9. Troubleshooting
9.1 Starting Guidance
Table 8
Machine Information
Codes
Display Field A (Scope of Machine Information)
Display Field B (Details of Machine Information)
013901 Flux spread equipment un-carrying (rear).
Please set the flux spread equipment (rear) used by the pattern program.
013A01 Flux spread equipment un-carrying (front).
Please set the flux spread equipment (front) used by the pattern program.
9.2 Error IDs and Remedial Procedures
9.2.1 Others
Table 9
Error ID Error Name, Description, Cause, and Remedy
4b1001 Flux spread error
The flux spread was not completed within prescribed time.
Please remove and check flux spread equipment.
4b1002 Flux spread equipment error
Motor alarm was generated.
Please remove and check flux spread equipment.
9.2.2 Automatic Operation Error
Table 10
Error ID Error Name, Description, Cause, and Remedy
510c01 Auto Run Error
Comp. Missing (Recog.)
Since the picked-up components may have fallen on the turntable of flux spread
equipment, please check it.
