7 Screwed joint 7.1 Replacing the cover cap and grommet Service Manual SIPLACE SpeedStar (C&P20 P2) 01/2019 55 7 Screwed joint 7.1 Replacing the cover cap and grommet Parts 03134712-xx Cover cap 03159288-xx Grommet f…
6 Aperture ring, holding circuit and silencer
6.4 Replacing the placement circuit hose
54 Service Manual SIPLACE SpeedStar (C&P20 P2) 01/2019
Installation
► Cut the new hose to a length of 45 +/- 1mm.
► Follow the removal instructions in reverse order for further installation.
Also observe the installation instructions in the following section:
5.2 "Replacing the pressure control valve (PRV)" [}41]
► Observe in particular the torques specified!
7 Screwed joint
7.1 Replacing the cover cap and grommet
Service Manual SIPLACE SpeedStar (C&P20 P2) 01/2019 55
7 Screwed joint
7.1 Replacing the cover cap and grommet
Parts
03134712-xx Cover cap
03159288-xx Grommet for star motor SIPLACE C&P20P2
Equipment and tools
T44 00386132-xx Torque screwdriver ESD 0.1-0,6 Nm
T96 03171858-xx Torque Allen swap blade 1.5 mm TX6
T --- Tools for removing/fitting and calibrating the placement head, if needed
(see also the service manual for your machine)
Preparation
► Remove the head from the machine. For details about removing and fitting the placement
head, refer to the service manual for your machine.
Fit the head on the head mount [03056231‑xx].
► Make sure that the component sensor protective cap is fitted.
1.1.3 "Safety instructions for the component sensor" [}6]
Removal
Fig.71: Cover cap
► Remove the four fastening screws
(TX6) and then remove the cover
cap(1).
Fig.72: Cover cap and grommet
► Remove the grommet(1) from the
cover cap (2).
7 Screwed joint
7.1 Replacing the cover cap and grommet
56 Service Manual SIPLACE SpeedStar (C&P20 P2) 01/2019
Installation
Fig.73: Inserting the grommet
CAUTION!
The grommet may not be greased.
.
► There are four small studs on the grom-
met. Insert the grommet so that these
studs point downwards.
Fig.74: Cover cap
► Fasten the cover cap(1) into place with
four screws (TX6, M2x5, torque
0.3Nm).
