Plan_HF3_14_20_en line 1电路 - 第126页
Pag e = DD HF =HF +DD/10 9 Modificati on Date Na m e No rm Check. Proj. Origin Date Crea. f. ERSA Hot flow 3/xx 18 .0 6. 200 9 =HF +DD/8 133 953- V00 Ot to-Schott-Straße 5 97 87 7 W ertheim Gm bH Plant designation Pr oj …
Page
=
DD
HF
=HF+DD/9
8
Modification Date
Name Norm
Check.
Proj.
Origin
Date
Crea. f.
ERSA
Hotflow 3/xx
18.06.2009
=HF+DD/7
133953-V00
Otto-Schott-Straße 5
97877 Wertheim
GmbH
Plant designation
Project name
14:15:1908.07.2010
+
file name (*.pdf)
133953-V00_100705
basic-project
-
Device list
Description
Device list
DIN_PSL_50_2_ERSA_LS1
Part numberPage/Path
=HF+HM2-4M7 =HF+C1/325.05 6HZL-MOT144B fan soldering zone 7 bottom side
=HF+HM2-4M8 =HF+C1/330.05 6HZL-MOT144B fan soldering zone 8 bottom side
=HF+HM2-4M9 =HF+C1/335.05 6HZL-MOT144B fan soldering zone 9 bottom side
=HF+HM2-4M10 =HF+C1/340.05 6HZL-MOT144B fan soldering zone 10 bottom side
=HF+C1-7A1 =HF+C1/365.04 152422 frequency inverter fan cooling zone
152424 Frequenzumrichter A-Filter integriert
=HF+C1-7A11 =HF+C1/370.04 107215 thermostat controled cooling zone
=HF+C1-7F1 =HF+C1/370.01 6EBSIA-16A-B2 heating cooling zone
=HF+C1-7F10 =HF+C1/375.01 6EBSIA-06A-B1 outlet cooling
=HF+C1-7F11 =HF+C1/365.04 6EBSIA-16A-K3 frequency inverter fan cooling zone
152433 Sicherungsautomat 20A, 3-polig
=HF+C1-7F12 =HF+C1/350.01 6EBSIA-06A-K3 fan cooling zone top/bottomswitched
=HF+C1-7K1 =HF+C1/215.04 6ESÜB7D-40-00 cooling zoneheating on
=HF+C1-7K3 =HF+C1/210.03 6ESÜB7D-40-00 switch onfan cooling zoneswitched
=HF+C1-7K10 =HF+C1/150.06 6ETEM2-3 Interf. Relais 24VDC 1 Wechsler thermocontrolcooling zone
=HF+C1-7U1 =HF+C1/370.05 6ERELOMRON-3 heating cooling zone
=HF+C1-7V3 =HF+C1/350.02 6ESÜ-ZT02 interference- unit
=HF+CM-7B1 =HF+C1/170.01 140717 thermocouplecooling zone 1
=HF+CM-7B1.1 =HF+C1/370.05 6ETHE-IR10 thermoelementcooling zone 1 top
=HF+CM-7B2 =HF+C1/170.02 140717 thermocouplecooling zone 2
=HF+CM-7B3 =HF+C1/170.03 140717 thermocouplecooling zone 3
=HF+CM-7B4 =HF+C1/170.04 140717 thermocouplecooling zone 4
=HF+CM-7B10 =HF+C1/370.03 6ETHE-IR10 thermoelement recuperator flow
=HF+CM-7B11 =HF+C1/370.04 6ETHE-IR10 thermoelement recuperator return
=HF+CM-7E1 =HF+C1/370.00 6HKRO400V-3.3KW heating cooling zone
=HF+CM-7M1 =HF+C1/345.00 6HZL-MOT144B fan cooling zone 1 top
=HF+CM-7M2 =HF+C1/345.03 6HZL-MOT144B fan cooling zone 2 top
=HF+CM-7M3 =HF+C1/350.01 6HZL-MOT144B fan cooling zone 3 above
=HF+CM-7M4 =HF+C1/350.03 6HZL-MOT144B fan cooling zone 4 above
=HF+CM-7M5 =HF+C1/345.05 6HZL-MOT144B fan cooling zone 1 bottom side
=HF+CM-7M6 =HF+C1/345.07 6HZL-MOT144B fan cooling zone 2 bottom side
=HF+CM-7M7 =HF+C1/350.05 6HZL-MOT144B fan cooling zone 3 bottom side
=HF+CM-7M8 =HF+C1/350.07 6HZL-MOT144B fan cooling zone 4 bottom side
=HF+CM-7M10 =HF+C1/375.01 6QL630AL-H30 outlet coolingtransverse -fan
=HF+CM-7M11 =HF+C1/375.02 6QL630AL-H30 outlet coolingtransverse -fan
=HF+CM-7M12 =HF+C1/375.03 6QL630AL-H30 outlet coolingtransverse -fan
=HF+CM-7M13 =HF+C1/375.03 6QL630AL-H30 outlet coolingtransverse -fan
=HF+CM-7M20 =HF+C1/375.04 6VEN-4650 outlet coolingaxial-fan
0 1 2 3 4 5 6 7 8 9
Page
=
DD
HF
=HF+DD/10
9
Modification Date
Name Norm
Check.
