- - 85. EREPLACI NGOVERALLCHA NGERTRUCK COMPONENTS(2) 1 4 7 4 4 5 0 4 9 5 1 4 9 4 5 5 0 4 4 6 5 6 1 3 7 9 6 1 5 2 5 2 5 1 5 4 7 4 7 3 7 2 7 2 7 1 6 6 7 2 7 2 7 1 4 5 4 8 4 7 6 5 8 1 2 1 0 4 6 5 6 5 7 5 8 5 5 5 9 5…
- -
REF.NO NOTE PARTNO DESCRIPTION Qty
1 400-93575 E_BANK_ASSY 1
2 400-93576 E_BANK_SUB_ASSY (1)
3 400-71335 E_BANK_BASE (1)
4 E2602-721-000 BANKLOCATEBUSHA (2)
5 E2609-721-000 BANKLOCATEPINA (1)
6 E2610-721-000 BANKLOCATEPINB (1)
7 NM-6080003-SC NUTM8 (2)
8 WS-0820002-KN SPRINGWASHERM8 (2)
9 WP-0841601-SC WASHER8.4X17.4X1.6 (2)
10 400-71337 MARK_STAND (1)
11 E2505-729-0A0 MARKASM. (1)
12 E2505-729-000 MARKBASE (1)
13 E2601-725-000 MARK (1)
14 SL-6041292-TN SCREW (2)
15 SL-6052092-TN SCREW (2)
16 400-84622 FIXING_PLATE (4)
17 SM-3040652-TN SCREWM4L=6 (12)
18 400-84620 FIXING_BLOCK_D (4)
19 SM-3041052-TN SCREWM4L=10 (12)
20 400-84713 E_BANK_SHIM_0.02 (8)
21 400-84714 E_BANK_SHIM_0.03 (8)
22 400-84715 E_BANK_SHIM_0.05 (8)
23 400-84699 E_BANK_SHIM_0.10 (12)
24 SM-8040612-TP SCREWM4L=6 (20)
25 SM-8030602-TP SCREWM3X0.5L=6 (12)
26 SM-8041852-TP SCREWM4L=18 (8)
27 400-84619 FIXING_BLOCK_U (4)
28 SM-3040652-TN SCREWM4L=6 (12)
29 400-85588 RAIL_GUIDE_9 (3)
30 400-85589 RAIL_GUIDE_10 (1)
31 SM-6040802-TN SCREW (16)
32 400-85590 GUIDE_PLATE (41)
33 SM-3030552-TN SCREWM3L=5 (82)
34 SM-1030552-TN PLATESCREWM3L=5 (41)
35 400-93588 LOCK_SHAFT (1)
36 SM-6040802-TN SCREW (16)
37 E3074-729-000 BEARINGSHIMD (2)
38 400-93581 E_BANK_BASE_COVER (1)
39 SM-0040601-SC SCREWM4X0.7L=6 (8)
40 HX-0029400-00 FIXEDBASE (8)
41 SL-4030881-SC SCREWM3L=8 (8)
42 EA-9500B02-00 CABLEBAND150 (10)
43 400-93577 FDC_BRACKET_ASSY (1)
44 400-93589 FDC_BRACKET (1)
45 SL-6051092-TN BOLT (4)
46 400-93594 ETF_POSITION_LABEL(40) (1)
47 400-92647 EFIFCBL1-5ASM (1)
48 400-92648 EFIFCBL6-10ASM (1)
49 400-92649 EFIFCBL11-15ASM (1)
50 400-92650 EFIFCBL16-20ASM (1)
51 400-92651 EFIFCBL21-25ASM (1)
52 400-92652 EFIFCBL26-30ASM (1)
53 400-92653 EFIFCBL31-35ASM (1)
54 400-92654 EFIFCBL36-40ASM (1)
55 HK-0791900-00 CONNECTOR (80)
56 400-93590 FDC_BRACKET_STAY_L (1)
57 400-93591 FDC_BRACKET_STAY_R (1)
58 SL-6061292-TN SCREW (4)
59 HX-0022300-0A BUSHING (0.14)
60 400-93578 BANK_PCB_BOX_ASSY (1)
61 400-93592 BANK_PCB_BASE (1)
62 SL-6051092-TN BOLT (4)
63 401-87551 ELECBANK10PCBASMV2 (1)
64 HX-0009600-0A GROMMET (0.4)
65 HX-0029400-00 FIXEDBASE (8)
66 SL-4030691-SC SCREWM3L=6 (8)
67 400-93593 BANK_PCB_COVER (1)
68 SL-6030892-TN SCREW (4)
69 EA-9500B01-00 CABLEBAND (30)
70 EA-9500B02-00 CABLEBAND150 (30)
71 HX-0035400-0E BOARDPARTS (4)
72 SL-4030891-SC SCREWM3X8 (6)
73 400-01734 SCREW 4
74 E2732-721-000 BANKGUIDEROLLER 4
75 400-93582 FINGER_GUARD_BR 1
76 SL-6040892-TN BOLT 4
- -
85.EREPLACINGOVERALLCHANGERTRUCKCOMPONENTS(2)
1
4 7
4 4
5 0
4 9
5 1
4 9
4 5
5 0
4 4
6 5
6
1 3
7
9
6 1
5 2
5 2
5 1
5 4
7 4
7 3
7 2
7 2
7 1
6 6
7 2
7 2
7 1
4 5
4 8
4 7
6 5
8
1 2
