80
13. References and details
YSM20R (SESMK18400-00) v2.001
Details
SS feeder 72mm wide (KHJ-MC800-0XX, SS feeder Assy 72mm)
Dimensions and weight of
feeder
Length 425mm, Height 226mm, Width 79.5mm
Weight 2.4Kg
Applicable carrier tape
specifications
Width 72mm, Maximum thickness 0.6mm
Material Emboss
Convex emboss pocket, Maximum size 17mm
Feed pitch setting 4mm / 8mm / 12mm / 16mm / 20mm / 24mm / 28mm / 32mm / 36mm /
40mm / 44mm / 48mm / 52mm / 56mm
Applicable reel specifications Width 89.0mm or less,
φ
382mm or less
Empty tape feed groove Width 65mm, Depth 18.5mm
8mm-converted installation
occupied width
12mm pitch 7
16mm pitch 5
SS feeder 88mm wide (KHJ-MC900-0XX, SS feeder Assy 88mm)
Dimensions and weight of
feeder
Length 425mm, Height 226mm, Width 95.5mm
Weight 2.93Kg
Applicable carrier tape
specifications
Width 88mm, Maximum thickness 0.6mm
Material Emboss
Convex emboss pocket, Maximum size 17mm
Feed pitch setting 4mm / 8mm / 12mm / 16mm / 20mm / 24mm / 28mm / 32mm / 36mm /
40mm / 44mm / 48mm / 52mm / 56mm
Applicable reel specifications Width 105.0mm or less,
φ
382mm or less
Empty tape feed groove Width 81mm, Depth 18.5mm
8mm-converted installation
occupied width
12mm pitch 8
16mm pitch 6
Item Details
Splicing sensor built-in SS feeder, 8 mm wide KHJ-MC100-1XX, SS feeder Assy 8-S
Splicing sensor built-in SS feeder, 12 / 16 mm wide KHJ-MC200-1XX, SS feeder Assy 12 / 16-S
Splicing sensor built-in SS feeder, 24 mm wide KHJ-MC400-1XX, SS feeder Assy 24-S
Splicing sensor built-in SS feeder, 32 mm wide KHJ-MC500-1XX, SS feeder Assy 32-S
Splicing sensor built-in SS feeder, 44 mm wide KHJ-MC600-1XX, SS feeder Assy 44-S
Splicing sensor built-in SS feeder, 56 mm wide KHJ-MC700-1XX, SS feeder Assy 56-S
Splicing sensor built-in SS feeder, 72 mm wide KHJ-MC800-1XX, SS feeder Assy 72-S
Splicing sensor built-in SS feeder, 88 mm wide KHJ-MC900-1XX, SS feeder Assy 88-S
Additional splicing sensor for 8mm width KHJ-MC1A5-10X, Splice sensor 8mm
Additional splicing sensor for 12mm and larger widths KHJ-MC2A5-10X, Splice sensor Large
81
13. References and details
YSM20R (SESMK18400-00) v2.001
13.4.2 Feed pitch by feeder button operation
ZS feeder
[FUNC] button
[BACK] button
[FEED] button
Feeder type Set pitch
[FEED] or [BACK]
is pressed once.
[FUNC + FEED] or [FUNC +
BACK] are pressed once.
ZS feeder 4mm wide All pitches 1mm 1mm
ZS feeder 8mm wide
0 2mm
1mm1 1mm
2 or more 2mm
ZS feeder
12/16mm wide, 24mm wide,
32mm wide, 44mm wide,
56mm wide, 72mm wide,
88mm wide, 104mm wide
0
2mm
2mm
2 or more Set pitch
* Pressing the [FEED] or [BACK] button for a long time will enter the continuous feed mode.
* Even when pressing the [FUNC + FEED] or [FUNC + BACK] buttons for a long time, the operation does
not enter the continuous feed mode.
SS feeder
[FUNC] button
[BACK] button
[FEED] button
Feeder type Set pitch
[FEED] or [BACK]
is pressed once.
[FUNC + FEED] or [FUNC +
BACK] are pressed once
SS feeder 8mm wide
0 2mm 2mm
1 1mm
Set pitch
2 or more 2mm
SS feeder
12/16mm wide, 24mm wide,
32mm wide, 44mm wide,
56mm wide, 72mm wide,
88mm wide
0
2mm
2mm
4 or more Set pitch
* Pressing the [FEED] or [BACK] button for a long time will enter the continuous feed mode.
* Pressing the [FUNC] + [FEED] buttons will feed the tape by the set pitch feed width.
* 1mm-feed of the SS feeder 8mm-wide and 44mm-feed or longer of the SS feeder 32mm-wide or more
may vary depending on the feeder version. So, please contact your distributor for further information.
82
13. References and details
YSM20R (SESMK18400-00) v2.001
Item Details
IT option basic package
* To operate this package, IT-system is needed.
Provided. (Option) / Without barcode reader
Function 1: Setup verify
Function 2: Remaining quantity counter
* To operate the setup verify, wireless handy reader is needed.
Provided. (Option) / With barcode reader
Function 1: Setup verify
Function 2: Remaining quantity counter
* Barcode reader is assembled into portions before and after the
machine.
None (Standard)
Lot trace output
Provided. (Option)
* IT option basic package and T-Tool are needed.
None (Standard)
Automatic setup change-over
Provided. (Option)
* IT option basic package is needed.
* Carefully check the price of the fist machine and that or the
second or subsequent machine.
None (Standard)
Material time limit management
Provided. (Option)
* IT option basic package and wireless handy reader are needed.
None (Standard)
Bin Code Management Option
Provided. (Option)
* IT option basic package is needed.
None (Standard)
Load control
(FM head)
Provided. (Standard)
Load Load tolerance
5N - 13N Set load + / - 2N
14N - 30N Set load + / - 15%
