Appendix 1. Cable and Connector Specifications A1 - 13 Connectors for detector and motor power (IP67 and EN standard compatible) Straight plug Manufacturer: DDK (Ltd.) D or less 7.85 or m ore W A øC ± 0.8 -0.38 +0 øB [Un…
Appendix 1. Cable and Connector Specifications
A1 - 12
Appendix 1-3 Connector outline dimension drawings
Connector for CN2 Servo drive unit
Manufacturer: 3M (Ltd.)
<Type>
Connector: 10120-3000VE
Shell kit: 10320-52F0-008
[Unit: mm]
22.0
39.0
33.3
12.7
14.0
23.8
12.0
10.0
Manufacturer: 3M (Ltd.)
<Type>
Connector: 10120-3000VE
Shell kit: 10320-52A0-008
[Unit: mm]
22.0
3
9
.
0
33.3
2
3
.
8
12.7
14.0
12.0
1
0
.
0
Manufacturer: 3M (Ltd.)
<Type>
Connector: 10120-6000EL
Shell kit: 10320-3210-000
Because this connector is an
integrated molding part of the cable,
it is not an option setting in the
connector set.
The terminal connector (A-TM) also
has the same outline.
[Unit: mm]
20.9
29.7
33.0
42.0
11.5
22.0
14.0
12.0
33.3
12.7
39.0
23.8
10.0
12.0
10.0
14.0
22.0
33.3
12.7
23.8
39.0
11.5
42.0
33.0
20.9
29.7
Appendix 1. Cable and Connector Specifications
A1 - 13
Connectors for detector and motor power (IP67 and EN standard compatible)
Straight plug
Manufacturer: DDK (Ltd.)
D or less
7.85 or m ore
W
A
øC
±
0.8
-0.38
+0
øB
[Unit: mm]
Type A B C±0.8
D or less
W
CE05-6A18-12SD-B-BSS
1
1
/
8
-18UNEF-2B 34.13 32.1 57 1-20UNEF-2A
CE05-6A22-23SD-B-BSS
1
3
/
8
-18UNEF-2B 40.48 38.3 61 1
3
/
16
-18UNEF-2A
CE05-6A24-10SD-B-BSS
1
1
/
2
-18UNEF-2B 43.63 42.0 68 1
7
/
16
-18UNEF-2A
CE05-6A32-17SD-B-BSS
2-18UNS-2B 56.33 54.2 79 1
3
/
4
-18UNS-2A
Angle plug
Manufacturer: DDK (Ltd.)
D or less
R
±
0.7 U
±
0.7
(S)
±
1
Y or more
W
A
-0.38
+0
ø B
[Unit: mm]
Type A B D or less W R±0.7 U±0.7 (S) ±1
Y or
more
CE05-8A18-12SD-B-BAS
1
1
/
8
-18UNEF-2B 34.13 69.5 1-20UNEF-2A 13.2 30.2 43.4 7.5
CE05-8A22-23SD-B-BAS
1
3
/
8
-18UNEF-2B 40.48 75.5 1
3
/
16
-18UNEF-2A 16.3 33.3 49.6 7.5
CE05-8A24-10SD-B-BAS
1
1
/
2
-18UNEF-2B 43.63 86.3 1
7
/
16
-18UNEF-2A 18.2 36.5 54.7 7.5
CE05-8A32-17SD-B-BAS
2-18UNS-2B 56.33 93.5 1
3
/
4
-18UNS-2A 24.6 44.5 61.9 8.5
Cable clamp
Manufacturer: DDK (Ltd.)
(Moveable range of one side)
øE
(Cable clamp inside
diameter
)
H
G
±
0.7
A
V screw
C
1.6
(Bushing inside
diameter)
øF
(D)
B
±
0.7
[Unit: mm]
Total
length
Outside
dia.
Effective
screw
length
Type
Shell
size
A B C D E F G H
Installation
screw
V
Bushing
Compliant
cable
CE3057-10A-2 (D265)
18 23.8 30.1 10.3 41.3 15.9 11 31.7 3.2 1-20UNEF-2B CE3420-10-2 ø8.5 to ø11
CE3057-12A-2 (D265)
20 13 CE3420-12-2 ø9.5 to ø13
CE3057-12A-3 (D265)
22
23.8 35 10.3 41.3 19
10
37.3 4 1
3
/
16
-18UNEF-2B
CE3420-12-3 ø6.8 to ø10
CE3057-16A-2 (D265)
24 26.2 42.1 10.3 41.3 23.8 15.5 42.9 4.8 1
7
/
16
-18UNEF-2B CE3420-16-2 ø13 to ø15.5
CE3057-20A-1 (D265)
32 27.8 51.6 11.9 43.0 31.7 23.8 51.6 6.3
1
3
/
4
-18UNS-2B
CE3420-20-1 ø22 to ø23.8
+0
-0.38
+0
–0.38
Appendix 1. Cable and Connector Specifications
A1 - 14
Connectors for detector, motor power and brake (IP67 and EN standard compatible)
Straight plug
Manufacturer: DDK (Ltd.)
-0.25
+0.05
øG
J
±
0.12
E±0.3
C±0.5
Gasket
D
H or less
A
-0.38
+0
øB
[Unit: mm]
Type A B C±0.5 D E±0.3 G J±0.12
MS3106A10SL-4S (D190)
5
/
8
-24UNEF-2B 22.22 23.3
9
/
16
-24UNEF-2A 7.5 12.5 13.49
MS3106A22-14S (D190)
1
3
/
8
-18UNEF-2B 40.48 34.11 1
1
/
4
-18UNEF-2A 12.15 29.9 18.26
Straight back shell
Manufacturer: DDK (Ltd.)
W screw
øC
øA
L
B
V screw
O-ring
7.85 or more
(Effective screw length)
D
(Spanner grip)
[Unit: mm]
Type L A B C D V W
CE02-22BS-S
35 36.5 10.9 17.8 32.4 1
1
/
4
-18UNEF-2B 1
3
/
16
-18UNEF-2A
Angle back shell
Manufacturer: DDK (Ltd.)
Type: CE-22BA-S
[Unit: mm]
ø38.6
50.5 or less
39.6 or less
16.3
(49.6)
7.5 or more
33.3
1
1
/
4
-18UNEF-2B screw
1
3
/
16
-18UNEF-2A screw
O-ring