Proj.
Origin
Date
Crea. f.
ERSA
Hotflow 3/xx
18.06.2009
=HF+DD/8
133953-V00
Otto-Schott-Straße 5
97877 Wertheim
GmbH
Plant designation
Project name
14:15:1908.07.2010
+
file name (*.pdf)
133953-V00_100705
basic-project
-
Device list
Description
Device list
DIN_PSL_50_2_ERSA_LS1
Part numberPage/Path
=HF+CM-7M21 =HF+C1/375.05 6VEN-4650 outlet coolingaxial-fan
=HF+CM-7M24 =HF+C1/375.06 6VEN-4650 outlet coolingaxial-fan
=HF+CM-7M25 =HF+C1/375.07 6VEN-4650 outlet coolingaxial-fan
=HF+CM-7Y1
=HF+C1/370.08 155824 proportional valvecontroled cooling zone
=HF+C1-9A1 =HF+C1/365.02 152424 frequency inverter fans preheating bottom side
=HF+C1-9F1 =HF+C1/285.01 6EBSIA-16A-B2 preheating zone 1 bottom side
=HF+C1-9F2 =HF+C1/290.01 6EBSIA-16A-B2 preheating zone 2 bottom side
=HF+C1-9F3 =HF+C1/295.01 6EBSIA-16A-B2 preheating zone 3 bottom side
=HF+C1-9F4 =HF+C1/300.01 6EBSIA-16A-B2 preheating zone 4 bottom side
=HF+C1-9F5 =HF+C1/305.01 6EBSIA-16A-B2 preheating zone 5 bottom side
=HF+C1-9F6 =HF+C1/310.01 6EBSIA-16A-B2 preheating zone 6 bottom side
=HF+C1-9F7 =HF+C1/315.01 6EBSIA-16A-B2 preheating zone 7 bottom side
=HF+C1-9F11 =HF+C1/365.02 152433 frequency inverter fan preheating bottom side
=HF+C1-9F12 =HF+C1/285.07 6EBSIA-06A-K3 fans preheating zone bottom side switched
=HF+C1-9K1 =HF+C1/215.03 6ESÜB7D-40-00 preheating zone1-4 bottom side on
=HF+C1-9K2 =HF+C1/215.03 6ESÜB7D-40-00 preheating zone5-7 bottom side on
=HF+C1-9K3 =HF+C1/210.02 6ESÜB7D-40-00 switch onfan preheating zonebottom side switched
=HF+C1-9K10 =HF+C1/140.02 6ETEM2-3 Interf. Relais 24VDC 1 Wechsler thermocontrolbottom side OK
=HF+C1-9U1 =HF+C1/195.01 6ERELOMRON-3 preheating zone 1 bottom side
=HF+C1-9U2 =HF+C1/195.02 6ERELOMRON-3 preheating zone 2 bottom side
=HF+C1-9U3 =HF+C1/195.03 6ERELOMRON-3 preheating zone 3 bottom side
=HF+C1-9U4 =HF+C1/195.04 6ERELOMRON-3 preheating zone 4 bottom side
=HF+C1-9U5 =HF+C1/195.05 6ERELOMRON-3 preheating zone 5 bottom side
=HF+C1-9U6 =HF+C1/195.07 6ERELOMRON-3 preheating zone 6 bottom side
=HF+C1-9U7 =HF+C1/195.08 6ERELOMRON-3 preheating zone 7 bottom side
=HF+C1-9V3 =HF+C1/285.08 6ESÜ-ZT02 interference- unit
=HF+HM1-9B1 =HF+C1/160.01 140717 thermocouplepreheating zone 1bottom side
=HF+HM1-9B1.1 =HF+C1/180.01 83324 thermocouplepreheating zone 1bottom side
=HF+HM1-9B2 =HF+C1/160.02 140717 thermocouplepreheating zone 2bottom side
=HF+HM1-9B2.1 =HF+C1/180.02 83324 thermocouplepreheating zone 2bottom side
=HF+HM1-9B3 =HF+C1/160.03 140717 thermocouplepreheating zone 3bottom side
=HF+HM1-9B3.1 =HF+C1/180.03 83324 thermocouplepreheating zone 3bottom side
=HF+HM1-9B4 =HF+C1/160.04 140717 thermocouplepreheating zone 4bottom side
=HF+HM1-9B4.1 =HF+C1/180.04 83324 thermocouplepreheating zone 4bottom side
=HF+HM1-9B5 =HF+C1/160.05 140717 thermocouplepreheating zone 5bottom side
=HF+HM1-9B5.1 =HF+C1/180.05 83324 thermocouplepreheating zone 5bottom side
=HF+HM1-9B6 =HF+C1/160.07 140717 thermocouplepreheating zone 6bottom side HF3/20
=HF+HM1-9B6.1 =HF+C1/180.07 83324 thermocouplepreheating zone 6bottom side HF3/20
0 1 2 3 4 5 6 7 8 9
Page
=
DD
HF
=HF+DD/11
10
Modification Date
Name Norm
Check.
