Plan_HF3_14_20_en line 1电路 - 第166页
Pag e = + DL HF =HF +DL/3 2 Modificati on Date Na m e No rm Check. Proj. Origin Date Crea. f. Hot flow 3/xx 18 .0 6. 200 9 =HF +DL/1 133 953- V00 Ot to-Schott-Straße 5 97 87 7 W ertheim Gm bH Plant designation Pr oj e c …
Page
=
+ DL
HF
=HF+DL/2
1
Modification Date
Name Norm
Check.
Proj.
Origin
Date
Crea. f.
schb
Hotflow 3/xx
18.06.2009
=HF+DH/35
133953-V00
Otto-Schott-Straße 5
97877 Wertheim
GmbH
Plant designation
Project name
ERSA
14:15:2308.07.2010
cable overview
Cable overview
Cable designations Cable typePage/Path Length
Function text
Manufacturer
ø
DIN_KBU_35_ERSA_LS1
Cores article no.
=HF+C1-W3
=HF+C1/355.07 Phönix Kaufteil
5
0,34 124708 data-cable for programming
=HF+C1-W10
=HF+C1/25.02
LIYCY
4
0,14 6KADA04x0,14 supply meassuring energy
=HF+C1-WM10 =HF+C1/35.07 H05VV5-F
2
0,75 6KAÖL02X0,75N Supply lead fan switch cabinet
=HF+C1-1W1
=HF+C1/355.01 LD
2
0,22 6KADA02X0.22 CAN supply frequency inverter fans preheating top
=HF+C1-1WA1 =HF+C1/225.06 H05VVC4V5-K
4
1,50 6KAÖL04X1,50S frequency inverter fan preheating top
=HF+C1-3W1
=HF+C1/360.01 LD
2
0,22 6KADA02X0.22 CAN supply frequency inverter fans soldering zone
=HF+C1-3WA1 =HF+C1/260.06 H05VVC4V5-K
4
1,50 6KAÖL04X1,50S frequency inverter soldering zone 6 top
=HF+C1-4?WA1 =HF+C1/320.06 H05VVC4V5-K
4
1,50 6KAÖL04X1,50S frequency inverter fan soldering zone bottom side
=HF+C1-4W1
=HF+C1/360.04 LD
2
0,22 6KADA02X0.22 CAN supply frequency inverter fans soldering zone
=HF+C1-4WA1 H05VVC4V5-K
4
1,50 6KAÖL04X1,50S frequency inverter fan soldering zone bottom side
=HF+C1-7W1
=HF+C1/355.06 LD
2
0,22 6KADA02X0.22 CAN supply frequency inverter fans cooling zone
=HF+C1-7WA1 =HF+C1/345.01 H05VVC4V5-K
4
1,50 6KAÖL04X1,50S frequency inverter fan cooling zone
=HF+C1-9W1
=HF+C1/355.04 LD
2
0,22 6KADA02X0.22 CAN supply frequency inverter fans preheating bott
=HF+C1-9WA1 =HF+C1/285.06 H05VVC4V5-K
4
1,50 6KAÖL04X1,50S frequency inverter fan preheating bottom side
=HF+C1-90WA100 =HF+C1/900.01 secomp Ethernet
1
0,10 54773 network cableplc-switch
=HF+CM-7W2 =HF+C1/145.02 Fremdfertiger Kaufteil
2
1,00 152501 closed-bridge cooling zone top
=HF+CM-7W4 =HF+C1/145.05 Fremdfertiger Kaufteil
2
1,00 152501 closed-bridge cooling zone top
=HF+CM-7W6 =HF+C1/150.02 Fremdfertiger Kaufteil
2
1,00 152501 closed-bridge cooling zone bottom
=HF+CM-7W8 =HF+C1/150.05 Fremdfertiger Kaufteil
2
1,00 152501 closed-bridge cooling zone bottom
=HF+CM-7WB1 =HF+C1/170.00 Thermo
2
0,22 6ETHE2X0,22NI thermocouple cooling zone 1
