MAINTENANCE PARTS LIST
KJD-0803(MPL)
Auto Tray Stacker (for R-type)
Safety.
To replace the purchased parts safely, be sure to comply with the following items.
However the following cannot cover all items regarding safety in detail. So it is
extremely important that the worker or person handling the machine make correct
decisions regarding safety.
CAUTION Machine operation of operator•Work is limited to maintenance and
safety skill.
Be sure to turn off the machine’s power supply and remove the air coupler before
doing the exchange work.
Be sure to push the emergency stop SW, and do adjustment work under the
emergency stop condition.
Refer to the maintenance manual for the replacement work of each consumable
part.
* Safety alert symbols and signal words
CAUTION
Indicates a potentially hazardous situation which, if not avoided, may result in minor
injury, or material loss or damage to the machine. These points are important for
protecting the safety of the machine and data, etc.
Level column
Make use of these as reference, “
•
r
•×”, as mentioned in the Level column.
“
” It is based on taking the basic maintenance training, and being able to do
equal work.
“
” Please contact our company service when it is judged that the customer’s
condition difcult.
From the problem that arises from these, we cannot assume responsibility such as
accidents.
Note
Rank A : The functions of these parts gradually deteriorate with operating time.
Rank B : The machine stops immediately if the functions of these parts are disabled.
Rank C : The machine still operates even if the functions of these parts are disabled,
because there are many parts.
Rank E : The functions of consumable part gradually deteriorate with operating time.
/ : Maintenance is excluded (The screws are also equal, display is omitted)
Q’ty : The number of parts used for the machine.
Level
: Aims to undergo basic maintenance training and have the capability to do the
job.
Level
r
: Yamaha Corp. aims to render exclusive training
Level
Í
: Yamaha Corp. Service Engineering
Contents
KJD-0803
4
Magazine Section
Magazine Assy. ..........................................
4-1
5
Hook Section
Hook-axis Assy. ..........................................
5-1
6
Base / System Parts Section
Base / System Parts ....................................
6-1
1
Cover Section
Cover Assy. ................................................
1-1
2
Z-axis Section
z-axis Assy. .................................................
2-1
3
Rack Section / Pallet Section
Rack Assy. / Pallet Assy. .............................
3-1