Proj.
Origin
Date
Crea. f.
ERSA
Hotflow 3/xx
18.06.2009
=HF+DD/9
133953-V00
Otto-Schott-Straße 5
97877 Wertheim
GmbH
Plant designation
Project name
14:15:1908.07.2010
+
file name (*.pdf)
133953-V00_100705
basic-project
-
Device list
Description
Device list
DIN_PSL_50_2_ERSA_LS1
Part numberPage/Path
=HF+HM1-9B7 =HF+C1/160.08 140717 thermocouplepreheating zone 7bottom side HF3/20
=HF+HM1-9B7.1 =HF+C1/180.09 83324 thermocouplepreheating zone 7bottom side HF3/20
=HF+HM1-9E1 =HF+C1/285.00 6HKRO400V-3.3KW heating preheating zone 1 bottom side
=HF+HM1-9E2 =HF+C1/290.00 6HKRO400V-3.3KW heating preheating zone 2 bottom side
=HF+HM1-9E3 =HF+C1/295.00 6HKRO400V-3.3KW heating preheating zone 3 bottom side
=HF+HM1-9E4 =HF+C1/300.00 6HKRO400V-3.3KW heating preheating zone 4 bottom side
=HF+HM1-9E5 =HF+C1/305.00 6HKRO400V-3.3KW heating preheating zone 5 bottom side
=HF+HM1-9E6 =HF+C1/310.00 6HKRO400V-3.3KW heating preheating zone 6 bottom side
=HF+HM1-9E7 =HF+C1/315.00 6HKRO400V-3.3KW heating preheating zone 7 bottom side
=HF+HM1-9M1 =HF+C1/285.05 6HZL-MOT144B fan preheating zone 1 bottom side
6HZL-MOT145 Lüftermotor Typ L7, 1450rpm
=HF+HM1-9M2 =HF+C1/290.05 6HZL-MOT144B fan preheating zone 2 bottom side
6HZL-MOT145 Lüftermotor Typ L7, 1450rpm
=HF+HM1-9M3 =HF+C1/295.05 6HZL-MOT144B fan preheating zone 3 bottom side
6HZL-MOT145 Lüftermotor Typ L7, 1450rpm
=HF+HM1-9M4 =HF+C1/300.05 6HZL-MOT144B fan preheating zone 4 bottom side
6HZL-MOT145 Lüftermotor Typ L7, 1450rpm
=HF+HM1-9M5 =HF+C1/305.05 6HZL-MOT144B fan preheating zone 5 bottom side
6HZL-MOT145 Lüftermotor Typ L7, 1450rpm
=HF+HM1-9M6 =HF+C1/310.05 6HZL-MOT144B fan preheating zone 6 bottom side
6HZL-MOT145 Lüftermotor Typ L7, 1450rpm
=HF+HM1-9M7 =HF+C1/315.05 6HZL-MOT144B fan preheating zone 7 bottom side
6HZL-MOT145 Lüftermotor Typ L7, 1450rpm
=HF+C1-10F1 =HF+C1/5.02 6EBSIA-63A-B3 prefuse 400VACheating zone 1-10 top
=HF+C1-10F2 =HF+C1/5.04 6EBSIA-63A-B3 prefuse 400VACheating zone 1-10 bottom side
=HF+C1-10F3 =HF+C1/5.06 6EBSIA-16A-B3 supply 400VACover emergency off
=HF+C1-11F1 =HF+C1/395.03 6EBSIA-06A-B1 supply pump hot-water-circuit
=HF+C1-11K1 =HF+C1/395.01 6ETEM2-3 water pump on hot-water-circuit
=HF+WC-11M1 =HF+C1/395.03 147511 pump hot-water-circuit
=HF+WC-11S1 =HF+C1/395.05 142939 water min advance warninghot-water-circuit
=HF+WC-11S2 =HF+C1/395.07 142939 water min hot-water-circuit
=HF+WC-11S3 =HF+C1/395.08 147646 Temperaturwächter G1/2" - 80°C thermo controlhot-water-circuit
=HF+C1-12K1 =HF+C1/390.07 6ETEM2-3 cold water cooling unit internal stop valve on
=HF+C1-12K2 =HF+C1/390.09 6ETEM2-3 cold water cooling unit externalstop valve on
=HF+WC-12S1 =HF+C1/390.01 6BO305 cooling unit pressure ok
=HF+WC-12Y1 =HF+C1/390.02 6X00050 stop valve internal 1
=HF+WC-12Y2 =HF+C1/390.03 6X00050 stop valve internal 2
=HF+WC-12Y3 =HF+C1/390.04 6X00050 stop valve external 1
0 1 2 3 4 5 6 7 8 9
