Plan_HF3_14_20_en line 1电路 - 第125页

Pag e = DD HF =HF +DD/9 8 Modificati on Date Na m e No rm Check. Proj. Origin Date Crea. f. ERSA Hot flow 3/xx 18 .0 6. 200 9 =HF +DD/7 133 953- V00 Ot to-Schott-Straße 5 97 87 7 W ertheim Gm bH Plant designation Pr oj e…

Page

=HF+DD/8

Modification Date

Name Norm

Check.

Proj.

Origin

Date

Crea. f.

ERSA

Hotflow 3/xx

18.06.2009

=HF+DD/6

133953-V00

Otto-Schott-Straße 5

97877 Wertheim

GmbH

Plant designation

Project name

14:15:1908.07.2010

file name (*.pdf)

133953-V00_100705

basic-project

Device list

Description

Device list

DIN_PSL_50_2_ERSA_LS1

Part numberPage/Path

=HF+HM2-3M6 =HF+C1/260.05 6HZL-MOT144B fansoldering zone 6 top

=HF+HM2-3M7 =HF+C1/265.05 6HZL-MOT144B fan soldering zone7 top

=HF+HM2-3M8 =HF+C1/270.05 6HZL-MOT144B fan soldering zone 8 top

=HF+HM2-3M9 =HF+C1/275.05 6HZL-MOT144B fan soldering zone9 top

=HF+HM2-3M10 =HF+C1/280.05 6HZL-MOT144B fansoldering zone 10 top

=HF+C1-4A1 =HF+C1/365.07 152422 frequency inverter fans soldering zone bottom side

=HF+C1-4F6 =HF+C1/320.01 6EBSIA-16A-B2 soldering zone 6 bottom side

=HF+C1-4F7 =HF+C1/325.01 6EBSIA-16A-B2 soldering zone 7 bottom side

=HF+C1-4F8 =HF+C1/330.01 6EBSIA-16A-B2 soldering zone 8 bottom side

=HF+C1-4F9 =HF+C1/335.01 6EBSIA-16A-B2 soldering zone 9 bottom side

=HF+C1-4F10 =HF+C1/340.01 6EBSIA-16A-B2 soldering zone 10 bottom side

=HF+C1-4F11 =HF+C1/365.08 6EBSIA-16A-K3 frequency inverter fan soldering bottom side

=HF+C1-4K1 =HF+C1/215.08 6ESÜB7D-40-00 soldering zonebottom side on

=HF+C1-4K3 6ESÜB6S-30-01 switch on fans 8-10 bottom switched

=HF+C1-4U6 =HF+C1/205.01 6ERELOMRON-3 soldering zone6 bottom side

=HF+C1-4U7 =HF+C1/205.02 6ERELOMRON-3 soldering zone7 bottom side

=HF+C1-4U8 =HF+C1/205.04 6ERELOMRON-3 soldering zone8 bottom side

=HF+C1-4U9 =HF+C1/205.05 6ERELOMRON-3 soldering zone9 bottom side

=HF+C1-4U10 =HF+C1/205.06 6ERELOMRON-3 soldering zone10 bottom side

=HF+HM1-4B6 =HF+C1/160.06 140717 thermocouplesoldering zone 6bottom side HF3/14

=HF+HM1-4B6.1 =HF+C1/180.06 83324 thermocouplesoldering zone 6bottom side HF3/14

=HF+HM1-4B7 =HF+C1/160.09 140717 thermocouplesoldering zone 6bottom side HF3/14

=HF+HM1-4B7.1 =HF+C1/180.08 83324 thermocouplesoldering zone 7bottom side HF3/14

=HF+HM2-4B8 =HF+C1/165.05 140717 thermocouplesoldering zone8 bottom side

=HF+HM2-4B8.1 =HF+C1/185.05 83324 thermocouplesoldering zone 8bottom side

=HF+HM2-4B9 =HF+C1/165.07 140717 thermocouplesoldering zone9 bottom side

=HF+HM2-4B9.1 =HF+C1/185.06 83324 thermocouplesoldering zone 9bottom side

=HF+HM2-4B10 =HF+C1/165.08 140717 thermocouplesoldering zone10 bottom side

=HF+HM2-4B10.1 =HF+C1/185.07 83324 thermocouplesoldering zone 10bottom side

=HF+HM2-4E6 =HF+C1/320.00 6HKRO400V-3.3KW heating soldering zone 6 bottom side

=HF+HM2-4E7 =HF+C1/325.00 6HKRO400V-3.3KW heating soldering zone 7 bottom side

=HF+HM2-4E8 =HF+C1/330.00 6HKRO400V-3.3KW heating soldering zone 8 bottom side

6HKRO400V-4.5KW Rohrheizkörper D250 400V 4,5KW

=HF+HM2-4E9 =HF+C1/335.00 6HKRO400V-3.3KW heating soldering zone 9 bottom side

6HKRO400V-4.5KW Rohrheizkörper D250 400V 4,5KW

=HF+HM2-4E10 =HF+C1/340.00 6HKRO400V-3.3KW heating soldering zone 10 bottom side

6HKRO400V-4.5KW Rohrheizkörper D250 400V 4,5KW

=HF+HM2-4M6 =HF+C1/320.05 6HZL-MOT144B fans soldering zone 6 bottom side

0 1 2 3 4 5 6 7 8 9

Page

=HF+DD/9

Modification Date

Name Norm

Check.

