MODEL GXH-1S

1202-007

Key No. PART No. PART NAME Q’ty REMARKS New Code

NOTE

601 6301257259 PLATE(PLATE) 2 803C--210-301 211D9475

602 6301233567 BRACKET 2 803C--210-302 211F7961

603 6301233628 BRACKET 2 803C--210-303 211F7963

604 6301233642 BRACKET 2 803C--210-304 211F7964

605 0914DA53 PLATE 2 803C--210-305 0914DA53

605 -01 0914DA4N TR100-70_GXH 2 0914DA4N

606 0914DA51 BRACKET 2 803C--210-306 0914DA51

606 -01 0914DA4N TR100-70_GXH 4 0914DA4N

607 6301569956 ASSY,BRACKET 2 803C--210-307 011F0169

607 -01 0914DA4N TR100-70_GXH 2 0914DA4N

609 6301546575 BRACKET 2 803C--210-309 211FC033

610 6301516561 MECH PARTS 2 803C--210-026 226J2323

611 6301530659 BRACKET 2 803C--210-311 211FB775

613 6301530734 BRACKET 2 803C--210-313 211FB779

615 6301359724 BRACKET 2 803C--210-315 211F9579

616 6301057965 ACCESSORY,P.C.B 14 803C--210-316 23L10081

617 6301233840 PLATE 2 803C--210-217 211D9273

618 6301233857 PLATE 2 803C--210-218 211D9274

619 6301233864 PLATE 2 803C--210-219 211D9275

620 6301240381 BRACKET 2 803C--210-220 211F8046

622 6301534817 BRACKET 2 803C--210-222 211FB857

624 6301233918 BRACKET 2 803C--210-224 211F7972

625 6301233925 BRACKET 2 803C--210-225 211F7973

626 6301359779 BRACKET 2 803C--210-055 211F9581

628 6301570075 BRACKET 2 803C--210-216 211FC426

629 6301536156 ENCODER(LIDA49M HEAD) 2 -U21 803C--210-005 23G40028

632 6301445533 COVER 2 803C--210-402 211AA550

633 6301430331 BRACKET 2 803C--210-403 211FA484

635 6301235523 UNIT,DRIVER 2 -A31(B),-A31(C),

803C--210-405 4U240428

636 6301250618 SOLENOID VALVE 2 -Y0902 803C--210-406 4L810328

637 6301347226 SOLENOID VALVE 2 -Y0901 803C--210-407 23D10008

638 6300955026 AIR LINE EQPT 2 803C--210-408 225B0367

639 6300036534 AIR LINE EQPT 2 803C--210-409 225B0059

640 6301430324 BRACKET 2 803C--210-410 211FA483

642 6301543307 BRACKET 2 803C--210-412 211FB975

643 6301544236 BRACKET 2 803C--210-413 211FB996

644 6301364346 BRACKET 2 803C--210-414 211F9651

645 6300037715 PIPE FITTINGS 2 225F0060

646 6300037746 PIPE FITTINGS 2 225F0061

648 6301541990 MOTOR,AC-SERVO 2 -M21 803C--210-203 4M150241

649 6301242507 P.C.B,MOUNT 2 -U25 803C--021-061 4B111464

650 6301325477 ACCESSORY,P.C.B 6 803C--210-159 23L10096

651 6300007527 BOLT,HEX-SCT 8 M3X10 221A0007

652 6300007602 BOLT,HEX-SCT 12 M4X6 221A0015

653 6300007619 BOLT,HEX-SCT 8 M4X8 221A0016

654 4110435004 SCR PAN 4X8 8 M4X8 PAN 221E0510

655 6300007626 BOLT,HEX-SCT 64 M4X10 221A0017

656 6300007633 BOLT,HEX-SCT 8 M4X12 221A0018

657 6300007657 BOLT,HEX-SCT 8 M4X16 221A0020

C-7

MODEL GXH-1S

1202-007

Key No. PART No. PART NAME Q’ty REMARKS New Code

NOTE

658 6300007756 BOLT,HEX-SCT 18 M5X12 221A0030

659 6300007763 BOLT,HEX-SCT 14 M5X16 221A0031

661 4111129001 SCR PAN 2X10 4 M2X10 PAN 221E0479

663 4110420703 SCR PAN 3X8 28 M3X8 PAN 221E0499

665 4110505004 SCR TRS 3X6 16 M3X6 TRS 221E0497

666 4110511708 SCR TRS 4X6 8 M4X6 TRS 221E0532

667 4111410307 NUT HEX 4 8 M4 221F0082

671 4111412608 WASHER SPR 2 4 SW2 221H0277

672 4110864408 WASHER SPR 3 20 SW3 F 221H0280

673 4111412806 WASHER SPR 3 8 SW3 221H0281

674 4110081706 WASHER SPR 4 8 SW4 F 221H0283

675 4111412905 WASHER SPR 4 88 SW4 221H0284

676 4111416705 WASHER SPR 5 32 SW5 221H0287

681 4111416903 WASHER V 2X5X0.3 4 FW2 221H0308

682 4111191909 WASHER V 3X7X0.5 20 FW3 F 221H0311

683 4111413902 WASHER V 3X7X0.5 8 FW3 221H0312

684 4111192104 WASHER V 4X9X0.8 8 FW4 F 221H0314

685 4111414008 WASHER V 4X9X0.8 84 FW4 221H0315

686 4111414107 WASHER V 5X10X1 32 FW5 221H0318

C-7
