2|Technical data
2 Technical data
2.1 Technical data of the entire system................................................................................................................26
2.1.1 General system data*.......................................................................................................................26
2.1.2 Pneumatics .......................................................................................................................................26
2.1.3 Protective gas technology (nitrogen) ...............................................................................................26
2.1.4 Extraction capacity ...........................................................................................................................26
2.1.5 Ambient conditions ..........................................................................................................................26
2.1.6 Safety devices ...................................................................................................................................27
2.1.7 Electrical data of the entire system ..................................................................................................27
2.1.7.1 Connection data* ...........................................................................................................27
2.2 Technical data of the single units.................................................................................................................... 27
2.2.1 Spray fluxer.......................................................................................................................................27
2.2.2 Bottom pre-heating, dynamic radiator cassette...............................................................................28
2.2.3 Top pre-heating, compressed air heater (option) ............................................................................28
2.2.4 Point and path soldering module .....................................................................................................29
2.2.5 Solder feeding: Point and path soldering module ............................................................................29
2.2.6 Single-track conveyor system ...........................................................................................................29
2.2.7 Available optionals ...........................................................................................................................31
Ersa GmbH Operating Instructions_VF366_en|Rev. 14|30/11/2017 25/551
2|Technical data
2.1 Technical data of the entire system
2.1.1 General system data*
Description
Length (mm) 2950
Width (mm) 1900
Height (mm) 1540
Height, hood open (mm) 2060
Weight (kg) 1700
Paint finish RAL 7035 / RAL 7016
*The technical drawings for this machine can be found in the annex of this operat-
ing manual.
2.1.2 Pneumatics
Designation
Minimum input pressure (bar) 6
Maximum air consumption (m
3
/h) 5
Required connection (hose) NW8
2.1.3 Protective gas technology (nitrogen)
Description
Minimum inlet pressure (bar) 6
Inert gas supply to the point and path
soldering module approx. (l/min)
25
Recommended degree of purity (equi-
valent to a degree of purity of 99.999%
or max. 10 ppm of other gases).
5.0
Nitrogen consumption per point and
path soldering module approx.(m
3
/h)
2
Nitrogen consumption per DIP soldering
module approx.(m
3
/h)
25
Required connection (hose) NW 8
2.1.4 Extraction capacity
Description
Exhaust support (piece / Ø mm) 2 / 150
Total suction capacity approx. (m
3
0h 450
* Depending on the particular configuration level. The actual values can be found in
the annex to these operating instructions.
2.1.5 Ambient conditions
Description
Ambient temperature (°C) 10…35
