MODEL CR-G300, FB-G300
1004-004
USING YOUR EXPLODED ILLUSTRATION
This Exploded Illustration shows the information about the parts of Feeder Cart CR-G300,
Feeder Base FB-G300 for GXH-3 Series and is made for Parts Ordering.
You must not replace a part with a new one according to only the information of this
Exploded Illustration.
1. Inquiring
For identification of each part, numbers are placed on illustration pages. These
numbers (Key No.) again appear in the far left column of the part table joined up
with the illustration.
The number shown in the Q’ty column of the part table represents the quantity of
certain part used in the equipment. In case of unit assembly, however, the number
represents the quantity of certain part contained in single unit.
2. Parts Ordering
For ordering parts, some parts might not be supplied as a single item, due to the
constitution of such parts.
When ordering parts, be sure to inform us of the following details:
Model
T
ype
Serial No.
Fig. No.
Key No.
PART No.
P
AR
T NAME
Quantity
[Example]
3. Miscellaneous
This Exploded Illustration is subject to change without prior notice.
All rights reserved. No part of this work covered by the copyrights hereon may be
reproduced or copied without written permission of the publisher.
'' NOTE '' is used to show the notice that is not directly related to safety.
Some of the parts shown in the Exploded Illustration could fall into the scope of your
government’
s regulations on strategic products. In that case, anybody who intend to
export the product should acquire due authorization.
CR-G300
Model Type
123456S 7890
Serial No.
Key No.31
Key No.
6301570389
PART No.
Q'ty
4
Fig. No.
Fig. B-1
PART NAME
CASTER
PREFACE-2
MODEL CR-G300, FB-G300
0712-002
CONT-1
目 次
CONTENTS
Fig. B
フィーダカート部
FEEDER CART
SECTION
Fig. B-1
フレーム部
Frame Section
Fig. B-2
リールホルダ、ハンドル
Reel Holder
,Handle
Fig. B
フィーダベース部
FEEDER BASE SECTION
Fig. B-1
フィーダベース
Feeder Base
Fig. B-2
フィーダレバー１
Feeder Lever 1
Fig. B-3
フィーダレバー２
Feeder Lever 2
Fig. B-4
電装ボックス
Electrical Box
Fig. B-5
コネクタ
ASSY Assy Connector
G -S001-13
カート帯電防止キャスター
G -S001-13 Cart Anti-static Caster
Fig. B
フィーダカート部
(G -S001-13) FEEDER CAR
T
SECTION(G -S001-13)
Fig. B-1
フレーム部
Frame Section
