User manual SIPLACE D4i 5 Tasks for the operating personnel From software version SR.605.03 SP2 10/2012 EN edition 5.8 Avoiding track errors 207 5.8 A voiding track errors 5.8.1 General → Make sure that the areas aro und…
5 Tasks for the operating personnel User manual SIPLACE D4i
5.7 Changing the set-up From software version SR.605.03 SP2 10/2012 EN edition
206
5.7 Changing the set-up
5.7.1 Printing out the conversion instructions before changing the set-up
Before a change of set-up, print out the conversion instructions on the printer for the SIPLACE Pro
computer as described in the "SIPLACE Pro" manual or in the online help.
5.7.2 What you should note when changing the feeder modules
→ Handle the feeder modules carefully when you insert them into or remove them from the com-
ponent table. Make sure that the X feeder modules do not bump against the edges of the com-
ponent table.
→ Vacuum the supporting surfaces of the feeder modules and clean the surface of the compo-
nent table when necessary according to the instructions in the preventive maintenance man-
ual.
CAUTION
Avoid removing components from the magnetic rail of the component table with the fingers.
You may injure yourself through contact with the finest metal splitter. 5
→ Remove loose components using a brush or a vacuum cleaner with a suitable nozzle.
User manual SIPLACE D4i 5 Tasks for the operating personnel
From software version SR.605.03 SP2 10/2012 EN edition 5.8 Avoiding track errors
207
5.8 Avoiding track errors
5.8.1 General
→ Make sure that the areas around the feeder modules are clean and that there are no loose
components in the feeder area or under the feeder modules.
→ Ensure that the supporting surfaces of the feeder modules, and particularly the magnetic rails
of the component tables, are clean and level.
→ Refill promptly with components.
→ Splice the tapes early. This generally means that you are to prepare the splicing material
when there is still approximately 1.5 m of tape on the reel.
→ Handle the feeder modules carefully when you insert them into or remove them from the com-
ponent table as these are high-precision devices.
→ Close the pick-up window on the feeder module as it could easily be damaged if you leave it
open.
→ Check that the pick-up position is set correctly for the components on the S feeder modules.
→ Check that the S feeder module plugs are connected to the right sockets.
5.8.2 Avoiding track errors with the tape container
→ Insert the separating plates correctly (see Fig. 5.5 - 2, page 201).
→ Tape reels with a diameter of 15" (381 mm) or more should be stored on spindles.
→ When using type 3 x 8 mm S feeder modules make sure to use the second level reel holder
for the middle tape reel (see Section 3.10.7
, page 139).
5 Tasks for the operating personnel User manual SIPLACE D4i
5.8 Avoiding track errors From software version SR.605.03 SP2 10/2012 EN edition
208
5.8.3 Component coordinate system and pick-up angle
5
Fig. 5.8 - 1 Position of the component and its pick-up angle
Special
component
Stick
magazine:
Chip-
components
with polarity
0402
2220
The anode must be
aligned with the +X
coordinate.
Package form Coordinate system
Position in the feeder module
Pick-up angle/
nozzle angle
Tape:
SOT 23
Stick
magazine:
Tape:
Tape:
SO-IC
DIL-IC
SOT 194
Tape:
Holes
Y
X
Y
X
Y
X
Y
X
Y
X
90°
90°
0°
90°
-90°
0°