=HF+CM-7WB2 =HF+C1/170.01 Thermo
2
0,22 6ETHE2X0,22NI thermocouple cooling zone 2
=HF+CM-7WB3 =HF+C1/170.02 Thermo
2
0,22 6ETHE2X0,22NI thermocouple cooling zone 3
=HF+CM-7WB4 =HF+C1/170.03 Thermo
2
0,22 6ETHE2X0,22NI thermocouple cooling zone 4
=HF+CM-7WB10 =HF+C1/370.03 Thermo
2
0,22 6ETHE2X0,22NI thermocouple recuperator flow
=HF+CM-7WB11 =HF+C1/370.03 Thermo
2
0,22 6ETHE2X0,22NI thermocouple recuperator return
=HF+CM-7WB1.1 =HF+C1/370.05 Thermo
2
0,22 6ETHE2X0,22NI thermocouple controled cooling zone
=HF+CM-7WE1 =HF+C1/370.01 Fremdfertiger Kaufteil
3
2,50 7,0 158061 heating cooling zone
=HF+CM-7WM1 =HF+C1/345.01 Fremdfertiger Kaufteil
7
1,00 7,0 152499 load fan cooling zone 1 top
=HF+CM-7WM2 =HF+C1/345.04 Fremdfertiger Kaufteil
7
1,00 7,0 152500 load fan cooling zone 2 top
=HF+CM-7WM3 =HF+C1/145.04 Fremdfertiger Kaufteil
7
1,00 7,0 152499 load fan cooling zone 3 top
=HF+CM-7WM4 =HF+C1/145.05 Fremdfertiger Kaufteil
7
1,00 7,0 152500 load fan cooling zone 4 top
=HF+CM-7WM5 =HF+C1/150.01 Fremdfertiger Kaufteil
7
1,00 7,0 152499 load fan cooling zone 1 bottom
=HF+CM-7WM6 Fremdfertiger Kaufteil
7
1,00 7,0 152500 load fan cooling zone 2 bottom
=HF+CM-7WM7 =HF+C1/350.06 Fremdfertiger Kaufteil
7
1,00 7,0 152499 load fan cooling zone 3 bottom
=HF+CM-7WM8 =HF+C1/150.05 Fremdfertiger Kaufteil
7
1,00 7,0 152500 load fan cooling zone 4 bottom
0 1 2 3 4 5 6 7 8 9
Page
=
+ DL
HF
=HF+DL/3
2
Modification Date
Name Norm
Check.
Proj.
Origin
Date
Crea. f.
Hotflow 3/xx
18.06.2009
=HF+DL/1
133953-V00
Otto-Schott-Straße 5
97877 Wertheim
GmbH
Plant designation
Project name
ERSA
14:15:2308.07.2010
cable overview
Cable overview
Cable designations Cable typePage/Path Length
Function text
Manufacturer
ø
DIN_KBU_35_ERSA_LS1
Cores article no.
=HF+CM-7WM10 =HF+C1/375.01 SIHF
3
0,75 6KASI03X0,75 outlet cooling transverse -fan
=HF+CM-7WM20 =HF+C1/375.04 H05VV5-F
3
0,75 6KAÖL03X0,75N outlet cooling axial-fan
6EST-IR1B
=HF+CM-7WY1 =HF+C1/370.08 Phönix Kaufteil
4
0,25 6EKABELVAU02 proportional valve controled cooling zone
=HF+E1-WA1 =HF+C1/500.03 Phönix Kaufteil 19 0,25 6ET0271-ZT1 SAC-box sensoric infeed
=HF+E1-WA2 =HF+C1/390.02 Phönix Kaufteil 19 0,25 6ET0271-ZT1 SAC-box sensoric outlet
=HF+E1-WB1 =HF+C1/435.01 Lumberg Kaufteil
3
0,25 10,0 6EKABELTOR-01 sensor EVT1 PC-connection
=HF+E1-WB2 =HF+C1/425.00 Phönix Kaufteil
3
0,25 10,0 6EKABELVAU16 sensor ISEL1 infeed sensor 1
=HF+E1-WB3 =HF+C1/430.01 Phönix Kaufteil
3
0,25 10,0 6EKABELVAU16 Sensor ISAL1 outlet sensor 1
=HF+E1-WB4 =HF+C1/435.02 Lumberg Kaufteil