Proj.

Origin

Date

Crea. f.

ERSA

Hotflow 3/xx

18.06.2009

=HF+DD/7

133953-V00

Otto-Schott-Straße 5

97877 Wertheim

GmbH

Plant designation

Project name

14:15:1908.07.2010

file name (*.pdf)

133953-V00_100705

basic-project

Device list

Description

Device list

DIN_PSL_50_2_ERSA_LS1

Part numberPage/Path

=HF+HM2-4M7 =HF+C1/325.05 6HZL-MOT144B fan soldering zone 7 bottom side

=HF+HM2-4M8 =HF+C1/330.05 6HZL-MOT144B fan soldering zone 8 bottom side

=HF+HM2-4M9 =HF+C1/335.05 6HZL-MOT144B fan soldering zone 9 bottom side

=HF+HM2-4M10 =HF+C1/340.05 6HZL-MOT144B fan soldering zone 10 bottom side

=HF+C1-7A1 =HF+C1/365.04 152422 frequency inverter fan cooling zone

152424 Frequenzumrichter A-Filter integriert

=HF+C1-7A11 =HF+C1/370.04 107215 thermostat controled cooling zone

=HF+C1-7F1 =HF+C1/370.01 6EBSIA-16A-B2 heating cooling zone

=HF+C1-7F10 =HF+C1/375.01 6EBSIA-06A-B1 outlet cooling

=HF+C1-7F11 =HF+C1/365.04 6EBSIA-16A-K3 frequency inverter fan cooling zone

152433 Sicherungsautomat 20A, 3-polig

=HF+C1-7F12 =HF+C1/350.01 6EBSIA-06A-K3 fan cooling zone top/bottomswitched

=HF+C1-7K1 =HF+C1/215.04 6ESÜB7D-40-00 cooling zoneheating on

=HF+C1-7K3 =HF+C1/210.03 6ESÜB7D-40-00 switch onfan cooling zoneswitched

=HF+C1-7K10 =HF+C1/150.06 6ETEM2-3 Interf. Relais 24VDC 1 Wechsler thermocontrolcooling zone

=HF+C1-7U1 =HF+C1/370.05 6ERELOMRON-3 heating cooling zone

=HF+C1-7V3 =HF+C1/350.02 6ESÜ-ZT02 interference- unit

=HF+CM-7B1 =HF+C1/170.01 140717 thermocouplecooling zone 1

=HF+CM-7B1.1 =HF+C1/370.05 6ETHE-IR10 thermoelementcooling zone 1 top

=HF+CM-7B2 =HF+C1/170.02 140717 thermocouplecooling zone 2

=HF+CM-7B3 =HF+C1/170.03 140717 thermocouplecooling zone 3

=HF+CM-7B4 =HF+C1/170.04 140717 thermocouplecooling zone 4

=HF+CM-7B10 =HF+C1/370.03 6ETHE-IR10 thermoelement recuperator flow

=HF+CM-7B11 =HF+C1/370.04 6ETHE-IR10 thermoelement recuperator return

=HF+CM-7E1 =HF+C1/370.00 6HKRO400V-3.3KW heating cooling zone

=HF+CM-7M1 =HF+C1/345.00 6HZL-MOT144B fan cooling zone 1 top

=HF+CM-7M2 =HF+C1/345.03 6HZL-MOT144B fan cooling zone 2 top

=HF+CM-7M3 =HF+C1/350.01 6HZL-MOT144B fan cooling zone 3 above

=HF+CM-7M4 =HF+C1/350.03 6HZL-MOT144B fan cooling zone 4 above

=HF+CM-7M5 =HF+C1/345.05 6HZL-MOT144B fan cooling zone 1 bottom side

=HF+CM-7M6 =HF+C1/345.07 6HZL-MOT144B fan cooling zone 2 bottom side

=HF+CM-7M7 =HF+C1/350.05 6HZL-MOT144B fan cooling zone 3 bottom side

=HF+CM-7M8 =HF+C1/350.07 6HZL-MOT144B fan cooling zone 4 bottom side

=HF+CM-7M10 =HF+C1/375.01 6QL630AL-H30 outlet coolingtransverse -fan

=HF+CM-7M11 =HF+C1/375.02 6QL630AL-H30 outlet coolingtransverse -fan

=HF+CM-7M12 =HF+C1/375.03 6QL630AL-H30 outlet coolingtransverse -fan

=HF+CM-7M13 =HF+C1/375.03 6QL630AL-H30 outlet coolingtransverse -fan

=HF+CM-7M20 =HF+C1/375.04 6VEN-4650 outlet coolingaxial-fan

0 1 2 3 4 5 6 7 8 9

Page

=HF+DD/10

Modification Date

Name Norm

Check.

