D3Parts List__N7202A043B - 第54页
9-C X軸:NPM-D3 X-Ax is:NPM-D3 パーツレイアウト Kit No. キット 品番 Kit Name キット名称 N610160756AA セクションNo. PARTS LAYOUT Section No. - - S35 ( KN610160756AA-26-3 )
Ref
No.
Remarks R
1
Q'ty
9-B
X軸:NPM-D3
X-Axis:NPM-D3
ｲﾗｽﾄ
No.
Part No.
品 名品 番 数量
R
2
パーツリスト
Kit No.
キット品番
Kit Name
キット名称
N610160756AA
Part Name
備 考
セクションNo.
PARTS LIST
Section No.
R
3
STOPPER
4
1 N210109236AB
BLOCK
4
2 N210189793AA
PIECE
8
3 N210109406AA
PLATE
2
4 N210130097AB
PLATE
2
5 N210133963AA
HOUSING
4
6 N210189805AA
WASHER
4
7 N210170739AA
COLLAR
4
8 N210189796AA
PLATE
2
9 N210189813AB
COVER
2
10 N210191513AA
PAN
2
11 N210191512AA
BRACKET
2
12 MTKP000634AA
BRACKET
1
13 MTKP000641AB
LINEAR-WAY
4
14 N510064152AA LRXSC20C2R594E121
LINEAR-SCALE
2
15 N510066263AC ST778A-440PF2
MOTOR
4
16 N510067050AA
S
DS045M288B04CT
GREASE-NIPPLE
2
17 N560AMT6-130 A-MT6X1-Type(M6X1)
SPACER
4
18 N510044825AA 3382330-40075
PIN
4
19 KXF0CXHAA00 1017003-40008
BOLT
4
20 MTNK000536AA
Hexagon head bolt Best class M6X16-6g 10T A2J (Trivalent) (MEC process:
BOLT
40
21 N510017397AA
Hexagon socket head cap screw M5X18-10.9 A2J (Trivalent)
SPRING
8
22 N510047200AA SSWB12-20
BOLT
4
23 N510017457AA
Hexagon socket head cap screw M6X8-10.9 A2J (Trivalent)
SPRING
4
24 N510055040AA SSWM18-20
WASHER
4
25 N510031255AA TT-0818-05
BOLT
6
26 N510067783AA Low Head Cap Screw M3X5-8.8 A2J (Trivalent)
PIN
8
27 N510020597AA MMS4-8
S34
--
( KN610160756AA-26-2 )
9-C
X軸:NPM-D3
X-Axis:NPM-D3
パーツレイアウト
Kit No.
キット品番
Kit Name
キット名称
N610160756AA
セクションNo.
PARTS LAYOUT
Section No.
--
S35
( KN610160756AA-26-3 )
Ref
No.
Remarks R
1
Q'ty
9-C
X軸:NPM-D3
X-Axis:NPM-D3
ｲﾗｽﾄ
No.
Part No.
品 名品 番 数量
R
2
パーツリスト
Kit No.
キット品番
Kit Name
キット名称
N610160756AA
Part Name
備 考
セクションNo.
PARTS LIST
Section No.
R
3
PLATE
2
1 N210093674AB
BRACKET
2
2 N210191488AA
BOLT
2
3 N210184016AA
PLATE
2
4 N210194631AC
BRACKET
2
5 N210183605AD
PLATE
2
6 N210134648AD
BRACKET
2
7 N210103043AB
COVER
2
8 N210188364AB
BRACKET
2
9 N210084790AB
BRACKET
2
10 MTPB008229AA
BRACKET
4
11 N210189801AB
HEAD PLATE
2
13 MTKP002609AB
MOTOR
2
14 N510067049AA
S
DS3045C1C1AA5C1
PIN
8
15 N510020608AA MMS5-15
SCREW
8
16 N510018278AA
Cross recessed Truss head machine screw M4X5-4.8 A2S (Trivalent)
PIN
8
18 N510020589AA MMS3-8
SPACER
4
19 N510026166AA CF-314E
COUPLER
2
20 N510045363AA MA-MS-SC4-06X08(CS33418-4)
SPACER
4
21 N510036999AA ASF-2605E
BOLT
4
22 N510067793AA Low Head Cap Screw M4X10-8.8 SOB
SPACER
4
23 N510029513AA ASF-410E
BOLT
4
24 N510067791AA Low Head Cap Screw M4X6-8.8 SOB
S36
--
( KN610160756AA-26-3 )
