Depending upon the length of the system, the c ooling tract in the Vision X C nitr o is laid out in 1- to 4 stages. The f ans in the individual zones, which can be c ontr oll ed sepa - ratel y as an option, allow for ac …
Depending upon the length of the
system, the cooling tract in the
VisionXC nitro is laid out in 1- to 4
stages. The fans in the individual
zones, which can be controlled sepa-
rately as an option, allow for accurate
control, and cooling gradients can
be correspondingly inuenced. This
assures stress-free cooling for your
PCBs, for lead-free soldering as well.
Due to our secure transport system
and the arrangement of the transport
mechanism outside of the process
chamber you receive a stabile process
while reducing maintenance expenses
and machine downtime.
The optionally available centre sup-
port makes it possible to process
large panel formats – an additional
advantage for exible manufacturing!
The Transport System
Heat transfer has been signicantly
optimized for the VisionXC through
the use of two, three or four peak
zones. Minimal distance between
the nozzle panels and the conve-
yor, as well as separately adjustable
ow rates for the upper and lower
heating zones, assure that the PCBs
are heated up in an extremely uniform
fashion. Stressing within the PCBs is
thus minimized, and related soldering
defects are reduced.
Ideal heat transfer
Smallest ΔT
Stress-free cooling
The Cooling Zone
Single lane transport with
center board support
Simply. More. Reliability. Simply. More. Experience.
Single Lane Transport Center Board Support
The reliable Reow Soldering System
for your production!
VisionXC
THERMAL SYST EMS
A reliable transport system
for highest process stability!
Cooling zone VisionXC nitro
Residues which accumulate during
soldering are separated by a new
Residue Management System inclu-
ded in VisionXC systems. Depending
on the system length it is equip-
ped with a 1 up to 3-stage Residue
Management System. Each stage
consists of a cooling and a lter unit.
With this combination liquid and
crystalline residues can be drastically
reduced. Out of this you gain the big
advantage of a lower rate of main-
tainance intervals and a higher ef-
ciency in working.
Residue
Management System
optimal cleaning
reduced maintenance expenses
easy accessibility
integrated in the oven
Cooler
Filter
Cooling zone
Best thermal Performance
for best soldering results!
Transport mechanism
The menu of the Visu2-Software is clearly
structured and intuitively. This avoids
faulty operations and a better workow
can be achieved.
Online Documentation
Extensive documentations (operating
instructions, service instructions, wir-
ing plan, etc.) are stored directly on the
system computer and can be recalled in a
comfortable and quick way.
With the Visu2-Software you can set opti-
mally the rights for different user groups,
e.g. for administrators, supervisors and
users.
More Tools
+ Multilingual Software
+ Data recording
+ Protocol Import/Export
+ Maintenance log
User Friendliness User Levels
Visu 2 - The User-friendly Software