1 0
4 6
5 6
5 7
5 8
5 5
5 9
5 7
7 0
7 0
6 9
7 0
6 9
5 3
1 4
1 5
1 5
1 0
1 2
1 8
1 6
1 7
1 8
2 1
2 6
2 6
1 9
2 3
2 0
2 4
2 4
1 9
2 5
2 5
8
1 1
4
3
1 1
4
3
2 1
2 2
2 2
2 1
2 2
2 1
2 2
2 9
2 8
2 7
4 3
4 3
4 6
4 8
3 5
3 0
3 6
3 4
3 2
3 1
7 0
6 9
7 0
6 9
7 0
6 9
7 0
6 9
7 0
7 0
7 0
5
7 0
7 0
6 6
6 7
7 1
7 1
6 8
6 8
6 8
7 2
7 2
7 2
7 2
6 7
4 1 4 2
7 5
7 6
6 4
3 8
3 9
4 0
3 7
3 3
2
6 2
6 0
6 3
6 3
- -
REF.NO NOTE PARTNO DESCRIPTION Qty
1 400-94893 TROLLEY_ASM 1
2 400-94927 TROLLEY_FRAME_ASM (1)
3 WP-0621036-SP WASHER (4)
4 SM-3061052-TN SCREW (4)
5 E4981-700-000 LABEL (1)
6 400-94837 TROLLEY_UPPER (1)
7 400-94322 TROLLY_BOTTOM (1)
8 400-01730 SCALEMARKSSEAL (2)
9 SM-6125052-TR SCREWM12L=150 (2)
10 WP-1052001-SC WASHER10,5X21X2 (4)
11 400-89239 E_TROLLEY_PLATE (4)
12 SL-6102042-TN SCREW (4)
13 400-94835 TROLLEY_STOPPER_BLOCK_R (1)
14 400-94836 TROLLEY_STOPPER_BLOCK_L (1)
15 SL-6082092-TN BOLT (6)
16 400-94833 BANK_PLATE_R (1)
17 400-94834 BANK_PLATE_L (1)
18 400-23221 SUPPORTSHAFT (2)
19 SM-8040602-TP SCREWM4X0.7L=6 (4)
20 E2703-721-000 TROLLEYSHAFT (1)
21 SB-8160005-C0 BEARING (4)
22 SL-6041042-TN BOLT (16)
23 400-94881 TROLLEY_SHAFT_L70 (1)
24 400-01748 TROLLEYSUBGUIDE (2)
25 SL-6063092-TN SCREWM6L=30 (2)
26 400-98942 SUPPORT_SHAFT (2)
27 400-23476 FGGUMSHEET (1)
28 WP-0430801-SC WASHERM4 (1)
29 SL-6040892-TN BOLT (1)
30 NM-6060003-SC NUTM6 (8)
31 400-94859 CASTER_107N (4)
32 SL-6082092-TN BOLT (16)
33 E2710-721-000 STOPPERATTACHMENT (2)
34 SM-6051002-TN BOLT (4)
35 E2711-721-000 TROLLEYSTOPPER (2)
36 SL-6061242-TN BOLT (8)
37 SM-3040652-TN SCREWM4L=6 (16)
38 400-94850 CASTER_BR (2)
39 SM-3040652-TN SCREWM4L=6 (8)
40 400-94860 TH_CASTER (4)
41
#01
400-94513 TRASH_BOX_L (1)
42 400-94858 TRASH_BOX (1)
43 400-94928 TROLLEY_HANDLE_ASM (2)
44 E2641-729-000 HANDLECLIP (1)
45 400-94854 HANDLE_SHAFT_ET (1)
46 SL-6083092-TN SCREW (3)
47 400-97175 TROLLEY_HANDLE (1)
48 SL-6040642-TN BOLT (1)
49 SL-6030642-TN SCREWM3L=6 (1)
50 E2635-729-000 HANDLESLIDER (1)
51 PS-0600182-KP SPRINGPIN (1)
52 PS-0400122-KP SPRINGPIN (2)
53 400-94929 TROLLEY_TAPE_GUIDE (1)
54 400-93594 ETF_POSITION_LABEL(40) (1)
55 400-94370 TAPE_GUIDE_BR_L (1)
56 400-94371 TAPE_GUIDE_BR_R (1)
57 SL-6061092-TN SCREW (4)
58 400-94372 TAPE_GUIDE_BR_C (1)
59 SM-3041052-TN SCREWM4L=10 (4)
60 400-94373 TAPE_GUIDE_SUPPORT_BR (1)
61 SL-4040891-SC SCREWM4L=8 (4)
62 400-94930 TAPEHOLDERCASM (1)
63 401-19292 ETF_POSITION_LABEL(40)_2 (2)
64 SM-1031001-SC SCREWM3X0.5L=10 (20)
65 400-94849 TAPE_HOLDER_PL (2)
66 400-94865 TAPE_FIXING_BAR (2)
67 SM-0030601-SC SCREWM3X0.5L=6 (12)
68 400-94863 TAPE_SUPPORT (3)
69 400-84674 REEL_SUPPORT_ANGLE (6)
70 SM-0030601-SC SCREWM3X0.5L=6 (18)
71 400-94862 TAPE_HOLDER_BR_1 (4)
72 SL-4040891-SC SCREWM4L=8 (16)
73 400-94864 TAPE_HOLDER_HANDLE (1)
74 SL-6051092-TN BOLT (2)
75 400-84676 SEPARATION_PLATE (20)
76 E1612-706-C00 REELSH (20)
