Page 49 444C-E-XXA00-A05-00 Maintenance position This manual is for CM201 and CM202 in common. The operating procedure is mainly described for CM202 AF . Basically , carry out the same maintenance as CM202 AF for CM202 B…
Page 48
∗ For further information about the specification, see “1-3 Equipment Specification” in the Operating Manual.
444C-E-XXA00-A05-00
HOW TO SEE DESCRIPTION FOR OPERATION
CM202-DH/DK
Front view Rear view
4U4C-AA00
4U4C-AB01
External view Features
Front view
4U4C-901EU
Rear view
4U4C-902EU
CM202-DHU
Conveyor cover
It has two sets of mounting stage.
• It mounts two boards at the same time.
• Up to 104 feeders can be set.
444C-102E
NOTICE
It is dangerous to operate the DU and the DHU while the feeder base cover and the
conveyor cover are removed.
Be sure to set the feeder base cover and the conveyor cover during operation.
CM201-DH/DS
Front view Rear view
It has a set of mounting stage.
• It mounts boards one by one.
• Up to 52 feeders can be set.
444C-101E
E14C-AA00
E14C-AB00
CM202-DS
Front view
Rear view
E24C-AA00
E24C-AB01
( The illustration of CM201-DH is used.)
Page 49
444C-E-XXA00-A05-00
Maintenance position
This manual is for CM201 and CM202 in common.
The operating procedure is mainly described for CM202 AF. Basically, carry out the same
maintenance as CM202 AF for CM202 BF, AR, and BR and CM201 AF and AR.
HOW TO SEE DESCRIPTION FOR OPERATION
Remarks
They do not depend on a line flow
direction.
They depend on a line flow direction.
At the upstream line, H1 and H2 are shown.
CM202
CM201
444C-422E
A stage
Rear side
Front side
B stage
AR
BR
AF
BF
A stage
Rear side
Front side
444C-423E
AR
AF
444C-120E
444C-120E
444C-120E
444C-119E
444C-121E
444C-119E
or
or
or
Flow direction
Machine display
Screen display
Left to Right
Right to Left
Page 50
444C-E-XXA00-A05-00
= MEMO =
