Page 1-58 444C-E-MMA01-A07-02 Check Every 140 Hours (Once a Week) 11 . Close the safety cover . 12. T urn ON the servo switch. 13. Press Z axis . 14. Press UNLOCK + Continuous moving . • The Z-axis ball screw of the head…
Page 1-57
REGULAR
MAINTENANCE
1
Check Every 140 Hours (Once a Week)
444C-E-MMA01-A07-01
10. Lubricate the X-axis linear bearing
and X-axis ball screw on the front and
rear sides through the grease nipple.
[Grease : SHELL STAMINA GREASE RL2]
444C-418E
X-axis ball screw
Linear bearing
4H4C-511P
CM201-DH, CM202-DH/DHU/DK
444C-418E
X-axis ball screw
Linear bearing
444C-524P
CM201-DS, CM202-DS
To the next page
Page 1-58
444C-E-MMA01-A07-02
Check Every 140 Hours (Once a Week)
11. Close the safety cover.
12. Turn ON the servo switch.
13. Press Z axis .
14. Press
UNLOCK
+ Continuous moving .
• The Z-axis ball screw of the head repeats to go
back and forth at full stroke, and spreads the
grease over whole area of it.
15. Press X axis .
16. Press
UNLOCK
+ Continuous moving .
• The X-axis repeats to go back and forth at full
stroke, and spreads the grease over whole of
ball screw and linear bearing.
17. Press Y axis .
18. Press
UNLOCK
+ Continuous moving .
• The Y-axis repeats to go back and forth at full
stroke, and spreads the grease over whole of
ball screw and linear bearing.
OFF ( )
ON ( )
SERVO
2
1
2
1
2
1
Page 1-59
REGULAR
MAINTENANCE
1
Check Every 140 Hours (Once a Week)
1-4-7 Cleaning the Line Camera Lens
If such as chips and dust adhere to the lens of the line camera, a nozzle looks as if it tapered or a
recognition error of chip components can occur.
1. Turn OFF the power supply.
∗ Because the cooling fan located under the
lighting is rotating, turn OFF the power supply.
2. Open the safety cover.
3. Ensure that the head and nozzle do
not lower. While holding the center of
the beam, press it inside gently.
4. Blow away the dust from between the
illumination and the line camera by
using the blower brush.
• Blow away the dust from the left side or the
front side.
Tools Blower brush Required time 5 minutes
OFF ( )
ON ( )
SERVO
444C-490P
Blower brush
444C-E-MMA01-A08-06
5. Wind a cloth around a stick or such a
thin plate as a ruler, and then wipe the
lens face.
∗ At this time, removing the NG chip discharge
box and its mount will make this work easy.
6. Clean the lighting cover glass.
∗ If the inside of the cover glass of the lighting is
heavily stained, detach the black lighting cover,
remove the cover glass holder, and then wipe
the inside of the glass with a cloth. (Be careful
not to apply forces to the glass.)
444C-518P
444C-519P
