Page 28
SAFETY PRECAUTIONS
Be sure to observe
CM202-D/DU (Danger labels)
The following danger labels are pasted on this machine. Follow the instructions on each label. If a label has
come off, put a new one on a proper position. To order a label from the manufacturer, refer to PARTS LIST.
Label part No.
The positions of danger labels on the front side
M32E
0 1 J Q B
feeder tables will have
serious injury.
444C-E-XXA00-A04-01
4Q4C-901E
The labels for safety pasted on the product
The positions of danger labels on the rear side
4Q4C-902E
0 1 K 1 B
DANGER
DO NOT OPEN
THE COVER
WHEN
OPERATING
You will have serious
injury if you touch the
active part inside.
0 1 K 1 B
DANGER
DO NOT OPEN
THE COVER
WHEN
OPERATING
You will have serious
injury if you touch the
active part inside.
0 1 J X A
DANGER
DO NOT TOUCH
ACTIVE PART
WHEN
OPERATING
You will have serious
injury if you touch the
active part.
0 1 J X A
DANGER
DO NOT TOUCH
ACTIVE PART
WHEN
OPERATING
You will have serious
injury if you touch the
active part.
(As for the explanation, the illustration of CM202-DU is used.)
Page 29
SAFETY PRECAUTIONS
Be sure to observe
CM202-DH/DHU/DK(Danger labels)
The following danger labels are pasted on this machine. Follow the instructions on each label. If a label has
come off, put a new one on a proper position. To order a label from the manufacturer, refer to PARTS LIST.
Label part No.
The positions of danger labels on the front side
M32E
0 1 J Q B
feeder tables will have
serious injury.
444C-E-XXA00-A04-01
4U4C-AA00
The labels for safety pasted on the product
The positions of danger labels on the rear side
4U4C-AB01
0 1 K 1 B
DANGER
DO NOT OPEN
THE COVER
WHEN
OPERATING
You will have serious
injury if you touch the
active part inside.
0 1 K 1 B
DANGER
DO NOT OPEN
THE COVER
WHEN
OPERATING
You will have serious
injury if you touch the
active part inside.
0 1 J X A
DANGER
DO NOT TOUCH
ACTIVE PART
WHEN
OPERATING
You will have serious
injury if you touch the
active part.
0 1 J X A
DANGER
DO NOT TOUCH
ACTIVE PART
WHEN
OPERATING
You will have serious
injury if you touch the
active part.
(As for the explanation, the illustration of CM202-DH is used.)
Page 30
SAFETY PRECAUTIONS
Be sure to observe
0 A 5 F B
WARNING
TAKE CARE NOT
TO TOUCH CUTTER
You will have serious
injury if you touch
cutter.
CM201-D (Warning labels)
The following warning labels are pasted on this machine. Follow the instructions on each label. If a label has
come off, put a new one on a proper position. To order a label from the manufacturer, refer to PARTS LIST.
Label part No.
The positions of warning labels on the front side
0 1 J Q B
feeder tables will have
serious injury.
The labels for safety pasted on the product
444C-441E
The positions of warning labels on the rear side
0 1 N M B
WARNING
WORKER
OPERATING
IN THE BACK
Make sure that no
worker is in the back
when machine
starting.
444C-442E
0 1 N L B
WARNING
WORKER
OPERATING
IN THE FRONT
Make sure that no
worker is in the front
when machine
starting.
0 1 N C B
WARNING
ELECTRIC
SHOCK
You will have serious
electric shock if you
touch electric active
part inside.
0 1 N C B
WARNING
ELECTRIC
SHOCK
You will have serious
electric shock if you
touch electric active
part inside.
A
444C-126E
Figure seen from A
444C-129E
Figure seen from B
0 1 P 9 B
WARNING
DO NOT DISABLE
SAFETY SENSOR
You will have serious
injury by active part
if you disable safety
sensor.
B
0 1 P 9 B
WARNING
DO NOT DISABLE
SAFETY SENSOR
You will have serious
injury by active part
if you disable safety
sensor.
444C-E-XXA00-A04-02
0 A 5 F B
WARNING
TAKE CARE NOT
TO TOUCH CUTTER
You will have serious
injury if you touch
cutter.
