User Manual SIPLAC E CS 2 Operational safety Software vers ion SR.101.xx 06/ 2003 US Edition 2.1 Safety instruc tions 17 2 Operational safety 2.1 Safety instructions 2.1.1 C onventions for the use of hazard symbols This …
1 Introduction User Manual SIPLACE CS
1.6 Revision index Software version SR.101.xx06/2003 US Edition
16
1.6 Revision index
1
1
1
1.7 Abbreviations
1
1
1
Manual Software version Edition
First edition User Manual SR.101.xx 06/2003 US
CO 1 Component 1
C&P 1 Collect&Place 1
C&P6 1 Collect&Place head with 6 segments 1
DCA 1 Direct Chip Attach 1
FC 1 Flip chip 1
WT 1 Waffle-pack tray 1
WPTC 1 Waffle-pack tray carrier 1
GND 1 Ground 1
IC 1 Integrated circuit 1
PCB 1 Printed circuit board 1
P&P 1 Pick&Place 1
WPC 1 Waffle-pack changer 1
User Manual SIPLACE CS 2 Operational safety
Software version SR.101.xx 06/2003 US Edition 2.1 Safety instructions
17
2 Operational safety
2.1 Safety instructions
2.1.1 Conventions for the use of hazard symbols
This User Manual contains notes that must be observed to guarantee your personal safety and to
avoid damage to equipment. These notes are highlighted by warning triangles and are indicated
as follows according to the level of risk:
2
DANGER or
as used in this User Manual means that death, severe injury or considerable damage to equip-
ment will occur if the danger instructions are not followed.
2
WARNING or
as used in this User Manual means that death, severe injury or considerable damage to equip-
ment may occur if the warning instructions are not followed.
2
CAUTION or
as used in this User Manual means that slight injury or damage to equipment may occur if the cau-
tion instructions are not followed.
NOTE
as used in this User Manual provides information on the product or indicates a part of the User
Manual that requires particular attention.
2.1.2 Qualified personnel
Qualified or adequately trained personnel means that these people are familiar with the setting up,
operation and maintenance of automatic placement systems and add-on devices and are suitably
qualified, e.g.
– have been trained, instructed or authorized to switch on and off, isolate, earth and identify elec-
trical circuits and system components in accordance with normal safety standards.
– have been trained or instructed in the upkeep and use of appropriate safety equipment in ac-
cordance with normal safety standards.
– have received first aid training.
2 Operational safety User Manual SIPLACE CS
2.1 Safety instructions Software version SR.101.xx06/2003 US Edition
18
2.1.3 Use as prescribed
The product must only be used for its intended purposes as described in the catalogues and
technical descriptions, namely the placement of SMD components, and only with the third-party
equipment and components recommended or permitted by SiemensDematic Use for a different
or extended purpose is not prescribed.
If the product is not used as prescribed, SIEMENSDEMATIC AG accepts no liability for any dam-
age that may occur and does not guarantee that the components will work properly and without
problems.
Use as prescribed also includes compliance with all the instructions in the user manual.
For the product to operate correctly and reliably, it must have been transported, stored, erected
and assembled correctly and must be operated and maintained with care.
2.1.4 Failure to use as prescribed
Failure to use the product as prescribed can result in both danger to life and limb and material
damage. For this reason any use that is not prescribed is not allowed. If the product is not used
as prescribed, SIEMENSDEMATIC AG accepts no liability for any damage that may occur and
does not guarantee that the components will work properly and without problems.
Failure to use the placement machine as prescribed includes, for example
– operation of the placement machine with safety equipment bypassed or removed.
– placement of components that do not meet the permitted specification.
– use of component feeders that have not been approved.
– use of unauthorized accessories and additional modules.
– use of the placement machine by unqualified personnel.
– operation of the placement machine without a guard ("dummy feeder") if not every location
contains a feeder.
2.1.5 Important notes on operational safety
The following points MUST be observed in order to maintain operational safety:
2.1.5.1 General
Æ The operational safety of SMD automatic placement systems can be guaranteed only if the
system is used as prescribed and in accordance with the instructions in the User/Service Man-
uals.
