13. References and details

YSM20R (SESMK18400-00) v2.001

Yamaha SMT line support software

Y.FacT

Requires a separate personal computer,

hub, LAN wiring, etc.For details,

please contact your distributor.

Item Details

P-Tool / programming tool

(with USB hardware key)

[Configuration elements]

(1) Main unit functions

⇒

Board editor / board explorer /

data base editor / feeder viewer

(2) USB protection key

(also referred to as a "hard key" or "dongle")

(3) ASCII conversion function

⇒

CAD-BOM format (2 files)

Compatible BOM: Bill of Materials (parts list)

(4) Line data distribution function

(multiple machine optimization)

(5) Common setup optimizing function

(6) Visual editor

⇒

simple desktop test mounting

/ automatic measurement of component dimensions

⇒

Board data creation package & production startup

preparation (CAD / CAM support)

* Function package of the Y.FacT support software.

* "YVi-OS" is required for editing the checking device

data.

K88-M4920-B0X, Software Y.FacT P-Tool Assy

" K88-M4921-71X, FacT Tools instal l" *1

" K88-M4923-21X, Box for FD Assy " *1

" K88-M4926-40X, Registerd Hard-key P-Tool " *1

Manual teaching / P-Tool option

(Visual editor function extension)

[Function]

Shortens initial data creation time and improves quality.

Component image pasting (shape drawing) verify / angle

correction / coordinate correction

(* POT2 function import selection)

M-Tool View

(with USB hardware key)

[Configuration elements]

(1) USB protection key

(also referred to as a "hard key" or "dongle")

(2) Floor Monitoring

(3) Line Monitoring

==> Floor Monitoring & Line Monitoring

* Function package of the Y.FacT support software.

* "Tool Drive", "Machine Monitoring OP" are required.

K88-M4931-00X, Software Y.FacT M-Tool View Assy

" K88-M4921-71X, FacT Tools install " *1

" K88-M4923-21X, Box for FD Assy " *1

" K88-M4926-P0X, Registered Hard-key M-Tool View" *1

M-Tool / monitoring tool

(with USB hardware key)

[Configuration elements]

(1) Main unit functions

⇒

Board editor / board

explorer / data base editor / feeder viewer /

single machine optimizing

(2) USB protection key

(also referred to as a "hard key" or "dongle")

(3) Line control function

(4) Data communication (transmission / reception)

(5) "Remaining component quantity" centralized

management monitor (linked to IT option).

==> Line management package & Line remote monitoring

(general-purpose LAN support)

* Function package of the Y.FacT support software.

K88-M4920-C0X, Software Y.FacT M-Tool Assy

" K88-M4921-71X, FacT Tools install " *1

" K88-M4926-50X, Registered Hard-key M-Tool " *1

13. References and details

YSM20R (SESMK18400-00) v2.001

Item Details

IT-System / server utility program

(with USB hardware key)

[Configuration elements]

(1) Server system building software

(2) USB protect key

(also referred to as a hard key or dongle)

(3) Communication utility for each client

personal computer other than the S-Tool personal computer

* Prerequisite item for S-Tool / IT option.

* For building a LAN system in a machine where

S-Tool or IT option is installed.

* For installing in the server personal computer.

* One of these programs is required for each data

management block (floor units, line units, etc.).

K88-M4920-V0X, Software IT-System Assy

" K88-M4921-90X, IT-System Installation Assy " *1

" K88-M4923-21X, Box for FD Assy " *1

" K88-M4926-B0X, Registered Hard-key System " *1

Tool Drive / server utility program

(with USB hardware key)

[Configuration elements]

(1) Basic functions ==> board explorer

(2) Server system building software

(3) USB protection key

(also referred to as a "hard key" or "dongle")

* For installing in the server personal computer.

* "Tool Drive", "Machine Monitoring OP" are required.

K88-M4931-10X, Software Tool Drive Assy

" K88-M4921-71X, FacT Tools install " *1

" K88-M4923-21X, Box for FD Assy " *1

" K88-M4926-R0X, Registered Hard-key Tool Drive " *1

S-Tool / external navigation

(with USB hardware key)

[Configuration elements]

(1) Basic functions

⇒

Board editor / board

explorer / database editor / feeder viewer /

single machine optimizing

(2) External navigation function software

(3) USB protection key

(also referred to as a hard key or dongle)

(4) Wired USB to personal computer connection

Barcode reader *1 unit

(5) Barcode ID label *1 set

⇒

Setup task package & mounting components

preparation support

* Support software Y.FacT function package

* This function requires the IT-System / server utility

program.

