71.CONVEYOR(W)COMPONENTS
9
2 8
2 6
2 5
2 4
2 7
3 2
3 5
A
2 3
3 4
3 4
A
3 3
3 1
1 6
1 8
1 9
B
B
3 6
2 1
2 0
1 4
1 5
1 7
3 0
2 9
2 2
4
3
8
8
5
2
3
8
4
7
8
5
6
8
7
8
8
4 3
4 2
4 0
4 1
4 1
3 8
4 4
4 4
4 5
4 5
4 6
4 6
4 7
4 8
4 7
4 8
4 9
3 7
8
8
A
6
A
1 2 1 3
4 3
5 0
3 9
1 0
8
6
1 0
8
2
1
1 1
- -
REF.NO NOTE PARTNO DESCRIPTION Qty
1 400-71465 CONVEYORCOVER3020(W)ASSY 1
2 400-97785 CONVEYOR_COVER_LW (2)
3 400-97786 CONVEYOR_SIDE_COVER_LW (2)
4 400-97787 CONVEYOR_UPPER_COVER_LW (2)
5 400-01484 CONVEYORSHUTTERU(LEN) (2)
6 400-01485 CONVEYORSHUTTERB(LEN) (2)
7 400-27245 CONVEYORCOVERSTOPPER(EEN) (2)
8 SM-0040601-SC SCREWM4X0.7L=6 (48)
9 400-01490 TAPE (4)
10 E1143-721-000 WOOLENCLOTHPAPER (4)
11 E5721-729-000 LABEL (2)
12
#02
400-94890 STOPPERRLASM(LW) 1
13
#01
400-94889 STOPPERFLASM(LW) 1
14
#02
400-94520 STOPPER_FRAME_RL_LW (1)
15 400-00911 STOPERCONNECT (1)
16 PA-1002008-A0 AIRCYLINDER (1)
17 SM-6031402-TN SCREWM3X0.5L=8 (2)
18 PC-0105080-00 SPEEDCONTROLLER (1)
19 PJ-3040405-11 ELBOWUNION (1)
20 SL-6041292-TN SCREW (2)
21 E2169-721-000 HOLDPLATE (1)
22 400-00909 STOPER (1)
23 400-94522 STOPPER_CHIP_LW (1)
24 WP-0330516-SC WASHER3.3X8X0.5 (1)
25 WS-0310002-KN SPRINGWASHERM3 (1)
26 NM-6030001-SC NUTM3X0.5TYPE1 (1)
27 400-23788 STOPERSPACER (1)
28 SL-6030842-TN SCREWM3L=8 (1)
29 400-00910 STOPPERPIN (1)
30 RE-0200000-K0 E-RING (1)
31 WP-0320501-SC WASHERM3 (1)
32 SM-1030401-SE SCREWM3L=4 (1)
33 SM-1031201-SC SCREWM3X0.5L=12 (1)
34 E2039-721-000 WASHERA (2)
35 E2038-721-000 STOPPERCOLLAR (1)
36
#01
400-94521 STOPPER_FRAME_FL_LW (1)
37 400-11052 CONVEYOREXTENTION150ASM 1
38 400-11054 RAILPLATER(150) (1)
39 400-11055 RAILF(150) (1)
40 400-11056 RAILR(150) (1)
41 400-11057 PWBGUIDEEX(150) (2)
42 400-11058 CONVEYORBELTEX(150) (2)
43 400-11072 JOINTPLATEF(150) (2)
44 SL-6031092-TN SCREW (6)
45 SL-6031492-TN SCREWM3L=14 (4)
46 SL-6041292-TN SCREW (6)
47 SL-6041092-TN SCREW (8)
48 NM-6040002-SN NUTM4 (8)
49 HX-0044000-00 CABLEBAND (5)
50 400-11053 RAILPLATEF(150) (1)
- -
72.AUXILIARYMEMORYCOMPONENTS
1
2
6
4
5
3
