5 Tasks for the operating personnel User manual SIPLACE D4i
5.5 Carrying out a walk-through inspection From software version SR.605.03 SP2 10/2012 EN edition
200
5.5.2 Splicing the tapes in good time
PLEASE NOTE:
Splice the tapes early enough so that the feeder modules do not run out of components. Oth-
erwise you will experience prolonged down times.
However, do not splice the tapes too early because if you wind the end of the old tape onto
the new reel after splicing, the reel holding the new tape may become overfilled and the tape
will slip off the reel and become tangled up. This will again result in pick-up errors and pro-
longed down times. 5
5.5.3 Checking the PCB supports
→ Check the position of the magnetic PCB supports on the lifting table:
– Make sure that the PCB supports do not collide with components on the underside of the
PCBs.
– In addition, make sure that the PCB supports do not collide with the PCB conveyor panels.
– Only use PCB supports as described in Section 6.7
, page 233.
5.5.4 Inserting separating plates in the tape container
→ The separating plate has different edges and can be inserted into the tape container in two
ways. If spindles are used, the recesses for the spindles in the separating plate point upwards
(see item . 6 in Fig. 5.5 - 2
, page 201). If you do not use spindles, the rounded edge of the
separating plate points upwards (see item 5 in Fig. 5.5 - 2
, page 201).
→ Insert the separating plates as shown in Fig. 5.5 - 2
, page 201 and remember that the smallest
division of the tape container is a 2x division. This will help avoid placement errors.
→ Check that the separating plates engage in the same positions on the three guide rails. Oth-
erwise the separating plate will be offset or bent.
User manual SIPLACE D4i 5 Tasks for the operating personnel
From software version SR.605.03 SP2 10/2012 EN edition 5.5 Carrying out a walk-through inspection
201
5
Fig. 5.5 - 2 Separating plates in the tape container
(1) Guide rail for the separating plates
(2) Tape container
(3) Waste tape container
(4) Position of the separating plate if no spindles are used
(5) Position of the separating plate if spindles are used
5 Tasks for the operating personnel User manual SIPLACE D4i
5.5 Carrying out a walk-through inspection From software version SR.605.03 SP2 10/2012 EN edition
202
5.5.5 Using spindles for large tape reels
→ Insert spindles into the separating plates when using large tape reels.
PLEASE NOTE 5
We recommend that you use spindles if the tape reel diameter exceeds 15" (381 mm). This will
ensure that the feeder modules operate reliably.
5
Fig. 5.5 - 3 Inserting spindles for large reels
5
(1) Component trolley
(2) Position of the spindles
(3) Separating plate
(4) Spindle (enlarged)