3
0,25 10,0 6EKABELTOR-01 sensor EVT2 PC-connection
=HF+E1-WB5 =HF+C1/425.02 Phönix Kaufteil
3
0,25 10,0 49759 sensor ISEL2 infeed sensor 2
Phönix 6EKABELVAU16
=HF+E1-WB6 =HF+C1/430.02 Phönix Kaufteil
3
0,25 10,0 49759 Sensor ISAL2 outlet sensor 2
Phönix 6EKABELVAU16
=HF+E1-WB7 =HF+C1/435.03 Lumberg Kaufteil
3
0,25 10,0 6EKABELTOR-01 sensor EVT3 PC-connection
=HF+E1-WB8 =HF+C1/425.00 Phönix Kaufteil
3
0,25 10,0 6EKABELVAU16 sensor ISEL3 infeed sensor 3
=HF+E1-WB9 =HF+C1/430.03 Phönix Kaufteil
3
0,25 10,0 6EKABELVAU16 Sensor ISAL3 outlet sensor 3
=HF+E1-WB10 =HF+C1/435.04 Lumberg Kaufteil
3
0,25 10,0 6EKABELTOR-01 sensor EVT4 PC-connection
=HF+E1-WB11 =HF+C1/425.04 Phönix Kaufteil
3
0,25 10,0 49759 sensor ISEL4 infeed sensor 4
Phönix 6EKABELVAU16
=HF+E1-WB12 =HF+C1/430.04 Phönix Kaufteil
3
0,25 10,0 49759 Sensor ISAL4 outlet sensor 4
Phönix 6EKABELVAU16
=HF+E1-16WY1 =HF+C1/400.02 Weidmüller Kaufteil
4
0,34 15543 supply lead pressure control valve temperature-man
=HF+E1-16WY2 =HF+C1/400.03 Weidmüller Kaufteil
4
0,34 15543 supply lead pressure control valve temperature-man
=HF+E1-16WY3 =HF+C1/400.05 Weidmüller Kaufteil
4
0,34 15543 supply lead pressure control valve temperature-man
=HF+E1-16WY4 =HF+C1/400.07 Weidmüller Kaufteil
4
0,34 15543 supply lead pressure control valve temperature-man
=HF+E1-16WY5 =HF+C1/400.02 Weidmüller Kaufteil
4
0,34 15543 supply lead pressure control valve temperature-man
=HF+E1-16WY6 =HF+C1/400.03 Weidmüller Kaufteil
4
0,34 15543 supply lead pressure control valve temperature-man
=HF+E1-16WY7 =HF+C1/400.05 Weidmüller Kaufteil
4
0,34 15543 supply lead pressure control valve temperature-man
=HF+E1-16WY8 =HF+C1/400.07 Weidmüller Kaufteil
4
0,34 15543 supply lead pressure control valve temperature-man
=HF+E1-19WA1 =HF+C1/20.08 Kaufteil
3
1,00 6EKADA-024 (???) (???)
=HF+E1-19WA4 =HF+C1/20.07 Kaufteil
3
1,00 6EKADA-024 supply monitor
=HF+E1-19WA5 =HF+C1/20.05 RS Kaufteil
1
0,00 100547 USB-extension
=HF+E1-19WA1.1 =HF+C1/20.08 Kaufteil
1
0,00 Kaufteil-Gerätekabel 230V supply PC
=HF+E1-19WA4.1 =HF+C1/20.06 Kaufteil
1
0,00 Kaufteil-Gerätekabel supply monitor
0 1 2 3 4 5 6 7 8 9
Page
=
+ DL
HF
=HF+DL/4
3
Modification Date
Name Norm
Check.
Proj.
Origin
Date
Crea. f.
Hotflow 3/xx
18.06.2009
=HF+DL/2
133953-V00
Otto-Schott-Straße 5
97877 Wertheim
GmbH
Plant designation
Project name
ERSA
14:15:2308.07.2010
cable overview
Cable overview
Cable designations Cable typePage/Path Length
Function text
Manufacturer
ø
DIN_KBU_35_ERSA_LS1
Cores article no.
