SIPLACE D4

Contents

Technical Data 32

Electrical Ratings and Compressed Air Supply 32

Electrical Connection, Interfaces and Compressed Air Connection 33

Dimensions and Set-up Conditions 34

Placement System’s Center of Gravity 35

Spacing Distances for the Single Conveyor 36

Spacing Distances for the Flexible

Dual Conveyor 37

Transport and Delivery Configuration 38

Standard List 39

List of Options 40

List of Languages 41

Awards 42

Overview of the Technical Data

Placement rate

IPC value

Benchmark value

Theoretical value

a) See page 7 for a definition of the output values

57,000 comp./h

66,000 comp./h

81,500 comp./h

Component range 01005 - 18.7 x 18.7 mm²

Placement accuracy

Angular accuracy

b) The accuracy value was measured using the vendor-neutral IPC standard

± 50 μm (3), ± 67 μm (4)

± 0.53° (3), ± 0.71° (4)

Feeder module types Tape feeder modules, stick magazine feeders, bulk

cases, application-specific OEM feeder modules

Feeding capacity 144 tracks with 3 x 8 mm S

PCB format max. 610 x 508 mm²

PCB thickness 0.3 - 4.5 mm (others available on request)

PCB weight max. 3 kg

Camera 5 illumination levels

SIPLACE D4 machine colors

Machine protection: Anthracite

(SIPLACE color code SN 614)

Hoods: Light Basic

(SIPLACE color code SN 700)

Machine protection: Light Basic

(SIPLACE color code SN 700)

Machine protection: Anthracite

(SIPLACE color code SN 614)

Machine Description

4-gantry placement

machine for maximum

output

High-tech with an optimum

price/performance ratio:

this was the SIPLACE team's

aim for the SIPLACE D4 - the

extremely fast four-gantry

machine from the new

SIPLACE D-series generation.

Now you can benefit from

the innovative added value

that the SIPLACE D4 creates

with its combination of

innovative and proven

technology.

With the SIPLACE D4, we

can provide you with an

extremely powerful place-

ment machine with four

gantries and four 12-nozzle

Collect&Place heads. It is

thus a high-speed placement

machine that combines a

high placement rate with

placement accuracy and

flexibility.

During placement, the place-

ment heads fetch the compo-

nents from the at-rest

component supply, and set

them down on the PCB,

which is also stationary. This

proven SIPLACE principle

guarantees reliable pick-up

of even the smallest compo-

nents, prevents the compo-

nents slipping on the PCB and

minimizes traversing paths.

Other highlights of the

SIPLACE D4 at a glance:

Optimized transport con-

ditions with the flexible

dual conveyor

The user also has access to

different variants of the PCB

conveyor: SIPLACE single

conveyor and flexible

SIPLACE dual conveyor. The

latter offers all the benefits of

the conventional dual con-

veyor, such as reducing non-

productive downtimes, com-

bined with the option of

using the single conveyor.

01005 placement

Even the trend towards com-

ponent miniaturization is no

problem for the SIPLACE D4

since it is equipped as stan-

dard to place 01005 compo-

nents. To do this, you simply

have to implement the optio-

nal 01005 package for

12-nozzle Collect&Place

heads. You can then process

even the tiniest components

currently available without

any problems.
