User Manual SIPLACE CS 4 Setting up the placement system
Software version SR.101.xx 06/2003 US Edition 4.1 Transport configuration and infrastructure
103
4.1.4 Compressed air supply
4.1.4.1 Compressed air specification
The compressed air supply should conform to the following specification:
4
4
4.1.4.2 Checking the compressed air supply
Check that the compressed air supply conforms to the prescribed machine specifications.
PLEASE NOTE:
The document entitled "Network configuration (electrical and compressed air) for SMD systems
on the customer's premises", part no. 00191409-xx, describes the action that can be taken to
meet the required specifications.
Æ Record the compressed air characteristics at the installation location.
p
min
0.55 MPa = 5.5 bar
p
max
1.0 MPa = 10 bar
Connection 1/2"
Compressed air consumption 400 l/min.
Particle size 0.1 µm
Particle density 0.1 mg/m³
Maximum oil content (class 1) Particle density 0.01 mg/m³
Pressure dewpoint (class 4) Dewpoint + 3°
4 Setting up the placement system User Manual SIPLACE CS
4.2 Setting up the placement system Software version SR.101.xx06/2003 US Edition
104
4.1.5 Power supply
4.1.5.1 Electrical ratings
4
4
4
4.1.5.2 Checking the main power supply
Check that the main power supply conforms to the prescribed machine specifications.
PLEASE NOTE:
The document entitled "Network configuration (electrical and compressed air) for SMD systems
on the customer's premises", part no. 00191409-xx, describes the action that can be taken to
meet the required specifications.
4.2 Setting up the placement system
4.2.1 Safety instructions
WARNING
– The applicable accident prevention regulations concerning the transportation of heavy goods
must be followed.
– There is a risk that the machine will tip over if you do not use the pallet jack specified in section
4.1.3
to transport the placement machine.
– In particular, you should wear safety boots to minimize the risk of crushing your feet.
– Attach the pallet jack only at the points identified by A in Fig. 4.1 - 1).
Supply voltage 3 x 200 VAC ± 5 %; 50/60 Hz (Japan)
3 x 208 VAC ± 5 %; 50/60 Hz (U.S.A)
3 x 400 VAC ± 5 %; 50/60 Hz (Europe)
Fuses 3 x 16 A (3 x 204 VAC)
Total connected load 5 kVA
Total power 2 kW
Power failure Max. 20 msec
User Manual SIPLACE CS 4 Setting up the placement system
Software version SR.101.xx 06/2003 US Edition 4.2 Setting up the placement system
105
4.2.2 Setting up the placement machine
Æ Raise the placement system using the fork-lift truck and adjust the feet until there is a gap of
830 mm between the top edge of the PCB conveyors and the bottom edge of the feet.
Æ Leave a gap of 1 to 3 mm between the PCB conveyors of the placement system.
Æ Align all the placement systems exactly in line with one another. Use a cord pulled tight to en-
sure this.
Æ Adjust each placement system using a spirit level with an accuracy of 0.02 mm/m.
Æ Lock the feet in position.
Æ Check the placement system again using the spirit level and correct the settings, if necessary.
CAUTION
Make sure that you remove all the shipping braces from the placement system. 4
Æ Fit any components that were dismantled for dispatch.
Æ Connect all the electrical and pneumatic lines.
RISK OF DEATH
The electrical connection work MUST be carried out only by appropriately trained and cer-
tified personnel. 4
