2|Technical data 2.2.7 Available optionals X = Standard O = Optional Automatic solder feeder O Solder wave height measurement X Segmented conveyor X Process monitoring with camera O Network capability O Remote maintena…
2|Technical data
Description
Recommended distance of the nozzle
from the board (mm)
1…1.5
Positioning accuracy of the board (mm) ± 0.2
1
No superstructures and substructures must be fitted in a 3 mm edge area!
2
Optionals are possible up to 60 mm.
Ersa GmbH Operating Instructions_VF366_en|Rev. 14|30/11/2017 30/551
2|Technical data
2.2.7 Available optionals
X = Standard
O = Optional
Automatic solder feeder O
Solder wave height measurement X
Segmented conveyor X
Process monitoring with camera O
Network capability O
Remote maintenance O
Centre support in the soldering module O
Soldering material hold-down system O
Top compressed air heater O
Code reader (barcodes) O
Code reader (matrix) O
Bottom preheater, dynamic IR emitter
cassette
X
Door and window interlocking system
(process reliability)
O
CAD assistant O
Ersa GmbH Operating Instructions_VF366_en|Rev. 14|30/11/2017 31/551
2|Technical data
Ersa GmbH Operating Instructions_VF366_en|Rev. 14|30/11/2017 32/551
