Appendix 1. Cable and Connector Specifications A1 - 15 Connectors for detector, motor power and brake (for general environment) Straight plug Manufacturer: DDK (Ltd.) W or more L or less J ±0.12 A V Y or less -0.38 +0 øQ…
Appendix 1. Cable and Connector Specifications
A1 - 14
Connectors for detector, motor power and brake (IP67 and EN standard compatible)
Straight plug
Manufacturer: DDK (Ltd.)
-0.25
+0.05
øG
J
±
0.12
E±0.3
C±0.5
Gasket
D
H or less
A
-0.38
+0
øB
[Unit: mm]
Type A B C±0.5 D E±0.3 G J±0.12
MS3106A10SL-4S (D190)
5
/
8
-24UNEF-2B 22.22 23.3
9
/
16
-24UNEF-2A 7.5 12.5 13.49
MS3106A22-14S (D190)
1
3
/
8
-18UNEF-2B 40.48 34.11 1
1
/
4
-18UNEF-2A 12.15 29.9 18.26
Straight back shell
Manufacturer: DDK (Ltd.)
W screw
øC
øA
L
B
V screw
O-ring
7.85 or more
(Effective screw length)
D
(Spanner grip)
[Unit: mm]
Type L A B C D V W
CE02-22BS-S
35 36.5 10.9 17.8 32.4 1
1
/
4
-18UNEF-2B 1
3
/
16
-18UNEF-2A
Angle back shell
Manufacturer: DDK (Ltd.)
Type: CE-22BA-S
[Unit: mm]
ø38.6
50.5 or less
39.6 or less
16.3
(49.6)
7.5 or more
33.3
1
1
/
4
-18UNEF-2B screw
1
3
/
16
-18UNEF-2A screw
O-ring
Appendix 1. Cable and Connector Specifications
A1 - 15
Connectors for detector, motor power and brake (for general environment)
Straight plug
Manufacturer: DDK (Ltd.)
W
or
more
L
or less
J
±0.12
A
V
Y
or less
-0.38
+0
øQ
[Unit: mm]
Coupling
screw
Length of
coupling section
Total
length
Connection
nut outside
diameter
Cable clamp
installation
screw
Effective
screw
length
Max.
width
Type
A J±0.12 L or less øQ V W or more Y or less
MS3106B18-12S
1
1
/
8
-18UNEF
18.26 52.37 34.13 1-20UNEF 9.53 42
MS3106B22-14S
MS3106B22-23S
1
3
/
8
-18UNEF 18.26 55.57 40.48 1
3
/
16
-18UNEF 9.53 50
MS3106B24-10S
1
1
/
2
-18UNEF
18.26 58.72 43.63 1
7
/
16
-18UNEF 9.53 53
MS3106B32-17S
2-18UNS
18.26 61.92 56.33 1
3
/
4
-18UNS 11.13 66
Angle plug
Manufacturer: DDK (Ltd.)
J
±0.12
L
or less
A
R
±0.5
U
±0.5
V
-0.38
+0
øQ
W or
more
[Unit: mm]
Coupling
screw
Length of
coupling
section
Total
length
Connectio
n nut
outside
diameter
Cable clamp
installation
screw
Effective
screw
length
Type
A J±0.12 L or less øQ R±0.5 U±0.5 V W or more
MS3108B18-12S
1
1
/
8
-18UNEF
18.26 68.27 34.13 20.5 30.2 1-20UNEF 9.53
MS3108B22-14S
MS3108B22-23S
1
3
/
8
-18UNEF 18.26 76.98 40.48 24.1 33.3
1
3
/
16
-18UNE
F
9.53
MS3108B24-10S
1
1
/
2
-18UNEF
18.26 86.51 43.63 25.6 36.5
1
7
/
16
-18UNE
F
9.53
MS3108B32-17S
2-18UNS
18.26 95.25 56.33 32.8 44.4 1
3
/
4
-18UNS 11.13
Straight plug
Manufacturer:
Japan Aviation Electronics (Ltd.)
Type: MS3106B10SL-4S
[Unit: mm]
ø 22.2
±0.8
13.5
±0.3
5
/
8
-24UNEF-2B
5
/
8
-24UNEF-2A
38.9
or less
Effective screw
length
(Including relief
of 2.77 or less)
9.5
or more
+0
–0.38
+0
–0.38
Appendix 1. Cable and Connector Specifications
A1 - 16
Connectors for detector, motor power and brake (for general environment)
Angle plug
Manufacturer:
Japan Aviation Electronics (Ltd.)
Type: MS3108B10SL-4S
[Unit: mm]
13.5
±0.3
ø22.2
±0.8
5
/
8
-24UNEF-2B
5
/
8
-24UNEF-2A
36.9±
0.8
46.0 or less
ø25.0
±0.8
9.5 or more
Cable clamp
Manufacturer: DDK (Ltd.)
øD (Cable clamp inside diameter)
øE (Bushing inside diameter)
F (Moveable range)
G±0.7
1.6
C
A
±0.7
V
øB±0.7
[Unit: mm]
Total
length
Outside
diameter
Effective
screw
length
Installation
screw
Type Shell size
A±0.7 øB±0.7 C øD øE F G±0.7 V
Bushing
MS3057-4A
10SL, 12S 20.6 20.6 10.3 7.9 5.6 1.6 22.2
5
/
8
-24UNEF
AN3420-4
MS3057-10A
18 23.8 30.1 10.3 15.9 14.3 3.2 31.7
1-20UNEF
AN3420-10
MS3057-12A
20, 22 23.8 35.0 10.3 19.0 15.9 4.0 37.3
1
3
/
16
-18UNEF
AN3420-12
MS3057-16A
24, 28 26.2 42.1 10.3 23.8 19.1 4.8 42.9
1
7
/
16
-18UNEF
AN3420-16
MS3057-20A
32 27.8 51.6 11.9 43 31.7 6.3 51.6
1
3
/
4
-18UNEF
AN3420-20