=HF+E1-19WA10.1 =HF+C1/900.07 supply control-panel
=HF+E1-19WA1.2 =HF+C1/20.01 Bachmann Ethernet
1
0,10 23734 networkcable plc-ipc
=HF+E1-19WA4.2 =HF+C1/20.04 Kaufteil
1
0,14 6EKADA-020 VGA cable monitor
=HF+E1-19WA10.2 =HF+C1/900.07 Bachmann Ethernet
1
0,10 23734 network cablecontrol-panel
=HF+E1-19WA12.2 =HF+C1/900.02 Bachmann Ethernet
1
0,10 23734 network cableplc-PC
=HF+E1-19WA1.3 =HF+C1/20.03 RS Kaufteil
1
0,00 100547 USB-extension
=HF+E1-21WB1 =HF+C1/115.04 Phönix Kaufteil
4
0,25 6EKABELVAU02 pressure switch exhaust air infeed
=HF+E1-21WB2 =HF+C1/115.04 Phönix Kaufteil
4
0,25 6EKABELVAU02 pressure switch exhaust air outlet
=HF+E1-21WM1 =HF+C1/115.07 M-E-K Electric SIHF
4
1,00 WF71.52.071 cablehood exhaust-air
Phoenix 6ESTC-6
Phoenix Contact WF71.81.162
=HF+E1-22WS1 =HF+C1/30.02 H05VV5-F
2
0,75 6KAÖL02X0,75N emergency off switch front on the left
=HF+E1-22WS2 =HF+C1/30.03 H05VV5-F
2
0,75 6KAÖL02X0,75N emergency off switch front on right
=HF+E1-22WS3 =HF+C1/30.04 H05VV5-F
2
0,75 6KAÖL02X0,75N emergency stop bottom in the back left
=HF+E1-22WS4 =HF+C1/30.05 H05VV5-F
2
0,75 6KAÖL02X0,75N emergency stop bottom in the back right
=HF+E1-23WH1 =HF+C1/35.00 auer Kaufteil
6
0,34 Anschlusskabel Melde signal lamp
=HF+E1-24WA1 =HF+C1/40.02 Fremdfertiger Kaufteil
3
2,50 158061 Supply lead hood control
=HF+E1-24WA2 =HF+C1/40.07 skf Kaufteil
1
0,00 139997 Supply lead terminal hood control
=HF+E1-24WA1.1 =HF+C1/40.04 skf Kaufteil
1
0,00 139997 contril lead hood control
=HF+E1-24WA1.2 =HF+C1/40.04 skf Kaufteil 15 0,00 141044 Supply lead data hood control
=HF+E1-24WM1 =HF+C1/40.02 skf Kaufteil
1
0,00 139939 hood motor infeed
=HF+E1-24WM2 =HF+C1/40.04 skf Kaufteil
1
0,00 139939 hood motor outlet
=HF+E1-24WM3 =HF+C1/40.05 skf Kaufteil
1
0,00 139939 hood motor middle
=HF+E1-24WS1 =HF+C1/40.00 Phönix Sensor-Aktor-Vert
4
0,25 6EKABELVAU12 switch hood closed
=HF+E1-25WM1 =HF+C1/45.01 ERL Kaufteil
5
1,00 112699 24VDC-supply chain conveyor 1
=HF+E1-25WM2 =HF+C1/50.01 ERL Kaufteil
5
1,00 112699 24VDC-supply chain conveyor 2
=HF+E1-25WM3 =HF+C1/55.01 ERL Kaufteil
5
1,00 112699 24VDC-supply chain conveyor 3
=HF+E1-25WM4 =HF+C1/60.01 ERL Kaufteil
5
1,00 112699 24VDC-supply chain conveyor 4
=HF+E1-25WM1.1 =HF+C1/45.06 Phönix Sensor-Aktor-Vert
5
0,34 124708 CAN-conection chain conveyor 1
=HF+E1-25WM2.1 =HF+C1/50.05 Phönix Sensor-Aktor-Vert
5
0,34 72344 CAN-connection chain conveyor 2
=HF+E1-25WM3.1 =HF+C1/55.05 Phönix Sensor-Aktor-Vert
5
0,34 72344 CAN-connection chain conveyor 3
=HF+E1-25WM4.1 =HF+C1/60.05 Phönix Sensor-Aktor-Vert
5
0,34 72344 CAN-connection chain conveyor 4
=HF+E1-26WM1 =HF+C1/65.02 Phönix Kaufteil
3
0,25 5,0 63334 chain-oiler 1
=HF+E1-26WM2 =HF+C1/65.04 Phönix Kaufteil
3
0,25 5,0 49759 chain-oiler 2
Phönix 63334
0 1 2 3 4 5 6 7 8 9