K88-M4920-L0X , Software Y.FacT S-Tool Assy

" K88-M4921-71X, FacT Tools install " *1

" KGA-M55B2-00X, Bar-Code-Reader USB" *1

" K88-M4923-21X, Box for FD Assy" *1

" K88-M4928-00X, Tool FDR Pos Assy (Labels) " *1

" K88-M4926-C0X, Registered Hard-key S-Tool " *1

S-Tool / Material time limit management

(with USB hardware key)

[Function]

By preventing the use of life-expired printer materials,

this function contributes to a higher production quality.

This function manages the life of materials (solder and tray

components, etc.,) with consideration to factors such as their

storage conditions, and notifies the operator when a material

life has expired or expiration date approaches.

This function also enhances quality control by maintaining

information regarding dates when components were received

and released from the warehouse.

* This function requires S-Tool / Set-up navigation.

* This function requires the wireless Handy Reader

function.

K88-M4920-S0X, SOFT Y.FacT S-Tlim Assy

" K88-M4926-F0X, Registerd HK S-Tlim" *1

" K88-M4921-71X, FacT Tools install " *1

" K88-M4923-21X, Box for FD Assy" *1

S-Tool / Bin Code Management Option

[Function]

Component characteristics, such as rank of the LED component,

etc. are verified to prevent incorrect setup in the production.

Whether or not the rank is used and whether or not the

component applicable to the rank is used that have been preset

are verified in the setup phase.

* IT option basic package is needed.

K88-M4931-20X, Software Y.FacT Srank Assy

" K88-M4926-U00, Registerd HK S-Rank" *1

" K88-M4921-71X, FacT Tools install " *1

" K88-M4923-21X, Box for FD Assy" *1

13. References and details

YSM20R (SESMK18400-00) v2.001

Item Details

S-Tool Option / carriage communication cable set

(with license protection key)

* For the external setup work, Carriage external setup

power unit is required.

KHJ-M668B-000, HNS FESCOM 3M

KHJ-M668B-100, HNS FESCOM 5M

KHJ-M668B-200, HNS FESCOM 7M

T-Tool / production record management tool

(with USB hardware key)

[Configuration elements]

(1) Product lot trace software

(2) USB protection key

(also referred to as a hard key or dongle)

⇒

Production lot & product ID record management

* Support software Y.FacT function package

K88-M4920-R0X , Software Y.FacT T-Tool Assy

" K88-M4921-A0X, T-Tools install " *1

" K88-M4923-21X, Box for FD Assy " *1

" K88-M4926-D0X, Registerd Hard-key T-Tool " *1

Item Details

Version upgrade P-Tool

(No license protection key)

K88-M4920-F0X, Software Y.FacT Version-Up

* Only functions for which the customer possesses a license key are activated.

Version upgrade M-Tool View

(No license protection key)

K88-M4920-F0X, Software Y.FacT Version-Up

* Only functions for which the customer possesses a license key are activated.

* Installation CD-R only

K88-M4921-71X, FacT Tools instal

Version upgrade M-Tool

(No license protection key)

K88-M4920-F0X, Software Y.FacT Version-Up

* Only functions for which the customer possesses a license key are activated.

* Installation CD-R only

K88-M4921-71X, FacT Tools instal

Version upgrade IT-System

(No license protection key)

K88-M4920-P0X, Software IT-System Version-Up

* Installation CD-R only

K88-M4921-90X, IT-System Installation Assy

Version upgrade Tool Drive

(No license protection key)

K88-M4920-F0X, Software Y.FacT Version-Up

* Only functions for which the customer possesses a license key are activated.

* Installation CD-R only

K88-M4921-71X, FacT Tools install

Version upgrade S-Tool

(No license protection key)

K88-M4920-F0X, Software Y.FacT Version-Up

* Installation CD-R only

K88-M4921-71X, FacT Tools instal

Version upgrade T-Tool

(No license protection key)

K88-M4920-U0X, Software T-Tool Version-Up

* Installation CD-R only

K88-M4921-A0X, T-Tools install
