Master any mix.
Turn up the volume.
MYPro A40™ pick-and-place
INTUITIVE INTERFACE DESIGN
Of course, no modern production environment is
complete without the most streamlined user
interface. On the MYPro A40™, this means an
all-new graphical interface that raises the visibility
of vital process data while providing simple,
intuitive touchscreen guidance. It makes operator
training simple, day-to-day functions more
accessible and program settings virtually foolproof.
SOFTWARE-DRIVEN AUTOMATION
True to the MYPro™ assembly concept, the MYPro
A40™ includes the richest software suite in the
industry. Standard CFX and ERP interfaces enable
factory-wide connectivity. And MYCenter puts you
in full control with complete material tracking,
proactive replenishment, modern SQL databases
and enhanced process automation.
EASY MATERIAL MANAGEMENT
Mycronic’s modular feeder system is designed for
accuracy, ease of use and convenience. It gains
unrivalled flexibility from a combination of
intelligent feeders and magazines for tapes, sticks
and trays. Our unique Agilis™ feeders with no
moving parts are easier and quicker to load than
any other on the market. And by keeping pre-
loaded Agilis feeders on hand, you can perform
set-ups and changeovers even faster. Since all
Mycronic magazines can be replenished while
the machine is running, you never have to stop
production if you run out of components.
In addition, all magazines and Agilis feeders have
a unique identity that links them to the machine’s
system software. This enables the machine to
recognize the presence, absence and location of
components — a valuable asset when it comes to
keeping track of inventory, since the machine
knows exactly how many components are left on
each tape reel. Reprogramming of pick positions
is also eliminated. Instead, the system software
instantly recognizes the feeder, regardless of
machine or position, and reopti mizes the mounting
program to maintain the highest levels of eciency.
The Mycronic software suite includes:
• Full visibility planning and fast, error-free converting
of CAD and material data
• 100% stock accuracy with scannable feeders and ERP
connection module
• Complete traceability down to individual PCB level
• User-friendly material handling with e-labels for
paperless kitting guidance
• Proactive replenishment monitor with automated
material delivery
Available models and production cells
MYPro A40DX-13: feeder capacity up to 160 x 8mm reels
MYPro A40DX-17: feeder capacity up to 224 x 8mm reels
MYPro A40DX Synergy line:
• Two MYPro A40DX combined into a unified,
high-volume pick-and-place solution
• 118,000 cph rated top speed
• Feeder capacity up to 448 x 8 mm reels
* All MYPro A40DX models include two MX7 high-speed
mountheads and one MIDAS high-precision mounthead.
THE EVOLUTION OF AN ICON
Same robust frame and feeder technology. All-new
mounthead and user interface. A leap forward in
performance and versatility. Thanks to the all-new,
high-speed MX7™ mounthead technology, the
industry’s most flexible pick-and-place platform
just got turbocharged.
48% HIGHER THROUGHPUT
High-mix meets high-speed. Or rapid proto typing
meets volume production. However you look at it,
the MYPro A40DX™ maintains the industry’s fastest
changeovers while boosting top placement speeds
by up to 48%. Giving high-mix producers far higher
capacity for long series production runs. Or volume
manu facturers the flexibility to take on jobs of any
size without compromising overall cycle times.
Thanks to seven independently controlled pick-
and-place nozzles, the MX7™ mounthead optimizes
every movement to cover a vast range of
applications and component sizes.
MOUNT 6 TIMES LARGER COMPONENTS
Because each of the seven MX7™ nozzles moves
independently in theta and Z axes, they can pick,
rotate and place nearly any imaginable component
with extreme precision. Fine-pitch CSPs, FCs or
BGAs. From components as tiny as 01005 up to
those as large as 45x45x15 mm or as long as
150x40x15 mm. Or stacked, dipped and entirely
new package varieties. Whatever the next job
demands, a series of high-precision vacuum
sensors and a low-impact nozzle mass ensure you
can pick and place a significantly broader range of
parts and sizes without damaging, mis-picking or
dropping components.
40,000
cph
59,000
cph
118,000
cph
MX7™ Width / Length
45 x 45 mm
MX7™ Height / Width
15 x 45 mm
HYDRA
high-precision
mounthead
Width 18.6 x
Length 18.6 mm
HYDRA
H 5.6 x W 18.6 mm
MYPro™
MY300DX
Placement speed
Component size (top-view)
Component range improvement for high-speed mounthead
Component size (side-view)MYPro
A40DX™
*MYPro A40DX™
Synergy
Looking to expand your product mix and your production volumes? Now you can.
The MYPro A40™ delivers the high accuracy and fast changeovers you expect
from the icon of agility, together with a dramatic increase in throughput speed.
Whatever jobs tomorrow might throw your way, there’s never been a more
versatile way to scale up production and grow your business.
Bigger volumes.
Bigger opportunities.
The new MX7
™
mounthead
Flexibility. Turbocharged.
At the heart of the MYPro A40™ is the next-generation MX7™ mounthead
technology. The result of several years of in-house development, it
packs a powerhouse of independent motors, sensors and servo control
technologies into a remarkably compact footprint.
NEXT-LEVEL FLEXIBILITY
• Mount six times larger components up to
45x45x15 mm
• Mount long components up to 150x40x15 mm
HIGH-SPEED PERFORMANCE
• 48% faster top placement speeds
• 14 independent Z and Theta motors
PRECISION ENGINEERING
• Low-maintenance modular design
• 7 high-precision vacuum sensors for
low-force placement of less than 2N
The master of high-mix just turned up the volume.
All so you can handle the widest possible range
of components and batch sizes with the highest
productivity and fastest cycle times. Equipped
with the all-new high-speed MX7™ mounthead,
the MYPro A40™ paves a new path forward
towards the future of flexible assembly.
The MYPro A40
™
Flex your potential
Boost
your output:
48% higher
speeds
Expand your
possibilities:
6 times larger
component size
with MX7™
Simplify
your workflow:
All-new
intuitive user
interface
