MYD series
Cross-industry capable
platform
The MYD series automatic inline dispensing system is proven across many
industries such as electronics, medical devices, optics and industrial assembly
to name a few.
CONSUMER ELECTRONICS
KEY APPLICATIONS,
CONSUMER ELECTRONICS
- Hot melt
- Underfill
- Pin encapsulation
- Conformal coating
- Edge/corner bonding
- Surface mount package
- Package on package
- Dam and fill
- SMA
- FPC component
- Reinforcement materials
SMT ELECTRONICS
AUTOMOTIVE ELECTRONICS
LED AND MEDICAL INDUSTRY
76
MYD Series Core Components
Highest Throughput, lowest
cost of ownership
UNIQUE CAPABILITIES
The MYD jet valves and pumps can produce high
drop velocity, allowing a wide range of fl uids and
applications.
It is easy to change the drop velocity to fi ne tune
the dispensing process and achieve a high process
capability.
PRECISE CONTROLS
Closed loop controls and system feedback are key for
higher yields. Focus on smart jetting controls, closed
loop substrate heating, user specifi ed temperature
spot checks and closed loop material dispense are
the foundation of quality output.
SIMPLE MAINTENANCE
The MYD jet valves are designed with simplicity and
ease of use in mind. Minimal disassembly required
and wear parts are easily replaced.
Diff erent types of jet valves provide wide range of capabilities to optimize
your process based on your specifi c materials. For large fl ow applications,
auger valves and positive displacement pumps decrease cycle time while
maintaining tight process controls. All jets, valves and pumps are designed
with speed, durability and precision in mind.
8 9
MYD series
Key features
DUAL LANE CONVEYORS
Dual lane help in maximizing your production line
and optimizing throughput. Two diff erent jobs can
run on each line.
CONFIGURABLE CONVEYOR STATIONS
Edge clamps, vacuum blocks, vacuum heating and
non-contact heating modules off er all the potential
material handling options for eff cient dispensing
TILT OPTIONS
Pneumatic and electrical tilt and rotate options enable precise
material dispense in diffi cult to reach locations. Individual angle
off sets are programmed for precise dispensing.
DUAL VALVE CONFIGURATIONS
Synchronous dual valve; two heads work at the same
time to save cycle time and improve productivity.
Asynchronous dual valve; two heads work at diff erent
time. Diff erent materials can be used on each valve.
TEMPERATURE SPOT CHECK
User programmable location where exact
temperature is measured and verifi ed with
programmable go/no-go logic.
AUTOMATIC VISUAL INSPECTION
AVI, automatic visual inspection, improves inspection quality and
helps automate the production line. The AVI can be setto warn, fl ag
and log production results increasing yield traceability and visibility.
