing sensor built-in SS feeder, 12 / 16 mm wide KHJ-MC200-1XX, SS feeder Assy 12 / 16-S
Splicing sensor built-in SS feeder, 24 mm wide KHJ-MC400-1XX, SS feeder Assy 24-S
Splicing sensor built-in SS feeder, 32 mm wide KHJ-MC500-1XX, SS feeder Assy 32-S
Splicing sensor built-in SS feeder, 44 mm wide KHJ-MC600-1XX, SS feeder Assy 44-S
Splicing sensor built-in SS feeder, 56 mm wide KHJ-MC700-1XX, SS feeder Assy 56-S
Splicing sensor built-in SS feeder, 72 mm wide KHJ-MC800-1XX, SS feeder Assy 72-S
Splicing sensor built-in SS feeder, 88 mm wide KHJ-MC900-1XX, SS feeder Assy 88-S
Additional splicing sensor for 8mm width KHJ-MC1A5-10X, Splice sensor 8mm
Additional splicing sensor for 12mm and larger widths KHJ-MC2A5-10X, Splice sensor Large