Proj.

Origin

Date

Crea. f.

ERSA

Hotflow 3/xx

18.06.2009

=HF+DD/8

133953-V00

Otto-Schott-Straße 5

97877 Wertheim

GmbH

Plant designation

Project name

14:15:1908.07.2010

file name (*.pdf)

133953-V00_100705

basic-project

Device list

Description

Device list

DIN_PSL_50_2_ERSA_LS1

Part numberPage/Path

=HF+CM-7M21 =HF+C1/375.05 6VEN-4650 outlet coolingaxial-fan

=HF+CM-7M24 =HF+C1/375.06 6VEN-4650 outlet coolingaxial-fan

=HF+CM-7M25 =HF+C1/375.07 6VEN-4650 outlet coolingaxial-fan

=HF+CM-7Y1

=HF+C1/370.08 155824 proportional valvecontroled cooling zone

=HF+C1-9A1 =HF+C1/365.02 152424 frequency inverter fans preheating bottom side

=HF+C1-9F1 =HF+C1/285.01 6EBSIA-16A-B2 preheating zone 1 bottom side

=HF+C1-9F2 =HF+C1/290.01 6EBSIA-16A-B2 preheating zone 2 bottom side

=HF+C1-9F3 =HF+C1/295.01 6EBSIA-16A-B2 preheating zone 3 bottom side

=HF+C1-9F4 =HF+C1/300.01 6EBSIA-16A-B2 preheating zone 4 bottom side

=HF+C1-9F5 =HF+C1/305.01 6EBSIA-16A-B2 preheating zone 5 bottom side

=HF+C1-9F6 =HF+C1/310.01 6EBSIA-16A-B2 preheating zone 6 bottom side

=HF+C1-9F7 =HF+C1/315.01 6EBSIA-16A-B2 preheating zone 7 bottom side

=HF+C1-9F11 =HF+C1/365.02 152433 frequency inverter fan preheating bottom side

=HF+C1-9F12 =HF+C1/285.07 6EBSIA-06A-K3 fans preheating zone bottom side switched

=HF+C1-9K1 =HF+C1/215.03 6ESÜB7D-40-00 preheating zone1-4 bottom side on

=HF+C1-9K2 =HF+C1/215.03 6ESÜB7D-40-00 preheating zone5-7 bottom side on

=HF+C1-9K3 =HF+C1/210.02 6ESÜB7D-40-00 switch onfan preheating zonebottom side switched

=HF+C1-9K10 =HF+C1/140.02 6ETEM2-3 Interf. Relais 24VDC 1 Wechsler thermocontrolbottom side OK

=HF+C1-9U1 =HF+C1/195.01 6ERELOMRON-3 preheating zone 1 bottom side

=HF+C1-9U2 =HF+C1/195.02 6ERELOMRON-3 preheating zone 2 bottom side

=HF+C1-9U3 =HF+C1/195.03 6ERELOMRON-3 preheating zone 3 bottom side

=HF+C1-9U4 =HF+C1/195.04 6ERELOMRON-3 preheating zone 4 bottom side

=HF+C1-9U5 =HF+C1/195.05 6ERELOMRON-3 preheating zone 5 bottom side

=HF+C1-9U6 =HF+C1/195.07 6ERELOMRON-3 preheating zone 6 bottom side

=HF+C1-9U7 =HF+C1/195.08 6ERELOMRON-3 preheating zone 7 bottom side

=HF+C1-9V3 =HF+C1/285.08 6ESÜ-ZT02 interference- unit

=HF+HM1-9B1 =HF+C1/160.01 140717 thermocouplepreheating zone 1bottom side

=HF+HM1-9B1.1 =HF+C1/180.01 83324 thermocouplepreheating zone 1bottom side

=HF+HM1-9B2 =HF+C1/160.02 140717 thermocouplepreheating zone 2bottom side

=HF+HM1-9B2.1 =HF+C1/180.02 83324 thermocouplepreheating zone 2bottom side

=HF+HM1-9B3 =HF+C1/160.03 140717 thermocouplepreheating zone 3bottom side

=HF+HM1-9B3.1 =HF+C1/180.03 83324 thermocouplepreheating zone 3bottom side

=HF+HM1-9B4 =HF+C1/160.04 140717 thermocouplepreheating zone 4bottom side

=HF+HM1-9B4.1 =HF+C1/180.04 83324 thermocouplepreheating zone 4bottom side

=HF+HM1-9B5 =HF+C1/160.05 140717 thermocouplepreheating zone 5bottom side

=HF+HM1-9B5.1 =HF+C1/180.05 83324 thermocouplepreheating zone 5bottom side

=HF+HM1-9B6 =HF+C1/160.07 140717 thermocouplepreheating zone 6bottom side HF3/20

=HF+HM1-9B6.1 =HF+C1/180.07 83324 thermocouplepreheating zone 6bottom side HF3/20

0 1 2 3 4 5 6 7 8 9
