2 Safety
2.2 Warning labels
26 Instruction Guide ASM ProcessLens 02/2017
2.2.3.5 Warning label W 209
Fig.14: W 209 [03009349-xx] (quantity per machine: 1)
For Australia, Canada, Mexico and USA, warn-
ing label W 209 is affixed to the extension kit in-
stead of the yellow ring on the EMERGENCY
STOP buttons.
See fig. "Warning labels front view" [}18]
2.2.3.6 Warning label W203
Fig.15: W203 [03009342-xx] (quantity per machine: 4)
Danger of Crushing
Reaching in here can lead to injuries to the
arms and hands.
Do not reach into the machine while it is run-
ning.
See fig. "Warning labels front view" [}18] and "Warning labels back view" [}19]
2.2.3.7 Warning label W204
Fig.16: W204 [03009343-xx] (quantity per machine: 2)
Danger of Crushing
Reaching in here can lead to injuries to the
arms and hands.
Do not reach into the machine while it is run-
ning.
See fig. "Warning labels - front view - inside - part 1" [}20]
2.2.3.8 Warning label W206
Fig.17: W206 [03009345-xx] (quantity per machine: 2)
Dangerous Voltages
The parts behind the cover are still live when
the main power switch is off.
The machine must be disconnected from the
mains before servicing it.
NAFTA region: Risk of electric shock or
burn
See fig. "Warning labels - Power supply unit and voltage distribution board" [}22]
2 Safety
2.2 Warning labels
Instruction Guide ASM ProcessLens 02/2017 27
2.2.3.9 Warning label P010 - Do Not Touch
Fig.18: Do not touch label (quantity per machine: 1)
Do not touch!
Do not touch the optical module.
See fig. "Warning labels - front view - inside - part 1" [}20]
2.2.3.10 Warning label HS - Hot Surface
Fig.19: Hot surface label [03031926-xx] (quantity per
machine: 1)
RISK OF BURNS FROM HOT SURFACE!
The protective cover of the power supply unit
can become hot during continuous operation.
► Take care when touching the protective
cover of the power supply unit.
See fig. "Warning labels - Power supply unit and voltage distribution board" [}22]
2.2.3.11 Warning label PSUC - Power Supply Unit Cover
Fig.20: Warning label for power supply unit cover [03113903-xx] (quantity per machine: 1)
See fig. "Warning labels - Power supply unit and voltage distribution board" [}22]
2.2.3.12 Warning label - General warning/attention
Fig.21: Warning label - General warning/attention
[03079298-xx] (quantity per machine: 1)
General warning/attention
Risk of part damage if cover is removed!
See fig. "Warning labels - Conveyor" [}23]
2 Safety
2.2 Warning labels
28 Instruction Guide ASM ProcessLens 02/2017
2.2.3.13 Warning label - Sensitive conveyor side
Fig.22: Warning label - Sensitive conveyor side
[03110412-xx] (quantity per machine: 2)
Sensitive conveyor side
The conveyor sides are highly sensitive and
may not be moved unless the brakes have been
released.
Moving the sides without releasing the brakes
can cause irreparable damage to the conveyor
sides.
See fig. "Warning labels - Conveyor" [}23]
2.2.3.14 Warning label - Support pins 94 mm
Fig.23: Warning label - Support pins 94 mm [00368570-
xx] (quantity per machine: 2)
Support pins 94 mm
Risk of damage to PCBs if wrong support pins
are used.
See fig. "Warning labels - Conveyor" [}23]
2.2.3.15 Warning label - Entanglement hazard
Fig.24: Warning labels - Entanglement hazard
[03136855-xx] (quantity per machine: 5)
Moving belt hazard
Reaching into the machine can lead to injuries
to the arms and hands from skin and clothing
contact.
► Do not reach into the machine while it is
running.
See fig. "Warning labels - Conveyor" [}23]
